- Page 1 PROTIMETER Psyclone™ Protimeter Thermo-Hygrometer Operating Manual Amphenol Advanced Sensors INS7800, Rev. D May 2014...
- Page 2 Introduction The Protimeter Psyclone thermo- hygrometer measures relative humidity with psychometric measurements, along with temperature. One button Start Hold enables operation, and four arrow keys allow you to set up and change the measurements shown on the LCD screen. An optional surface temperature probe enables users to determine if condensation is present.
- Page 3 Table 1: Psyclone Measurement Parameters Parameter Symbol % Relative Humidity % RH Grains per pound g/kg Grams per kilo Gram Dewpoint DEW POINT Temperature Wet Bulb WET BULB Temperature kcal/kg Kilo Calorie per Kilogram BTU/lb British Thermal Units per Pound Ambient Temperature AMBIENT Surface Temperature SURFACE Proximity to Dew...
- Page 4 Starting the Psyclone for the First Time The Psyclone comes with two AA, 1.5V batteries already installed. To begin using the meter, extend the retractable probe and press the ) button. The LCD screen briefly flashes, similar to Figure 2 below. After a few seconds, the meter changes to measurement mode and displays only the currently selected...
- Page 5 Starting the Psyclone for the First Time (cont.) Figure 3: Typical Screen Display During Operation • To freeze the Psyclone at a particular reading, press the “Hold” button briefly. The message appears to the left of the temperature reading, as shown in Figure 2 on the previous page.
- Page 6 Selecting Parameters and Calculations Use the four arrow keys to select the parameters and calculations you want to display. Press any of the arrow keys to scroll to the parameter row (shown in Figure 2 on page 3); then RIGHT press the arrow key to scroll to the parameter or calculation.
- Page 7 Selecting Parameters and Calculation (cont.) • To select a calculation (Minimum, Maximum or Average): Scroll to the middle row, and then RIGHT LEFT press the arrow key to select the desired calculation. The min/max/ave calculations are made from the last time the meter was powered up.
-
Page 8: Setting User Options
Setting User Options To set up the user options to your particular requirements, firmly press SETUP DOWN and hold the key (the arrow key) for 2 seconds. The lower part of the screen appears similar to Figure 4 below. Figure 4: Setup Menu The factory default settings are: •... - Page 9 Setting User Options (cont.) • Units °F/°C — You can display all temperature measurements in either °F or °C. (Setting °C also results in displaying other parameters in metric units, such as g/kg. Setting °F prompts the meter to display other parameters in non- metric units, such as GPP or grains DOWN per pound.) Press the...
- Page 10 Setting User Options (cont.) • Backlight — You can set the backlight for the LCD display to remain on from 1 to 9 minutes at a “0” time. (If you set the time to the backlight is turned off.) Use DOWN arrow keys to scroll to the desired number of...
- Page 11 Using the Optional Surface Temperature Probe (# BLD5808 ) Note: The Surface Temperature (Surface) and Temperature Difference (Temp Diff) appear only if you are using the surface temperature probe option. To obtain surface temperatures via the optional probe: Plug in the surface temperature probe on the right side of the Psyclone.
- Page 12 Using the Optional Surface Temperature Probe (cont.) In Surface mode, the reading shown will be the surface temperature. (Allow time for the reading to settle.) In Temp Diff mode, the temperature shown will be the proximity to Dew Point (when condensation will occur). For example, a reading of 5 degrees would indicate that the surface temperature is 5 degrees above the...
-
Page 13: Error Codes
Caring for Your Psyclone • When you have finished using the Psyclone, retract the probe back into the meter. • Use the carrying case to protect the Psyclone when not in use. • Keep the Psyclone out of water, and away from dirt and dust. •... -
Page 14: Replacement Parts
Replacement Parts To order the parts listed below, or for additional service, contact Protimeter • Battery Cover (BAT7800) • Pouch (POU8512) • Belt Clip (BLD7810) Specifications Power 2 x AA 1.5v Enclosure PC with silicone Material rubber boot Dimensions ~165 mm x ~65 mm x ~30 mm (~6.5 in. - Page 15 Specifications (cont.) Operating 0 to 50°C Temperature (32 to 122°F) Range Probe -20 to 85°C Measurement (-4 to 185°F) Temperature Range in Duct Temperature ± 0.5°C Accuracy (0 to 50°C/ 32 to 122°F) Certifications CE Approval, RoHS Compliance & WEEE Emissions: Class A Immunity - Annex C.
-
Page 16: Dew Point
Glossary Symbol Definition % RH The ratio of the amount of water vapor in the air at a specific temperature to the maximum amount that the air could hold at that temperature, expressed as a percentage Specific The ratio of the mass of Humidity water vapor to the mass (GPP, g/kg and... - Page 17 Glossary (cont.) Symbol Definition WET BULB The temperature of a (°C/°F) wetted thermometer in moving air. The wet bulb temperature is a measure of the rate of evaporation, which is influenced by the amount of water vapor in the air. Enthalpy The amount of thermal (kcal/kg)
-
Page 18: Limited Warranty
Limited Warranty Amphenol Thermometrics, Inc. warrants the Psyclone thermo- hygrometer (Psyclone) against defects in material and workmanship for 24 months from the date of shipment. Materials or workmanship faults in the humidity and temperature probe assembly are covered for 12 months from the date of shipment. -
Page 19: Return Policy
MERCHANTABILITY OR FITNESS FOR PARTICULAR PURPOSE SHALL APPLY Amphenol Thermometrics, Inc. standard terms and conditions apply. Return Policy If a Amphenol Thermometrics, Inc. instrument malfunctions within the warranty period, the following procedure must be completed: 1. Notify Amphenol Thermometrics, Inc., giving full details of the... - Page 20 3. Upon receipt, Amphenol Thermometrics, Inc. will evaluate the instrument to determine the cause of the malfunction. Page 18 Protimeter Psyclone...
- Page 21 • If Amphenol Thermometrics, Inc. determines that the damage is not covered under the terms of the warranty, or if the warranty has...
- Page 23 Copyright © 2014 Amphenol Thermometrics, Inc. 967 Windfall Road St. Marys, Pennsylvania 15857, USA...
- Page 24 U.S.A. Amphenol Thermometrics, Inc. 967 Windfall Road St. Marys, Pennsylvania 15857, USA U.K. Amphenol Thermometrics (U.K.) Ltd. Crown Industrial Estate Priorswood Road Taunton, TA2 8QY, UK www.protimeter.com www.amphenol-sensors.com Amphenol Advanced Sensors INS7800, Rev. D May 2014...
