- Page 1 EXCELSIOR - SUPERLARIO SEMI-ROTATIVE HAND-PUMPS. Use and maintenance manual GIANNESCHI Pumps and Blowers Srl Via Giulio Pastore 19/21 - 55040 Capezzano Pianore - Lucca – ITALIA Tel +39 0584 969391 (r.a.) Fax +39 0584 969411 Web Site: www.g-r.it - E-mail: Info@g-r.it...
- Page 2 Index. 1 Introduction 1.1. Condition of use. 1.2. Preliminary inspection. 1.3. Handing and storage. 2. Installation 2.1. Safety 3. Maintenance 4. Starting...
- Page 3 This document contains important information about the safety, use and maintenance of Excelsior and Superlario pumps, this booklet has to be read before put into service the pumps and make available to all others future operators. Conserve this booklet carefully.
- Page 4 INSTALLATION. During the installation all regulations for safety and good practice must be followed. The following points on installing and operating the pumps will ensure the best performance from the pumps: • Make sure the pump is installed in a position where it is accessible for working and maintenance.
- Page 5 MAINTENANCE. Gianneschi Pumps and Blowers hand operated pumps and are designed to require minimum of maintenance. The pump must be repaired only by competent or qualified personnel, using manufacturer's spares.
- Page 6 SPARE PARTS EXCELSIOR Pump Casing Washer Cover Lock washer Seal ring Counter flanges Shaft Flange packing Wing piston Screw Flaps Suction divider Raps VE packing Parallel Pin Handle Screw Handle Screw...
- Page 7 SPARE PARTS SUPER LARIO Pump casing O ring Plate valve Packing Piston Valve Cover piston Spring Washer for piston Washer Seeger Cotter pin Handle Packing Screw Cover Washer Screw Counter flange Cover Packing Packing Screw Screw Seal MIM Plug...
- Page 8 EXCELSIOR SUPERLARIO Description/Application field. Excelsior is double acting semi-rotary hand wing pump. Superlario is self priming double acting pistons pump, with a suction lift is up to 8 m. It is recommended for installations needing high suction lift Both pumps are suitable for fresh and sea water pumping, emptying bilge, emergency and oil transfer.
