ELCOS CAM-432 Instruction And User's Manual

This carries out the control and command function of a generator set, maintains the charge of the starter
battery and operates the contactors of the mains and of the generator so that power can be supplied to the
power users. It is constructed solely for built-in installation on an electric switchboard and to be connected
to other components (contactors, fuses, overload switches, etc...) that the installer will have prepared to
complete the system.
COMPLETE WITH:
• three-phase voltmeter check a three-phase mains a two-phase genset
• texts in 6 languages: Italian, English, French, German, Spanish and Portuguese.
• automatic supervision of faults
• glow plugs control
• starter control
• remote commands with contacts (startup- stop - test)
• EJP-functions
• easy programming by dip switches
• available input for anomaly
• clock for programming the start up or stopping of the genset
• programmable weekly selftest
• anomaly historical record (including data from the last 100 anomalies)
• automatic battery charger(1A)
• serial port RS232
ELCOS SRL - Parma - CAM-432 - MAN - EN
AUTOMATIC GENSET CONTROL UNIT WITH
DIESEL OR PETROL ENGINE
TYPE CAM-432
COMPLETE WITH DISPLAY TO
SHOW:
• useful signals for
generator set management.
• Instruments:
3 mains voltmeters
Generator voltmeter (TWO-PHASE)
3 ammeters main/genset
generator frequency meter
total hour meter
partial hour meter
battery voltmeter
fuel level indicator
