Eclipse GEO Operator's Manual page 35

ThE gEO TriggEr
assEMBlY
having removed the trigger frame completely from the
Geo body (see page 62), use a 5/64" hex key to remove
the two screws that hold the bearing carrier in place
in the top of the frame
(sEE FigUrE 14.1)
the bearing carrier and trigger assembly free from the
trigger frame taking care not to damage the micro-
switch or the opto sensors
(sEE FigUrE 14.2)
using a 1/16" hex key, loosen the trigger pin retaining
set screw from the bottom of the trigger
. use a small hex key to push the trigger pin out of
14.3)
the bearing carrier from one side
(sEE FigUrE 14.4)
clean the trigger and bearing carrier thoroughly and
also clean the space within the frame that the trigger
sits into.
carefully remove the trigger spring from the spring
hole in the top of the trigger and clean off any paint
debris or moisture from it (sEE FigUrE 14.5)
68.
. Gently lift
.
(sEE FigUrE
.
.
Fig 14.2
(cONTiNUEd)
replace the trigger spring into the spring hole in the
top of the trigger and position the trigger so that the
hole through the trigger lines up with the holes in the
bearing carrier, slide the trigger pin in place and using a
1/16" hex key tighten down the trigger pin retaining set
screw to hold the assembly together
Gently lower the trigger assembly and bearing carrier
into the frame, taking care not to damage the micro-
switch or the opto sensor, and ensuring that the trigger
is positioned correctly (sEE FigUrE 14.7)
hex key tighten the two screws that hold the bearing
carrier in place in the top of the Geo frame.
Fig 14.1
you have now stripped and cleaned your Geo trigger
assembly.
Fig 14.3
Fig 14.4
.
(sEE FigUrE 14.6)
. using a 5/64"
