ThE sETUp MENU

this menu is the starting point for access to all of the
parameters that control the way that the Geo operates.
to access this menu, first turn on the Geo and then
remove the 3 screws holding the right hand cheek
of the rubber grips . peeling back the
(sEE FigUrE 8.1)
cheek will reveal a red setup button
board , double-click this button or,
(sEE FigUrE 8.2)
alternatively, push and hold it for 2 seconds.
if the tournament lock is off then this menu is
(lOcK)
joined to the end of the main menu and can therefore
be accessed without tools.
36.
on the circuit
(a)
a
lOcK
ThE TOUrNaMENT lOcK paraMETEr
the Geo has a tournament lock which prevents the
user from making changes to any parameter that
affects the way in which the Geo shoots without the
use of tools.
this parameter is used to set the state of the
tournament lock and has the following choices:-
> ON: turn on the tournament lock. the set-up menu is
added to the main menu, making it easily accessible by
pressing and holding the button.
> OFF: turn off the tournament lock. the set-up menu
is only accessible by removing the right hand cheek of
the rubber grips and then pressing and holding the red
button on the circuit board.
sETUp
> caNcEl: cancel selection and leave the parameter
unchanged.
Fig 8.1
Fig 8.2
prEsET
ThE prEsET MENU
in order to simplify the set up of the Geo a number
of preset configurations are available for selection.
choosing one of these presets will cause all of the
necessary parameters to be set in such a way as to
make the Geo comply with the rules governing a
particular paintball league. it is also possible for the
user to save up to two preset configurations of their
own.
lOad
ThE lOad prEsET paraMETEr
this parameter is used to load the required preset
configuration and has the following choices.
> FacTOrY: reset every parameter to the factory set
defaults. the Geo leaves the factory set in this way and
this is also described on the run screen as semi.
> Nppl: load a set of parameters that configures the
Geo to comply with the 2008 nppl rules governing
firing modes.
> psp 08: load a set of parameters that configures the
Geo to comply with the 2008 psp rules governing firing
modes.
