Natus Quantum
Instructions for Use:
Natus Medical Incorporated
DBA Excel-Tech Ltd. (XLTEK)
2568 Bristol Circle
Oakville, Ontario, L6H 5S1 Canada
Tel: +1 905-829-5300
Website:
natus.com
EU Representative / Importer
Natus Manufacturing Limited
IDA Business Park
Gort, Co. Galway, Ireland
Associated Product Part Numbers:
017048
Copyright © 2021 by Natus Medical Incorporated. All Rights Reserved. All product names appearing on
this document are trademarks or registered trademarks owned, licensed to, promoted or distributed by
Natus Medical Incorporated, its subsidiaries or affiliates.
CaviWipes is a trademark of Metrex Research, LLC. Sani-Cloth is a registered trademark of PDI, Inc.
Description:
®
The Natus Quantum
10-10/10-20 Pin Box is a passive inbox replacing standard touch-proof connector
pin boxes on a Quantum Breakout Box. It provides convenient connection for electrodes placed according
to the International 10-20 or 10-10 placement scheme.
The 10-10/10-20 Pin Box features 32 additional referential inputs and 8 inputs that can be used either as
individual referential inputs or four bipolar channels.
®
10-10/10-20 Pin Box
Page 1 of 9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Quantum 10-10 and is the answer not in the manual?

Questions and answers

Related Manuals for natus Quantum 10-10

Summary of Contents for natus Quantum 10-10

  • Page 1 Associated Product Part Numbers: 017048 Copyright © 2021 by Natus Medical Incorporated. All Rights Reserved. All product names appearing on this document are trademarks or registered trademarks owned, licensed to, promoted or distributed by Natus Medical Incorporated, its subsidiaries or affiliates.

  • Page 2: Intended Use

    Intended Use: The Natus Quantum 10-10/10-20 Pin Box is intended to be used as an accessory with the Natus Quantum Breakout Box to provide to the EEG technician an input layout according to the 10-10 and ® 10-20 input scheme during routine EEG or LTM studies with NeuroWorks software.
  • Page 3 Edit | Settings | Acquisition (tab). Note: Additional Breakout Boxes can be added for additional channels. Refer to the section “Connecting the Breakout Boxes to the Natus Base Unit” of the Quantum User and Service Manual for additional information. Page 3 of 9...

  • Page 4: Cleaning Instructions

    5. Activate the 10-10 module for the Quantum by selecting the checkbox next to 10-10 MODULE under the Pinboard Usage section. Note: Refer to the section “Quantum Breakout Boxes MAIN and B” of the Quantum User and Service Manual to learn more about connectors on the Breakout Box.

  • Page 5: Environmental Specifications

    Misaligned connector pins may lead to damage of system components at power-on. • Refer to the Natus Quantum User and Service Manual for connection diagrams. CAUTION Device dropped or damaged in transit or use may lead to loss of function.

  • Page 6: Compliance Standards

    WEEE is reused or recycled safely. In line with that commitment Natus may pass along the obligation for take back and recycling to the end user, unless other arrangements have been made. Please contact us for details on the collection and recovery systems available to you in your region at natus.com...
  • Page 7 • Neurology: https://neuro.natus.com/neuro-support Search for “Natus Quantum 10-10/10-20 Pin Box IFU” (refer to the Product Part Number) and choose the version for your local language for the instructions to use. The files can be printed, saved, or searched using Adobe Reader. A copy of Adobe Reader can be downloaded directly from Adobe Systems (www.adobe.com).

  • Page 8: Glossary Of Symbols

    Glossary of Symbols: Standard Symbol Standard Title Symbol Title Explanation Reference Not applicable Not applicable An indication of This product is a medical device. Medical Device 21 CFR Part Labeling-Prescription Prescription only Indicates that the product is 801.109(b)(1) devices authorized for sale by or on the order of a licensed healthcare practitioner.
  • Page 9 Standard Symbol Standard Title Symbol Title Explanation Reference IEC 60601-1 Medical electrical Follow instructions for Refer to instruction manual/ equipment — Part 1: Table D.2 #10 Booklet. General requirements for basic safety and NOTE on ME EQUIPMENT "Follow instructions for use” essential performance Medical devices —...
