INSTALLATION, USE AND MAINTENANCE
CONTENTS
CONTENTS
FEATURES ................................................................................................................................ 2
OPERATION............................................................................................................................. 3
USE AS A PART OF A SAFETY SYSTEM...................................................................................... 3
TECHNICAL DATA.................................................................................................................... 4
INDICATORS............................................................................................................................ 5
INSTALLATION ......................................................................................................................... 6
Preacautions and mechanical installation ..................................................................... 6
Distance from reflecting surfaces .................................................................................. 6
Multiple systems. ......................................................................................................... 7
Safety distance and positioning .................................................................................... 7
ELECTRICAL CONNECTIONS.................................................................................................. 8
CHECKS AND MAINTENANCE ................................................................................................ 9
OPERATING FAULTS................................................................................................................ 9
WARRANTY ............................................................................................................................ 10
MECHANICAL DIMENSIONS ................................................................................................. 11
IDENTIFICATION LABELS ....................................................................................................... 12
ORDERING CODES AND SPARE PARTS ................................................................................. 12
Ordering codes......................................................................................................... 12
Spare parts ............................................................................................................... 12
PHOTOELECTRIC
BARRIER
ULISSE UPC
ULISSE UPC
73/23/CEE
89/336/CEE
1
Advertisement
Table of Contents
Related Manuals for Reer ULISSE UPC
Summary of Contents for Reer ULISSE UPC
-
Page 1: Table Of Contents
PHOTOELECTRIC BARRIER ULISSE UPC ULISSE UPC 73/23/CEE 89/336/CEE INSTALLATION, USE AND MAINTENANCE CONTENTS CONTENTS FEATURES ..........................2 OPERATION..........................3 USE AS A PART OF A SAFETY SYSTEM..................3 TECHNICAL DATA........................4 INDICATORS..........................5 INSTALLATION ......................... 6 Preacautions and mechanical installation ..............6 Distance from reflecting surfaces .................. -
Page 2: Features
CAUTION CAUTION Ulisse UPC photocell meets the requirements of a type 2 safety device only if connected with a certified safety interface in accordance with the Machine Directive (89/392 IEC and amendments) and with the standard IEC 1496-1, 2. ReeR SpA will not be liable for any consequence arising from the use of Ulisse UPC photocells under conditions differing from the ones described above. -
Page 3: Operation
IEC or European Standard (e.g. IEC 1496). No other use of Ulisse UPC as a safety device is admitted. REER will not be liable for any consequence arising from the use of Ulisse photocells under conditions differing from the... -
Page 4: Technical Data
TECHNICAL DATA TECHNICAL DATA MODEL MODEL UPCE-EMITTER UPCE-EMITTER UPCR-RECEIVER UPCR-RECEIVER Scanning range 0,8 ÷ 6 Minimum detectable item Immunity to ambient light > 10.000 (solar) Emission angle ± 4° Emission wavelenght 880 (modulated infrared) Response time < 8 Power supply 24 ±... -
Page 5: Indicators
INDICATORS INDICATORS COLOUR COLOUR STATE STATE INDICATION INDICATION Beam Yellow emitted EMITTER Test function Yellow or no beam Controlled Green area is free RECEIVER Controlled Green area is obstructed Figure 1 1 Figure... -
Page 6: Installation
INSTALLATION INSTALLATION Preacautions and mechanical installation Before installation please consider that: • Neither the emitter nor the receiver have to be placed in the proximity of high-intensity or blinking light sources • If the system is installed in places undergoing sudden temperature variations it is necessary to adopt the customary measures to prevent the formation of condensate on the lenses, as this might impair their detection capability. -
Page 7: Multiple Systems
Multiple systems. When using 2 pairs of ULISSE UPC photocells arranged next to or on top of each other in order to prevent them from mutually interfering it is necessary to arrange the elements so that the beam emitted by one system is received only by the respective receiver (fig. 3). -
Page 8: Electrical Connections
ELECTRICAL CONNECTIONS ELECTRICAL CONNECTIONS Ulisse UPC is fitted with a 3 pin M8 male connector (fig. 5). It is possible to use 5 m or 15 m cables equipped with an M8 female connector, either straight or at 90°, which can be supplied upon request. -
Page 9: Checks And Maintenance
CHECKS AND MAINTENANCE CHECKS AND MAINTENANCE The ULISSE UPC photocell has no specific maintenance requirement; at all events, we recommend cleaning the lenses of the emitter and the receiver at regular intervals, so as to prevent an excessive quantity of dust from building up and hampering the optical beam transmission and reception functions, as this may result in the failure of the equipment and the machine connected to it. -
Page 10: Warranty
At any rate, REER S.p.A. reserves the right to replace a defective apparatus in its entirety, with another of identical or similar characteristics, instead of repairing individual defective parts, at its discretion. -
Page 11: Mechanical Dimensions
MECHANICAL DIMENSIONS MECHANICAL DIMENSIONS Emitter and receiver Emitter and receiver... -
Page 12: Identification Labels
IDENTIFICATION LABELS IDENTIFICATION LABELS MOD. UPCE P/N 8011604 MOD. UPCR P/N 8011605 S/N field codification: Year of production Part number Week of production ORDERING CODES AND SPARE PARTS ORDERING CODES AND SPARE PARTS Ordering codes ITEM ITEM CODE CODE Emitter + receiver UPCE + UPCR 1200300 Emitter UPCE... - Page 13 REER s.p.a. REER s.p.a. 32 via Carcano 32 via Carcano 10153 Torino Italia 10153 Torino Italia Tel. +39-011/2482215 r.a. Tel. +39-011/2482215 r.a. Fax +39-011/859867 Fax +39-011/859867 Internet: Internet: www.reer.it e-mail: info@reer.it e-mail: info@reer.it...
