Installation and Operating Manual
Way Valve
WSR-D80112-S
Version 1.5, 2016-02-26
91800271810, Protection Class: 0: Offen (public)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WSR-D80112-S and is the answer not in the manual?

Questions and answers

Summary of Contents for Voith WSR-D80112-S

  • Page 1 Installation and Operating Manual Way Valve WSR-D80112-S Version 1.5, 2016-02-26 91800271810, Protection Class: 0: Offen (public)
  • Page 2 WSR-D80112-S Contact Contact Voith Turbo GmbH & Co. KG Voithstraße 1 74555 Crailsheim, GERMANY Phone: + 49 7951 32-0 Fax + 49 7951 32-500 E-mail www.voith.com Voith Turbo GmbH & Co. KG After-Sales Service of Business Unit Electronic Drive Systems Voithstraße 1...
  • Page 3: Table Of Contents

    WSR-D80112-S Contents Contents User Information Identification of text function Safety information Field of application General information Health and safety at work 1.5.1 Accident prevention 1.5.2 Environment General description of the way valve Proper use Technical Data Way Valve Packing, Storage, and Transportation...
  • Page 4 WSR-D80112-S Contents Test run Parameter settings 6.2.1 Potentiometer effect 6.2.2 Setting of X0 and X1 potentiometers 6.2.3 Setting of proportional gains 6.2.4 Adjustment of operating frequency SF 6.2.5 Adjustment of the hydraulic center position 6.2.6 Factory setting Operation Operation with manual operation knob...
  • Page 5: User Information

    WSR-D80112-S User Information 1 User Information 1.1 Identification of text function Texts in this installation and operating manual are differentiated as to their function and are identified accordingly. The following text functions are possible: Text type Function Action instruction 1., 2., etc.
  • Page 6: Safety Information

    WSR-D80112-S User Information 1.2 Safety information Safety information is classified as follows: DANGER  DANGER indicates an immediate threat to a person's life or health. Failure to observe this note will result in death or most serious injury. WARNING  WARNING indicates a potentially hazardous situation to the life and health of persons.
  • Page 7: Field Of Application

    The terms and conditions stated in the General Terms and Conditions of Sale for Industrial Engineering of Voith Turbo GmbH & Co. KG, Crailsheim shall apply. Warranty claims are excluded, if these are due to one or several of the following causes: ...
  • Page 8: Health And Safety At Work

    User Information NOTICE  During the warranty period, repair work on the way valve may be performed only with the approval of Voith Turbo GmbH & Co. KG, Crailsheim. Constructional modifications Mounting work and structural modifications are not permitted. The threaded joint of the cable gland on the control magnet (VRM) and the position pickup is secured against distortion.
  • Page 9: Accident Prevention

    WSR-D80112-S User Information 1.5.1 Accident prevention WARNING  Operating medium leaving/leaking out of the way valve may get in contact with hot machine parts, posing a risk of fire.  The way valve is under pressure!  On operation with manual operation knob, uncontrolled piston rod movements may result posing a risk to persons and property.
  • Page 10: Environment

    1.6 General description of the way valve In hydraulics, a "Voith way valve" serves to release, block or change the flow direction of the hydraulic fluid by converting a setpoint signal, 4mA to 20mA, into a linear movement of the control piston.
  • Page 11: Technical Data

    WSR-D80112-S Technical Data 2 Technical Data 2.1 Way Valve General data Way valve type WSR-D80112-S Article number 22000106810 Operating Manual No. 91800271810 Product identification See nameplate Ingress IP 65 as per EN 60529 protection Ambient temperature for operation T -20 ... +70 ...
  • Page 12 See Chapter 10 Hydraulic connection See Chapter 10 Weight approx. 21 1) According to customer's request or especially for high-flash point fluids 2) Fluor-caoutchouc 3) Acrylnitril-Butadien-caoutchouc 4) According to the customer's specification and consultation with Voith Turbo GmbH & Co.KG...
  • Page 13 WSR-D80112-S Technical Data Electrical data Supply voltage (power) including residual ripple 24 (+10% / -15%) V DC Current consumption 1 A, max. 3 A for t < 1 sec Supply voltage (control) 24 (+10% / -15%) V DC Current consumption 0.2 A...
  • Page 14: Packing, Storage, And Transportation

    If it is intended to store the way valve for a longer period of time, special precautions have to be taken. Coordinate such precautions for each individual case with Voith Turbo GmbH & Co. KG, Crailsheim. NOTICE  The ambient conditions for storage must be within the limits indicated in...
  • Page 15: Transport

    WSR-D80112-S Packing, Storage, and Transportation 3.3 Transport CAUTION  Improper transportation or lifting of the way valve may cause damage to property and personal injuries.  Ensure, in particular, that no constraining forces act on the cable gland of the control magnet.
  • Page 16: Design And Functioning

    WSR-D80112-S Design and Functioning 4 Design and Functioning 4.1 Design The way valve comprises the main functional units:  Voith Control Magnet VRM (1a)(1a) Manual operation knob (1b) Retaining clip (1c) Cable gland  Control housing  Control piston  Tappet for power transmission ...
  • Page 17: Function

    For way valve operation, an electric and a hydraulic auxiliary energy are required. All electric controllers and connections necessary for the way valve operation are integrated in the Voith control magnet (VRM). The control loop parameters and the parameters to scale the position of the piston rod are set via potentiometers on the VRM.
  • Page 18 WSR-D80112-S Design and Functioning Limitation of maximum value In case of incorrect connection of the setpoint, e.g. by unintentional connection of 24 VDC to the plus-port of the setpoint input, the setpoint current is limited to an uncritical value by means of an overload protector integrated in the VRM, thus protecting the way valve control against damage.
  • Page 19: Installation

    WSR-D80112-S Installation 5 Installation 5.1 Notes WARNING  Only staff satisfying the qualifications according to Chapter 1.5 is allowed to work on the way valve.  Work performed improperly could result in severe injuries. CAUTION  Electric lines, cable glands, cable entries and electric connections must not be damaged.
  • Page 20: Mounting

    WSR-D80112-S Installation 5.2 Mounting DANGER  Any work on the way valve may only be performed in de-energized condition and with the oil supply system switched off. During installation, the oil and power supply for the way valve has to be secured against unintentional switching-on.
  • Page 21: Hydraulic Connection

    WSR-D80112-S Installation In case of problematic locations, please confer with Voith Turbo GmbH & Co. Recommended fastening bolts  4 M12 hex. bolts, EN ISO 4762  Property class 10.9  Minimum tightening torque M = 88 Nm, thread oil-moistened (µr=0.08) ...
  • Page 22: Electrical Connection

    WSR-D80112-S Installation 5.4 Electrical connection DANGER  Work on electrical installations or operational equipment is only to be performed by qualified electricians or by trained staff under the guidance and supervision of a qualified electrician according to electro-technical regulations and the legal provisions of the respective country.
  • Page 23: Commissioning

    6 Commissioning NOTICE  Prior to delivery, the way valve has been tested and adjusted at Voith Turbo GmbH & Co. KG. The settings are documented in the supplied test report.  It must be ensured that the signal of the position pickup coming from the cylinder is falling, i.e.
  • Page 24 WSR-D80112-S Commissioning How to de-aerate the hydraulic system Operate the way valve for a period of min. 10 minutes at a setpoint sine rhythm (4 mA to 20 mA). Alternatively, it is possible to also run the setpoint via a ramp. Should it not be possible to specify a setpoint sine rhythm, connect a setpoint source directly to the way valve.
  • Page 25: Parameter Settings

    In order to be able to get to potentiometers SF and FM, loosen 2 hexagon socket screws on the cover and remove the latter.  Potentiometers SF and FM may only be adjusted upon prior consultation with Voith Turbo GmbH & Co. KG, Crailsheim. Position of potentiometers: Metal cover...
  • Page 26: Potentiometer Effect

    WSR-D80112-S Commissioning 6.2.1 Potentiometer effect Potentiometer Description The 0% position of the piston rod of the hydraulic cylinder can be adjusted by means of the X0 potentiometer. By turning the potentiometer clockwise, the piston rod moves towards increasing stroke. The 100% position of the piston rod of the hydraulic cylinder can be adjusted by means of the X1 potentiometer.
  • Page 27: Setting Of X0 And X1 Potentiometers

    WSR-D80112-S Commissioning 6.2.2 Setting of X0 and X1 potentiometers Position (%) Mech. stop hydr. cylinder Mech. stop Valve Regulation Mech. stop hydr. cylinder Setpoint w (mA) Fig. 5: Graph of regulation range With potentiometers X0 and X1, an effective stroke of the piston from a hydraulic cylinder can be allocated to setpoint 4..20 mA.
  • Page 28 WSR-D80112-S Commissioning NOTICE  Should the actual value remote indication increase permanently, i.e. higher than 4 mA when adjusting the potentiometer X0 counterclockwise, the lower mechanical stop (on valve adjustment usually the valve seat) is reached and the regulating range exceeded. In order to reach the "closed position" of a valve safely at a setpoint of 4 mA, even at thermal linear expansion or drifting of a signal, the stroke may also be adjusted at a setpoint of e.g.
  • Page 29: Setting Of Proportional Gains

    WSR-D80112-S Commissioning 6.2.3 Setting of proportional gains Potentiometers KPU and KPD allow for an easy adaptation of the proportional gain to the respective requirements of the application. Control parameters KPD and KPU on the way valve have been preset at the factory.
  • Page 30 WSR-D80112-S Commissioning Graph of step-change response (KPU and KPD) Setpoint w [mA] Time Actual value x Time Fig. 6: Graph of step-change response to a change in setpoint NOTICE  Set KPU before setting KPD. KPU influences the setting of KPD.
  • Page 31: Adjustment Of Operating Frequency Sf

    6.2.4 Adjustment of operating frequency SF NOTICE  Potentiometer SF may only be adjusted upon prior consultation with Voith Turbo GmbH & Co. KG, Crailsheim. If at operating temperature, the piston rod of the actuator vibrates with high frequency...
  • Page 32: Operation

    WSR-D80112-S Operation 7 Operation 7.1 Operation with manual operation knob The operation with the manual operation knob enables the uncontrolled positioning of the actuator without electrical connection of the way valve. NOTICE  During operation with the manual operation knob, a consumer, e.g. a hydraulic cylinder, is positioned uncontrolled.
  • Page 33: Normal Operation

    WSR-D80112-S Operation 7.2 Normal operation During normal operation, the way valve is operated with an external position setpoint. If the way valve does not work as expected, normal operation is interrupted. To remedy the malfunction, perform a troubleshooting analysis. 7.3 Troubleshooting NOTICE ...
  • Page 34 Connect setpoint source directly to the way control magnet valve. If malfunctioning still continues, replace the control magnet. Please consult Voith Turbo if a malfunction occurs which is not included in this table. NOTICE  Periodic steady-state vibrations of the piston rod always indicate some abnormal or even dangerous operating mode.
  • Page 35: Maintenance, Servicing And Inspection

    WSR-D80112-S Maintenance, Servicing and Inspection 8 Maintenance, Servicing Inspection NOTICE  For trouble-free and reliable operation of the way valve, inspection, maintenance and servicing are necessary and need to be performed in certain intervals.  The intervals indicated apply to way valve operation and proper use within the permissible operating conditions.
  • Page 36: Inspection

    WARNING  These inspection works must only be performed by the operator's trained expert personnel in an appropriate workshop or by Voith personnel at the Voith workshop (see Chapter 1.5). Remove the way valve from the machinery and have it...
  • Page 37: Spare Parts Information

    6 years (for NBR) and 10 years (for FPM). WARNING  Attention! Dismantling of the Voith way valve and the replacement of spare parts may only be performed by Voith Turbo or after prior consultation with Voith Turbo! 8.4 Seal replacement...
  • Page 38: Replacing The Control Magnet

    WSR-D80112-S Maintenance, Servicing and Inspection 8.5 Replacing the control magnet CAUTION  Before replacing the control magnet ensure that the oil supply to the way valve has been de-pressurized and the power supply been disconnected and secured against accidental switching on while working.
  • Page 39 WSR-D80112-S Maintenance, Servicing and Inspection Fig. 8: Removing the hex. nuts and washers Fig. 9: Removing the control magnet from the threaded rods...
  • Page 40: Mounting

    WSR-D80112-S Maintenance, Servicing and Inspection 8.5.2 Mounting Remount the control magnet in reverse order as described in Chapter 8.5.1. 1. Ensure that the 74x3 O-ring is in its groove and is not damaged (Fig. 10). 2. Check that the four M6 threaded rods are screwed into the control housing (Fig.
  • Page 41: Replacement Of The Hydraulic Part

    WSR-D80112-S Maintenance, Servicing and Inspection 8.6 Replacement of the hydraulic part CAUTION  Before replacing the hydraulic part ensure that the oil supply to the way valve has been de-pressurized and the power supply been disconnected and secured against accidental switching on while working.
  • Page 42: Mounting

    WSR-D80112-S Maintenance, Servicing and Inspection 8.6.2 Mounting Remount the hydraulic part in reverse order as described in Chapter 8.6.1. 1. Please ensure that the O-rings are in their grooves and are not damaged (Fig. 13). 2. Screw the hydraulic part on the adapter plate using the four M12 socket head screws and tighten same with a torque of 88 Nm.
  • Page 43: Decommissioning

    WSR-D80112-S Decommissioning 9 Decommissioning CAUTION  If the way valve is switched off for repair purposes or for a system shutdown, disconnect the hydraulic and electric supply systems, and secure them against accidental switch-on while working.  Relieve any possibly existing accumulators.
  • Page 44: Annex

    WSR-D80112-S Annex 10 Annex Outline Drawing 22000106812 Wiring Diagram 22000073912...
  • Page 45 WSR-D80112-S Annex Voith Turbo GmbH & Co. KG Electronic Drive Systems Voithstraße 1 D-74564 Crailsheim, Germany Phone: + 49 7951 32-470 Fax + 49 7951 32-605 E-mail turbinenstelltechnik@voith.com...

This manual is also suitable for:

22000106810
