We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this ceiling fan. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
USE AND CARE GUIDE
ANTIGUA PLUS 56-INCH CEILING FAN
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 6 p.m., EST, Monday-Friday.
1-855-HD-HAMPTON
HAMPTONBAY.COM
To view an instructional video on how to install this product:
1. Go to www.homedepot.com and enter either the Item or Model number, found in the top
right corner of the cover of this instruction manual, in the search eld.
2. Click on your product from the list of search results and click on the video link in the
"Product Overview" section.
Thank you for choosing Hampton Bay!
THANK YOU
Item #XXX-XXX
Model #91116, 91140
UL Model #56-ANTHL
Advertisement
Related Manuals for HAMPTON BAY ANTIGUA PLUS
Summary of Contents for HAMPTON BAY ANTIGUA PLUS
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this ceiling fan. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
-
Page 2: Table Of Contents
Table of Contents Table of Contents ..............2 Assembly ................7 Safety Information ............... 2 Operation ................13 Warranty ................3 Care and Cleaning ............. 14 Pre-Installation ..............3 Troubleshooting ..............14 Installation ................6 Safety Information All wiring must be in accordance with the National Electrical WARNING: To reduce the risk of personal injury, Code ANSI/NFPA 70-1999 and local electrical codes. -
Page 3: Warranty
“wobble” is normal and should not be considered a defect. Servicing performed by unauthorized persons shall render the warranty invalid. There is no other express warranty. Hampton Bay hereby disclaims any and all warranties, including but not limited to those of merchantability and fitness for a particular purpose to the extent permitted by law. - Page 4 Pre-Installation (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Part Description Quantity Blade attachment screw Pull chain Plastic wire connecting nut Extra blade bracket screw and Hanger pin lockwasher Locking pin Close-to-ceiling mount hardware (rubber gasket)
- Page 5 Pre-Installation (continued) PACKAGE CONTENTS Part Description Quantity Part Description Quantity Slide-on mounting bracket Blades (inside canopy) Blade bracket Ball/downrod assembly Decorative bowl cap Canopy with canopy ring attached Light kit fitter assembly Decorative motor collar cover Glass bowl Fan-motor assembly LED Light bulb, 9.5-Watt maximum Switch cup IMPORTANT: This product and/or components are...
-
Page 6: Installation
Installation MOUNTING OPTIONS NOTE: You may need a longer downrod to maintain WARNING: To reduce the risk of fire, electric shock proper blade clearance when installing on a steep, sloped or personal injury, mount to outlet box marked ceiling. The maximum angle allowable is 30° away from “acceptable for fan support of 35lbs. - Page 7 Assembly - Standard Ceiling Mount Preparing for standard mounting Routing the wires □ □ Remove the canopy ring (KK) from the canopy (C) by Route the wires exiting the top of the fan motor (E) into turning the ring counter clockwise until it unlocks. the decorative motor collar cover (D) and through the □...
- Page 8 Assembly - Close-To-Ceiling Mount Preparing for close-to-ceiling Routing the wires mounting □ Remove three of the six screws and lockwashers (MM) (every □ Remove the canopy ring (KK) from the canopy (C) by other one) securing the motor collar (M) to the top of the fan turning the ring counter clockwise until it unlocks.
- Page 9 Assembly - Hanging the Fan Attaching the fan to the electrical box Hanging the fan WARNING: The hook is only to hold the fan while attaching WARNING: To reduce the risk of fire, electric shock or wiring. Failure to hang the fan properly by following these personal injury, mount to outlet box marked “acceptable instructions may result in the hook breaking, causing the for fan support of 35lbs.
-
Page 10: Assembly
Assembly - Hanging the Fan (continued) Wrapping the extra wire Making the electrical connection NOTE: Follow this step ONLY if you did not cut the WARNING: Each wire nut supplied with this fan is designed to extra length off from the wires coming from the accept up to one 12-gauge house wire and two wires from the ceiling fan. - Page 11 Assembly - Hanging the Fan (continued) Mounting the fan - standard Mounting the fan close-to-ceiling WARNING: The locking slots of the ceiling canopy are provided only WARNING: When using the standard ball/downrod mounting, the as an aid to mounting. Do not leave the fan assembly unattended tab in the ring at the bottom of the mounting bracket must rest in until all four canopy screws are engaged and firmly tightened.
- Page 12 Assembly - Attaching the Fan Blades Attaching the fan blades □ Attach blade (G) to blade bracket (H) using the screws (AA) provided. Please note that the rubber washers are pre- attached to the blade bracket (H). Insert a screw into the blade bracket (H).
- Page 13 Assembly - Installing the Fan with the Light Kit Attaching the light kit fitter Installing the glass shades and bulbs assembly WARNING: To reduce the risk of electric shock, disconnect NOTE: Notice the location of the fan’s reverse switch (RR). the electrical supply circuit to the fan before installing the This is the switch used to change the fan’s directional light fixture.
- Page 14 Operating your Fan WARNING: To reduce the risk personal injury. Do not bend the blade holders while installing, balancing the blades, or cleaning the fan. Do not insert objects between rotating blades. Turn on the power and check the operation of the fan. The pull chain controls the fan speeds as follows: 1 pull - High, 2 pulls - Medium, 3 pulls - Low, 4 pulls - off The appropriate speed settings for warm or cool weather depend...
-
Page 15: Care And Cleaning
Care and Cleaning WARNING: Make sure the power is off before cleaning your fan. □ Because of the fan’s natural movement, some connections may become loose. Check the support connections, brackets, and blade attachments twice a year. Make sure they are secure. It is not necessary to remove the fan from the ceiling. □... - Page 16 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. - 6 p.m., EST, Monday-Friday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
