Eclipse GEO Operator's Manual page 30

MaiNTaiNiNg ThE BOlT
assEMBlY
WARNING
warNiNg: dE-gas YOUr MarKEr, dischargiNg aNY
sTOrEd gas iN a saFE dirEcTiON, aNd rEMOVE ThE
BarrEl, lOadEr aNd air sYsTEM TO MaKE ThE MarKEr
EasiEr TO wOrK ON.
using a 1/4" hex key unscrew the prop shaft from the
marker body .
(sEE FigUrE 11.1)
once the threaded section is free from the threads in
the marker body and turning freely, pull the prop shaft
from the marker body (sEE FigUrE 11.2)
place a finger down the feed neck and push the
bolt free from the can inside the body by pushing it
backwards (sEE FigUrE 11.3). once the bolt is free from
the can, insert a finger into the rear of the marker and
remove the bolt completely
(sEE FigUrE 11.4)
58.
.
.
Fig 11.3
(cONTiNUEd)
by inserting a finger or an appropriately sized hex key
into the rear of the marker body
onto one of the holes in the can and extract it from the
marker body (sEE FigUrE 11.6) .
you should now have removed the following parts
from the marker body: the can (A), the bolt (b) and the
prop shaft (c) .
(sEE FigUrE 11.7)
take the can and having cleaned off any old grease,
paint or debris, apply a small amount of eclipse Grease
to the internal o-ring and the 2 external o-rings
FigUrE 11.8).
Fig 11.1
NOTE: remove Any excess blobs of eclipse GreAse
from the inside And outside of the cAn.
Fig 11.2
Fig 11.4
, hook
(sEE FigUrE 11.5)
Fig 11.5
(sEE
B
a
QUicK gUidE
CONTENTS
ORIENTATION
QUICK SET-UP
USING YOUR GEO
MENU TREE
ADVANCED SET-UP
MAINTENANCE
MAINTENANCE
FAULT FINDING
SERVICE CENTERS
Fig 11.6
PARTS LIST
SPARES & ACCESSORIES
c
Fig 11.7
Fig 11.8
59.
