2015+ Ford Transit Low/Mid/High Roof Base Mounting Kit
Pages 2-3
Packaging Contents
Pages 4-7
Low Roof Medium Wheelbase (130")
Pages 8-11
Low Roof Long Wheelbase (148")
Pages 12-15
Mid/High Roof Medium Wheelbase (130")
Pages 16-19
Mid/High Roof Long Wheelbase (148")
Pages 20-23
Mid/High Roof Long Wheelbase Extended Length (148")
PRIME DESIGN, A SAFE FLEET BRAND ▪ Address: 1689 Oakdale Avenue #102, West St Paul, Minnesota 55118
Toll Free: 1.8.PRIME.RACK ▪ Fax: 651-552-1799 ▪ Email: info@primedesign.net ▪ Website: www.primedesign.net
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Safe Fleet Prime Design FBM-1017
Summary of Contents for Safe Fleet Prime Design FBM-1017
- Page 1 Mid/High Roof Long Wheelbase (148”) Pages 20-23 Mid/High Roof Long Wheelbase Extended Length (148”) PRIME DESIGN, A SAFE FLEET BRAND ▪ Address: 1689 Oakdale Avenue #102, West St Paul, Minnesota 55118 Toll Free: 1.8.PRIME.RACK ▪ Fax: 651-552-1799 ▪ Email: info@primedesign.net ▪ Website: www.primedesign.net...
-
Page 2: Contents Overview
CONTENTS OVERVIEW TWO & THREE CROSSBAR CONFIGURATIONS NOTE: This Manual contains information covering two and three Crossbar configurations. If your model is a two Crossbar configuration (ErgoRack only), disregard all Center Crossbar installation information. 1—FBM-1017 ............(Qty 1) Channels, 116” w/HKT-0132 Hardware Kit 23”... - Page 3 2—Crossbars (shown for illustrative purposes only) Ordered separately ErgoRack, Gen4 AluRack Prime Design Limited Warranty. Seller’s sole and exclusive warranty (and Buyer’s sole and exclusive remedy and Seller’s entire liability for any breach thereof) with respect to the Goods is set forth in the Limited Warranty document available at primedesign.net/warranty-liability (the “Prime Design Limited Warranty”).
-
Page 4: Mounting Brackets
LOW ROOF MEDIUM WHEEL BASE (130.00”) FBM ASSEMBLY SEQUENCE Prior to assembling the Channels and hardware, the OEM roof holes must be chased using an M8 x 1.25 tap and fluid. Doing so will ensure accurate torque is achieved. NOTE: Base, Rotation, Crossbar, and Side Rail features are shown for illustrative purposes only. - Page 5 The Channels include Torque all M8 x 25MM Flat Head Screws to aluminum Strip Nuts for a 150 in-lbs. Apply Silicone Sealant to screw 3 Crossbar configuration. heads to seal against water intrusion. For 2 Crossbar configurations, disregard the extra Strip Nut. F r o F r o Mid Crossbar...
- Page 6 CROSSBARS Shown with LH Base, and RH Rotation for illustrative purposes only 3E.1 h i c F r o h i c Do not mount the Crossbars to this FBM system at this time. Refer to the respective FEA or AR Assembly Manual(s) included with your chosen rack configuration features.
- Page 7 CROSSBARS (ALURACK) Shown with LR MWB AluRackfor illustrative purposes only h i c F r o 3A.1 h i c Do not mount the Crossbars to this FBM system at this time. Refer to the respective FEA or AR Assembly Manual(s) included with your chosen rack configuration features.
- Page 8 LOW ROOF LONG WHEEL BASE (148.00”) FBM ASSEMBLY SEQUENCE Prior to assembling the Channels and hardware, the OEM roof holes must be chased using an M8 x 1.25 tap and fluid. Doing so will ensure accurate torque is achieved. NOTE: Base, Rotation, Crossbar, and Side Rail features are shown for illustrative purposes only.
- Page 9 The Channels include Torque all M8 x 25MM Flat Head Screws to aluminum Strip Nuts for a 150 in-lbs. Apply Silicone Sealant to screw 3 Crossbar configuration. heads to seal against water intrusion. For 2 Crossbar configurations, disregard the extra Strip Nut. F r o Mid Crossbar Strip Nut...
- Page 10 CROSSBARS Shown with LH Base, and RH Rotation for illustrative purposes only 3E.1 h i c F r o h i c Do not mount the Crossbars to this FBM system at this time. Refer to the respective FEA or AR Assembly Manual(s) included with your chosen rack configuration features.
- Page 11 CROSSBARS (ALURACK) Shown with LR LWB AluRack for illustrative purposes only h i c F r o 3A.1 h i c Do not mount the Crossbars to this FBM system at this time. Refer to the respective FEA or AR Assembly Manual(s) included with your chosen rack configuration features.
- Page 12 MID/HIGH ROOF MEDIUM WHEEL BASE (130.00”) FBM ASSEMBLY SEQUENCE Prior to assembling the Channels and hardware, the OEM roof holes must be chased using an M8 x 1.25 tap and fluid. Doing so will ensure accurate torque is achieved. NOTE: Base, Rotation, Crossbar, and Side Rail features are shown for illustrative purposes only.
- Page 13 The Channels include Torque all M8 x 25MM Flat Head Screws to aluminum Strip Nuts for a 150 in-lbs. Apply Silicone Sealant to screw 3 Crossbar configuration. heads to seal against water intrusion. For 2 Crossbar configurations, disregard the extra Strip Nut. F r o F r o Mid Crossbar...
- Page 14 CROSSBARS Shown with LH Base, and RH Rotation for illustrative purposes only 3E.1 h i c F r o h i c Do not mount the Crossbars to this FBM system at this time. Refer to the respective FEA or AR Assembly Manual(s) included with your chosen rack configuration features.
- Page 15 CROSSBARS (ALURACK) Shown with MR/HR MWB AluRackfor illustrative purposes only h i c F r o 3A.1 h i c Do not mount the Crossbars to this FBM system at this time. Refer to the respective FEA or AR Assembly Manual(s) included with your chosen rack configuration features.
- Page 16 MID/HIGH ROOF LONG WHEEL BASE (148.00”) FBM ASSEMBLY SEQUENCE Prior to assembling the Channels and hardware, the OEM roof holes must be chased using an M8 x 1.25 tap. Doing so will ensure accurate torque is achieved. NOTE: Base, Rotation, Crossbar, and Side Rail features are shown for illustrative purposes only.
- Page 17 The Channels include Torque all M8 x 25MM Flat Head Screws to aluminum Strip Nuts for a 150 in-lbs. Apply Silicone Sealant to screw 3 Crossbar configuration. heads to seal against water intrusion. For 2 Crossbar configurations, disregard the extra Strip Nut. F r o Mid Crossbar Strip Nut...
- Page 18 CROSSBARS Shown with LH Base, and RH Rotation for illustrative purposes only h i c 3E.1 F r o h i c Do not mount the Crossbars to this FBM system at this time. Refer to the respective FEA or AR Assembly Manual(s) included with your chosen rack configuration features.
- Page 19 CROSSBARS (ALURACK) Shown with MR/HR LWB AluRackfor illustrative h i c purposes only F r o 3A.1 Do not mount the Crossbars to this FBM system at this time. h i c Refer to the respective FEA or AR Assembly Manual(s) included with your chosen rack configuration features.
- Page 20 HIGH ROOF LONG WHEEL BASE EXTENDED LENGTH (148.00”) FBM ASSEMBLY SEQUENCE Prior to assembling the Channels and hardware, the OEM roof holes must be chased using an M8 x 1.25 tap and fluid. Doing so will ensure accurate torque is achieved. NOTE: Base, Rotation, Crossbar, and Side Rail features are shown for illustrative purposes only.
- Page 21 The Channels include Torque all M8 x 25MM Flat Head Screws to aluminum Strip Nuts for a 150 in-lbs. Apply Silicone Sealant to screw 3 Crossbar configuration. heads to seal against water intrusion. For 2 Crossbar configurations, disregard the extra Strip Nut. F r o Mid Crossbar Strip Nut...
- Page 22 CROSSBARS Shown with LH Base, and RH Rotation for illustrative purposes only h i c F r o h i c Do not mount the Crossbars to this FBM system at this time. Refer to the respective FEA or AR Assembly Manual(s) included with your chosen rack configuration features.
- Page 23 CROSSBARS (ALURACK) Shown with HR LWBEL AluRack for illustrative purposes only h i c F r o 3A.1 h i c Do not mount the Crossbars to this FBM system at this time. Refer to the respective FEA or AR Assembly Manual(s) included with your chosen rack configuration features.
- Page 24 CENTER CROSSBAR MOUNTS FOR 2 CROSSBAR ERGORACK MODELS ONLY Place the center Crossbar Mounts into the vehicle’s glove box for future use. USAM-FBM1017-US01 Rev-A 0720 Prime Design Limited Warranty. Seller’s sole and exclusive warranty (and Buyer’s sole and exclusive remedy and Seller’s entire liability for any breach thereof) with respect to the Goods is set forth in the Limited Warranty document available at primedesign.net/warranty-liability (the “Prime Design Limited Warranty”).
