6 Installation

6.1 Alignment of the sensing face

1
4
*) max. 1 Nm
The socket is rotatable:
7
► Tighten the socket according to the manufacturer's indications.
Observe the socket tightening torque 0.6...1.5 Nm.

6.2 Installation conditions

• The unit is non flush mountable in steel in accordance with IEC 60947-5-2,
type I2C40SP2. In addition one side of the unit can be mounted flush with
steel.
• The unit can be mounted flush with copper, aluminium and brass according to
IEC 60947-5-2, type I1C40SP2.
8
2
5
*)
8
3
6
9
