OPERATING INSTRUCTION MANUAL
OPTICAL INTERFEROMETIC GAS ANALYZER
Safety Precautions
1. Read and understand the instructions in this manual before operating this instrument.
2. Keep manual accessible at all times.
3. This instrument cannot be used for any other purpose than what is specified in this
manual.
4. Follow all the instructions in this manual, an deviation will compromise the safety, quality
and performance of this instrument.
5. We accept no responsibility for an accident caused by the user not following the
instructions in this manual.
FOR
MODEL FI-800
FOR USERS
PT3E-0271
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Riken Keiki FI-800
Summary of Contents for Riken Keiki FI-800
- Page 1 PT3E-0271 OPERATING INSTRUCTION MANUAL OPTICAL INTERFEROMETIC GAS ANALYZER MODEL FI-800 FOR USERS Safety Precautions 1. Read and understand the instructions in this manual before operating this instrument. 2. Keep manual accessible at all times. 3. This instrument cannot be used for any other purpose than what is specified in this manual.
- Page 2 「Installation work manual」. This manual is a guidebook for use of the FI-800. All persons who use this analyzer for the first time and who has ever used the analyzer are requested to read through the manual to understand the content before use.
-
Page 3: Table Of Contents
Contents Function of １． the product １－１ Overall view and accessories ‥‥‥‥‥‥‥‥‥‥‥‥ １－２ Name of display part and its functions ‥‥‥‥‥‥‥ Operation method ２． ２ー１ Start-up method ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥ ２－２ Reference gas calibration ‥‥‥‥‥‥‥‥‥‥‥ ２－３ Gas alarm action ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥ ２－４ Checking of preset alarm levels ‥‥‥‥‥‥‥‥‥‥... -
Page 4: Function Of The Product
Accessory : Control key △警告“強力磁石” △WARNING:MAGNET MODEL TC-7 RIKEN KEIKI ！ WARNING The control key used for adjustment is made from a powerful magnet. If it is closed to a credit card, ID card, other magnet products, this... -
Page 5: １－２ Name Of Display Part And Its Functions
1-2. Name of display part and functions ① MAINTENANCE/ESC switch‥‥Used for entering into the maintenance mode with the control key. [Used to cancel the maintenance mode.] ② PW/TR light ‥ ‥ ……………… Illuminates continuously when the equipment is working (power light). And flickers in the case of abnormality in the equipment. -
Page 6: ２. Operation Method
２. Operation method 2-1. Start-up method Before start-up FI-800, confirm that the correct pipings and wiring works are performed. (Refer to the separate manual 「Installation work manual」 for details.) (1) Confirm that the power is not supplied to the unit... -
Page 7: ２－２ Reference Gas Calibration
Confirm relations between 「reference gas」 and 「reference gas concentration」 with 「Specifications for measuring gas」 prepared separately. 2-3. Gas alarm action The FI-800 provides three alarm patterns such as 「H, HH alarm」, 「L, LL alarm」 and 「L.H. alarm」. Each alarm action has the 1... -
Page 8: ２－４ Checking Of Preset Alarm Levels
！ CAUTION b-contact( Break contact) at non-exiting condition may change to open contact in a moment due to physical shock. Whenever alarm signals are used with b-contact(option), please put delayed circuit( for about one second) to receiver side of b-contact to avoid such phenomenon. -
Page 9: ２－６ Trouble Indications And Countermeasures
Flashing CONT light This is a cautional indication for the decrease １ ２ of contrast. This means that the interferometric sensor is being dirty. Recommend to replace or repair it before interruption of measurement. Flashing 2-6. Trouble indications and countermeasures Display of error code number When the abnormality is detected during Flashing... -
Page 10: Operation Method In Maintenance Mode
３．Operation method in maintenance mode ３－１ Maintenance mode and summery of each menu Maintenance mode of FI-800 is to make 「 Confirmation of the status for interferometric sensor」, 「Adjustment of 4～20mA output」 「Adjustment of sensor sensitivity」, 「Setting of alarm levels」 etc. -
Page 11: ３－２ Contrast Display Of Interferometric Sensor
３－２. Contrast display of interferometric sensor Pressing the SET switch during is displayed, is displayed for about 1 second. ０．５ ０ ８ After that, CONT and AL1 lights turns ON as shown in right figure and contrast of interferometric sensor measured by light source 1 is displayed. -
Page 12: ３－４ Adjustment Of 4～20Ma Output
３－4. Adjustment of 4～20mA output Pressing SET switch while Ｌ ４．０ displayed, 4mA test signal is output as shown right figure. Pressing ▲▼switch, it changes to 20mA output. ▲▼switch When SET switch is pressed during 4mA or 20mA test signal output, LCD flashes and signal level can be adjusted with ▲▼switch. -
Page 13: ３－６ Setting Of Alarm Levels
３－6. Setting of alarm levels Pressing SET switch during is displayed, the alarm pattern of FI-800 is displayed. Under this condition, the 「1 alarm level」 and 「2 alarm level」 are shown with ▲▼switch. AL1 light and AL2 light turn on for 「1 alarm level」... -
Page 14: ３－７ Alarm Test
３－7. Alarm test It is possible to confirm alarm functions of this analyzer. ！ CAUTION When make alarm(transmission) test, announce it to respective department beforehand as this analyzer has an alarm contact. Carry it out after making proper treatment (external signal output, alarm contact). ①... -
Page 15: ３－８ Setting Of Auto Ref Cal Cycle (Option)
３－8. Setting of AUTO REF CAL CYCLE(Option) Pressing SET switch during is displayed, auto reference calibration cycle is displayed. This is an optional function. The FI-800 which has no optional function is set to 「 ACC.0 」. Select ０～７ with ▲▼switch A C C. -
Page 16: Maintenance And Inspection
４．Maintenance and inspection This analyzer is used to operate continuously for a long time. To keep the sufficient performance, regular inspection is required. － Maintenance contract － It is recommendable to make maintenance contract for regular inspection, adjustments, repairing including gas calibration to maintain stable operation and sensitivity. - Page 17 <Monthly including daily inspection> Item Countermeasure Confirmation of Supply reference gas from GAS IN by changing the external reference gas level 3-way cock position and confirm that the reference gas level is indicated. If not, make “Reference gas calibration.” Confirmation of Make displays of contrast and light amount for interferometric deterioration for sensor.
-
Page 18: ４－２ Replacement Of Fuse
(4) Supply the power source and confirm that the analyzer works in normal. ４－３. Treatment for storage or long-time shutdown (1) When FI-800 is not used for a long time, remove the measuring gas (especially solvent gases and vapors) inside pipings by blowing the fresh air or nitrogen. -
Page 19: ４－４ Recommendable Spare Parts List
４－4. Recommendable spare parts list Inspection Replacement Description Q’ty/set interval interval Sealing packing 1 year 7～8 years 1 set (Non-gas contact part) Sealing packing 1 year 2～4 years 1set (Gas contact part) Interferometric sensor 1 year 5～8 years 1 pce Circuit board 5～6 years 1 pce... -
Page 20: Troubleshooting
５．Trouble shooting This trouble shooting does not cover all causes of troubles. They are shown main troubles simply to assist studying of causes. Symptoms Causes Treatment ・Power is ・Supply the rated AC power source ・ Correct power source is not supplied supplied ・... -
Page 21: ６. Definition Of Word
６. Definition of word The definition of word to be used in this manual. Measuring gas Target gas to measure in sample gas Base gas Remaining gas excluding measuring gas in sample gas. Reference gas The gas to be used as the basic standard gas to measure gas concentration. -
Page 22: ８－１ Standard Specifications
Low sample flow, decrease of light amount for interferometric function light source, decrease of interferometer contrast. Power requirement 100VAC±10%～220VAC±10%, 50/60Hz, max 8VA Operating temp. & -10℃～+40℃, below 80%RH(Condensing gas inside FI-800 is humidity not possible) Outer dimensions Approx. 220(W) x 332(H) x 122(D)mm Weight Approx 16Kg. Structure Flame-proof ExdⅡB+H2T4... -
Page 23: ８－３ Detection Principle
As long as the kinds of composing gases are known, the mixing ratio(concentration) can be determined by measuring the refractive index. The optical interferometric sensor applied in the FI-800 displays “Interference fringes” on the image sensor. The interference fringes which shifts in proportion to refractive index is reflected onto the image sensor.
