ASSEMBLY INSTRUCTIONS
®
RiverRidge
3 Tier Ladder Shelf
ITEM #: 02-068/06-092 WHITE
ITEM #: 02-069/06-093 GRAY
ADULT ASSEMBLY REQUIRED
This product requires assembly by an adult because of small parts. Care should be taken in
unpacking and assembling this item to keep small parts away from children.
WARNING
SEE FULL WARNING ON PAGE 2
Young children can be seriously injured or killed if furniture tips over. Don't use
this item for a TV stand or place heavy objects on top of item. Always use
angle-braces or anchors to secure furniture to the wall.
Advertisement
Related Manuals for RiverRidge 02-068/06-092
Summary of Contents for RiverRidge 02-068/06-092
- Page 1 ASSEMBLY INSTRUCTIONS ® RiverRidge 3 Tier Ladder Shelf ITEM #: 02-068/06-092 WHITE ITEM #: 02-069/06-093 GRAY ADULT ASSEMBLY REQUIRED This product requires assembly by an adult because of small parts. Care should be taken in unpacking and assembling this item to keep small parts away from children.
- Page 2 THIS SHELF UNIT WILL HOLD UP TO 20 POUNDS PER SHELF OR A TOTAL OF 60 POUNDS. DO NOT LOAD EACH SHELF WITH MORE THAN 20 POUNDS OR 60 POUNDS TOTAL WEIGHT. IF OVERLOADED WITH MORE THAN 20 POUNDS PER SHELF OR 60 POUNDS TOTAL WEIGHT, SHELF MAY TIP FROM WALL AND CAUSE SERIOUS INJURY OR DEATH.
-
Page 3: Parts List
PARTS LIST PARTS DESCRIPTION WOOD DOWEL 28 PCS CAM BOLT 4 PCS CAM LOCK 4 PCS MACHINE SCREW (6 X 20MM) 12 PCS WOOD SCREW (3.5 X 25MM) 27 PCS WALL SCREW (4 X 30MM) 1 PC WOOD SCREW (3 X 12MM) PLASTIC ANCHOR BRACKET 2PCS... - Page 4 PARTS DESCRIPTION BOTTOM SHELF RIGHT RAIL BOARD TOP SHELF MIDDLE AND BOTTOM 2 PCS SHELF REAR RAIL BOARD 2 PCS OP REAR RAIL BOARD TOP BAR OF LEFT AND 2 PCS RIGHT SIDE FRAME LEFT SIDE FRONT LEG LEFT SIDE REAR LEG RIGHT SIDE FRONT LEG RIGHT SIDE REAR LEG TOOLS NEEDED FOR ASSEMBLY: FLAT &...
- Page 5 STEP 1 1. Insert 1 wood dowel (A) into wood dowel hole on end of top rear rail board (10). 2. Attach top shelf left rail board (1) to top rear rail board (10) by inserting wood dowel (A) into hole on top shelf left rail board (1). Make sure hole on top rear rail board (10) is facing towards back side of shelf.
- Page 6 STEP 3 1. Insert 1 wood dowel (A) into wood dowel hole on end of rear rail board (9). 2. Attach bottom shelf left rail board (5) to rear rail board (9) by inserting wood dowel (A) into hole on bottom shelf left rail board (5). 3.
- Page 7 STEP 5 1. Insert 6 wood dowels (A) into wood dowel holes on middle shelf (8). 2. Attach middle shelf (8) to middle shelf rail board assembly by inserting wood dowels (A) into the wood dowel holes on middle shelf left rail board (3), middle shelf right rail board (4) and rear rail board (9).
- Page 8 STEP 7 1. Insert 2 wood dowels (A) into wood dowel holes on top bar (11). 2. Screw 2 cam bolts (B) into pre-threaded holes on top bar (11). 3. Attach top bar (11) to left side front leg (12) and left side rear leg (13) by inserting wood dowels (A) into wood dowel holes and inserting 2 cam bolts (B) into cam lock holes on left side front leg (12) and left side rear leg (13).
- Page 9 STEP 9 1. Attach pre-assembled top shelf（7）and rail boards to pre-assembled left-side frame by inserting 2 machine screws (D) through holes on left rail board (1) and tighten to pre-assembled left-side frame. 2. Repeat above step to assemble middle and bottom shelf (8) to pre-assembled left-side frame. STEP 10 1.
- Page 10 STEP 11 1. Place ladder shelf against wall and close to bracket (J). 2. Insert plastic lock strap (K) through hole on bracket (J) assembled on ladder shelf, then through hole on bracket (J) on wall and fasten plastic lock strap (K) to secure two brackets (J) firmly together.
- Page 11 ® Thank you for purchasing this RiverRidge Home item. We hope you ® enjoy it and consider purchasing other RiverRidge items. To order replacement parts at no cost to you, email customer.service@ssi-rr.com, call 1-(844)-223-5201 or order parts online at www.riverridgehome.com ®...
