Item #1002 722 088
Model #91252
UL Model #56152
USE AND CARE GUIDE
PENDLETON 52-INCH CEILING FAN
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
To view an instructional video on how to install this product:
1. Go to www.homedepot.com and enter either the Item or Model number, found in the top
right corner of the cover of this instruction manual, in the search eld.
2. Click on your product from the list of search results and click on the video link in the
"Product Overview" section.
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this ceiling fan. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Related Manuals for HAMPTON BAY Pendleton 91252
Summary of Contents for HAMPTON BAY Pendleton 91252
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this ceiling fan. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
-
Page 2: Table Of Contents
Table of Contents Table of Contents ..............2 Assembly ................7 Safety Information ............... 2 Operation ................14 Warranty ................3 Care and Cleaning ............. 15 Pre-Installation ..............3 Troubleshooting ..............15 Installation ................6 Safety Information READ AND SAVE THESE INSTRUCTIONS. WARNING: To reduce the risk of personal injury, do To reduce the risk of electric shock, ensure the electricity has not bend the blade brackets (also referred to as... -
Page 3: Warranty
“wobble” is normal and should not be considered a defect. Servicing performed by unauthorized persons shall render the warranty invalid. There is no other express warranty. Hampton Bay hereby disclaims any and all warranties, including but not limited to those of merchantability and fitness for a particular purpose to the extent permitted by law. - Page 4 Pre-Installation (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Mounting screws (16 pieces for blade screws 32 pieces for medallion attachment) Wire connecting nut Hanger pin Locking pin...
- Page 5 Pre-Installation (continued) PACKAGE CONTENTS LIGHT/DIMMER GRA ATEUR LUM HAUT FAN OFF ARRET VENT Part Description Quantity Part Description Quantity Slide-on mounting bracket Medallion for blades (inside canopy) Light kit pan Ball/downrod assembly Glass bowl Canopy with canopy ring attached Blades Decorative motor collar cover Receiver Fan-motor assembly...
-
Page 6: Installation
Installation MOUNTING OPTIONS NOTE: You may need a longer downrod to maintain WARNING: To reduce the risk of fire, electric shock or proper blade clearance when installing on a steep, sloped personal injury, mount to outlet box marked “acceptable for fan support of 35 lbs. (15.9 Kg) or less” using the ceiling. -
Page 7: Assembly
Assembly - Standard Ceiling Mount Preparing for mounting Routing the wires □ □ Remove the canopy ring (EE) from the canopy (C) by turning the Route the wires exiting the top of the fan motor ring counter-clockwise until it unlocks. assembly (E) through the center of the canopy ring (EE). - Page 8 Assembly - Hanging the Fan Attaching the fan to the electrical box Hanging the fan □ Carefully lift the fan motor assembly (E) up to the mounting WARNING: To reduce the risk of fire, electric shock or personal bracket (A). injury, mount to outlet box marked “acceptable for fan support □...
- Page 9 Assembly - Hanging the Fan (continued) Setting the remote control codes Installing the receiver WARNING: To reduce the risk of fire or electric shock, NOTE: The frequencies on your receiver and hand unit have remember to disconnect power. The electrical wiring must been preset at the factory.
- Page 10 Assembly - Hanging the Fan (continued) Wiring the receiver to the Making the electrical connection household wiring WARNING: Each wire connecting nut supplied with this fan is WARNING: To avoid possible electrical shock, turn the designed to accept up to one 12-gauge house wire and two electricity off at the main fuse box before wiring.
- Page 11 Assembly - Hanging the Fan (continued) Mounting the fan Wrapping the extra wire WARNING: When using the standard ball/downrod mounting, the NOTE: Follow this step ONLY if you did not cut the extra length off tab in the ring at the bottom of the mounting bracket must rest in from the wires coming from the ceiling fan to the receiver.
- Page 12 Assembly - Hanging the Fan (continued) Attaching the medallion to the blades □ Attaching the medallion (G) to the blade (J) by using the attachment screws (AA) provided, inserting a attachment screw (AA) through a hole in the blade (J) and into the medallion (G).
- Page 13 Assembly - Installing the Light Kit (continued) Attaching the light kit fitter assembly CAUTION: To reduce the risk of electric shock, disconnect the electrical supply circuit to the fan before installing the light kit. □ Remove one screw (RR) from the light kit pan (H). Loosen but do not remove the other two mounting screws.
-
Page 14: Operation
Operation CAUTION: This device complies with part 15 of the FCC rules. Changes or modifications not expressly approved by the manufacturer could void your authority to operate this equipment. Remote Control - Your fan is equipped with a remote control to operate the speed and lights of your new ceiling fan. -
Page 15: Care And Cleaning
Repeat for each blade. Any measurement deviation should be within 1/8 in. Run the fan for ten minutes. If the fan continues to wobble please contact Hampton Bay Customer Service and a balancing kit will be sent to you at no charge. - Page 16 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
