Sanitary mixproof valve
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Instruction Manual
Unique Sanitary Mixproof Valve (including US version)
ESE00923-EN8
2017-01
Original manual
TD 449-006_1
www.sks-online.com
www.sks-webshop.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Unique Basic and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alfa Laval Unique Basic

Summary of Contents for Alfa Laval Unique Basic

  • Page 1 Instruction Manual Unique Sanitary Mixproof Valve (including US version) TD 449-006_1 ESE00923-EN8 2017-01 Original manual www.sks-online.com www.sks-webshop.com...
  • Page 2 www.sks-online.com www.sks-webshop.com...

  • Page 3: Table Of Contents

    Table of contents The information herein is correct at the time of issue but may be subject to change without prior notice 1. Declaration of Conformity ................2. Safety ....................2.1. Important information ................2.2. Warning signs ..................2.3. Safety precautions ................3.
  • Page 4 Table of contents The information herein is correct at the time of issue but may be subject to change without prior notice 7.21. Axial installation tool ................7.22. Radial installation tool ................www.sks-online.com www.sks-webshop.com...

  • Page 5: Declaration Of Conformity

    1 Declaration of Conformity Revision of Declaration of Conformity 2013-12-03 The Designated Company Alfa Laval Kolding A/S Company Name Albuen 31, DK-6000 Kolding, Denmark Address +45 79 32 22 00 Phone No. hereby declare that Valve Designation Unique std. Type...

  • Page 6: Safety

    2 Safety Unsafe practices and other important information are emphasized in this manual. Warnings are emphasized by means of special signs. 2.1 Important information Always read the manual before using the Valve! WARNING Indicates that special procedures must be followed to avoid serious personal injury. CAUTION Indicates that special procedures must be followed to avoid damage to the valve.

  • Page 7: Safety Precautions

    Never touch the clip assembly or the actuator piston rod if the actuator is supplied with compressed air (see warning label) Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts.

  • Page 8: Installation

    Fit the warning label supplied on the valve after installation so that it is normally visible. 3.1 Unpacking/intermediate storage Step 1 CAUTION Alfa Laval cannot be held responsible for incorrect unpacking. Check the delivery for: 1. Complete valve. 2. Delivery note.
  • Page 9 3 Installation The instruction manual is part of the delivery. Study the instructions carefully. Fit the warning label supplied on the valve after installation so that it is normally visible. Step 5 Inspect the valve for visible transport damages. Inspection! TD 449-327 Step 6 Avoid damaging the air connections, the leakage outlet, the valve...

  • Page 10: General Information

    Never touch the clip assembly or the actuator piston rod if the actuator is supplied with compressed air (see the warning label). CAUTION Fit the supplied warning label on the valve so that it is normally visible. Alfa Laval cannot be held responsible for incorrect installation. NOTE Always install the valve vertically.
  • Page 11 3 Installation Study the instructions carefully and pay special attention to the warnings! The valve has ends for welding as standard but can also be supplied with fittings. Step 3 Fittings: Ensure that the connections are tight. Remember seal rings! Step 4 Air connection: R 1/8”...

  • Page 12: Welding

    Maintain the minimum clearances so that the actuator with the internal valve parts can be removed - please see later this section! If there is a risk of foot damage, Alfa Laval recommends to leave a distance of 120 mm (4.7”) below the valve (look at the specific built-in conditions).
  • Page 13 3 Installation Study the instructions carefully and pay special attention to the warnings! The valve has ends for welding as standard. Weld carefully/aim at stressless welding to avoid deformation on sealing areas. Check the valve for smooth operation after welding. Step 4 WARNING Make sure to turn the valve body correctly - conical valve seat...
  • Page 14 3 Installation Study the instructions carefully and pay special attention to the warnings! The valve has ends for welding as standard. Weld carefully/aim at stressless welding to avoid deformation on sealing areas. Check the valve for smooth operation after welding. NOTE! If ThinkTop®...
  • Page 15 3 Installation Study the instructions carefully and pay special attention to the warnings! The valve has ends for welding as standard. Weld carefully/aim at stressless welding to avoid deformation on sealing areas. Check the valve for smooth operation after welding. NOTE! If ThinkTop®...

  • Page 16: Recycling Information

    - At end of use, the equipment must be recycled according to the relevant, local regulations. Besides the equipment itself, any hazardous residues from the process liquid must be considered and dealt with in a proper manner. When in doubt, or in the absence of local regulations, please contact your local Alfa Laval sales company www.sks-online.com...

  • Page 17: Operation

    Never touch the clip assembly or the actuator piston rod if the actuator is supplied with compressed air (see the warning label). Never pressurise air connections (AC1, AC3) simultaneously as both valve plugs can be lifted (can cause mixing). CAUTION Alfa Laval cannot be held responsible for incorrect operation. Step 2 Burning danger! Never touch the valve or the pipelines when processing hot liquids or when sterilising.

  • Page 18: Fault Finding And Repair

    4 Operation The valve is adjusted and tested before delivery. Study the instructions carefully and pay special attention to the warnings! Pay attention to possible faults. The items refer to the parts list and service kits section. 4.2 Fault finding and repair NOTE Study the maintenance instructions carefully before replacing worn parts.

  • Page 19: Recommended Cleaning

    4 Operation The valve is designed for cleaning in place (CIP). CIP = Cleaning In Place. Study the instructions carefully and pay special attention to the warnings! NaOH = Caustic Soda. HNO = Nitric acid. Internal leakage in the valve is externally visible by means of the leakage outlet. 4.3 Recommended cleaning Step 1 Caustic danger!
  • Page 20 4 Operation The valve is designed for cleaning in place (CIP). CIP = Cleaning In Place. Study the instructions carefully and pay special attention to the warnings! NaOH = Caustic Soda. HNO = Nitric acid. Internal leakage in the valve is externally visible by means of the leakage outlet. Step 4 Examples of cleaning agents: Use clean water, free from chlorides.
  • Page 21 4 Operation The valve is designed for cleaning in place (CIP). CIP = Cleaning In Place. Study the instructions carefully and pay special attention to the warnings! NaOH = Caustic Soda. HNO = Nitric acid. Internal leakage in the valve is externally visible by means of the leakage outlet. Seat-cleaning cycles: Pay special attention to the warnings! 1.

  • Page 22: Maintenance

    Maintain the valve/actuator regularly. Study the instructions carefully and pay special attention to the warnings! Always use Alfa Laval genuine spare parts, and keep spare rubber seals and guide rings in stock. The valve is designed so that internal leakages do not result in the products becoming mixed. Internal leakage in the valve is externally visible. Check the valve for smooth operation after service.
  • Page 23 Maintain the valve/actuator regularly. Study the instructions carefully and pay special attention to the warnings! Always use Alfa Laval genuine spare parts, and keep spare rubber seals and guide rings in stock. The valve is designed so that internal leakages do not result in the products becoming mixed. Internal leakage in the valve is externally visible. Check the valve for smooth operation after service.

  • Page 24: Dismantling The Valve

    - If repair is required, replacing all actuator rubber seals is recommended. - Lubricate seals with Klüberplex BE31. - To avoid possible black remains on pos. 1 and 29, Alfa Laval recommends Klüber Paraliq GTE703 (white) for these two positions.
  • Page 25 Study the instructions carefully. The items refer to the parts list and service kits section. Handle scrap correctly. Always use Alfa Laval genuine spare parts. Replace seals if necessary. Step 2 Dismantling of lower sealing element: 1. Pull out o-ring (76) and lip seal (77).

  • Page 26: Lower Plug, Replacement Of Radial Seal

    Study the instructions carefully. The items refer to the parts list and service kits section. Handle scrap correctly. Always use Alfa Laval genuine spare parts. Step 5 1. If present, unscrew flushing tubes (66) and remove o-rings (67) and nozzles (68 + 69).
  • Page 27 Study the instructions carefully. The items refer to the parts list and service kits section. Handle scrap correctly. Always use Alfa Laval genuine spare parts. Step 2 Pre-mount seal ring as shown on drawing. Rotate along circumference to fix gasket as shown in the picture.

  • Page 28: Upper Plug, Replacement Of Axial Seal

    5 Maintenance Study the instructions carefully. The items refer to the parts list and service kits section. Handle scrap correctly Always use Alfa Laval genuine spare parts. Step 5 1. Supply compressed air. 2. Release compressed air. 3. Remove tool parts.
  • Page 29 5 Maintenance Study the instructions carefully. The items refer to the parts list and service kits section. Handle scrap correctly Always use Alfa Laval genuine spare parts. Step 3 Place tool part 1. Item no. Seat ø53 Seat ø81 Seat ø110 Seat ø115...

  • Page 30: Valve Assembly

    Study the instructions carefully. The items refer to the parts list and service kits section. Handle scrap correctly. Always use Alfa Laval genuine spare parts. Replace seals if necessary. 5.5 Valve assembly Step 1 1. Fit o-ring (47) (do not twist), lip seal (49) and o-ring (46) in upper sealing element (48) (Lubricate with Klüber Paralique GT 703).
  • Page 31 Study the instructions carefully. The items refer to the parts list and service kits section. Handle scrap correctly. Always use Alfa Laval genuine spare parts. Replace seals if necessary. Step 4 Recommended torque values for fitting upper and lower plug parts...
  • Page 32 Study the instructions carefully. The items refer to the parts list and service kits section. Handle scrap correctly. Always use Alfa Laval genuine spare parts. Replace seals if necessary. Step 6 - Never stick your fingers through the valve ports if the actuator is supplied with compressed air.

  • Page 33: Dismantling Of Actuator

    Study the instructions carefully. The items refer to the parts list and service kits section. Handle scrap correctly. Always use Alfa Laval genuine spare parts. Replace seals if necessary. 5.6 Dismantling of actuator Step 1 1. Dismantle the valve in accordance with instructions in section 5.2 Dismantling the valve...

  • Page 34: Assembly Of Actuator

    5 Maintenance Study the instructions carefully. The items refer to the parts list and service kits section. Always use Alfa Laval genuine spare parts. Replace seals if necessary. Lubricate the rubber seals before fitting them. 5.7 Assembly of actuator Step 1 Please see drawing when reassembling according to steps 2 to 5 on this page.

  • Page 35: Technical Data

    6 Technical data It is important to observe the technical data during installation, operation and maintenance. Inform the personnel about the technical data. 6.1 Technical data Unique is remote-controlled by means of compressed air. The valve is a normally closed (NC) valve. The valve has two independent plug seals, forming a leakage chamber between them under atmospheric pressure during every working condition.
  • Page 36 6 Technical data It is important to observe the technical data during installation, operation and maintenance. Inform the personnel about the technical data. Below table values for the Unique PMO version please refer to PD sheet. Size DN/OD 63.5 76.1 101.6 ISO/DIN/Sch.5 Kv-value...
  • Page 37 www.sks-online.com www.sks-webshop.com...

  • Page 38: Four Configurations Examples

    7 Parts list and service kits It is important to observe the technical data during installation, operation and maintenance. Inform the personnel about the technical data. 7.1 Four configurations examples TD 449-425 TD 449-426 Basic SeatClean www.sks-online.com www.sks-webshop.com...
  • Page 39 7 Parts list and service kits It is important to observe the technical data during installation, operation and maintenance. Inform the personnel about the technical data. TD 449-427 TD 449-428 HighClean UltraClean www.sks-online.com www.sks-webshop.com...

  • Page 40: Actuator

    7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. 7.2 Actuator 15.1 **11.1 **11 = acuator service kit = not used in actuator 1½” - 2”...
  • Page 41 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Parts list Pos. Denomination Upper stem Screw Air fitting Air fitting...
  • Page 42 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. 15.1 **11.1 **11 = acuator service kit = not used in actuator 1½” - 2”...
  • Page 43 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Parts list Pos. Denomination Upper stem Screw Air fitting Air fitting...

  • Page 44: Plug Setup Overview

    7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. 7.3 Plug setup overview Plug setup 1 Plug setup 2...

  • Page 45: Plug Setup 5

    7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Plug setup 5 Plug setup 6 2300-0022 2300-0023 Upper: Unbalanced with CIP OD spindle...

  • Page 46: Plug Setup 9

    7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Plug setup 9 Plug setup 10 2300-0026 2300-0027 Upper: Unbalanced...
  • Page 47 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Plug setup 13 Plug setup 14 2300-0030 2300-0031 Upper: Unbalanced...

  • Page 48: Plug Setup 10

    7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. 7.4 Plug setup 1 46 68 2300-0018 = wear parts = with SpiralClean in leakage chamber Pos.
  • Page 49 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Parts list Pos. Denomination Plug ♦ O-ring, EPDM O-ring, EPDM...
  • Page 50 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Service kits DN/OD 63.5 DN/OD 51 DN/OD 76.1 DN/OD 101.6 DN/OD 101.6...
  • Page 51 www.sks-online.com www.sks-webshop.com...

  • Page 52: Plug Setup 11

    7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. 7.5 Plug setup 2 2300-0019 = wear parts = with SpiralClean in leakage chamber Pos.
  • Page 53 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Parts list Pos. Denomination Plug ♦ O-ring, EPDM O-ring, EPDM...
  • Page 54 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Service kits DN/OD 63.5 DN/OD 51 DN/OD 76.1 DN/OD 101.6 DN/OD 101.6...
  • Page 55 www.sks-online.com www.sks-webshop.com...

  • Page 56: Plug Setup 12

    7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. 7.6 Plug setup 3 46 68 2300-0020 = wear parts = with SpiralClean in leakage chamber Pos.
  • Page 57 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Parts list Pos. Denomination Plug ♦ O-ring, EPDM O-ring, EPDM...
  • Page 58 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Service kits DN/OD 63.5 DN/OD 51 DN/OD 76.1 DN/OD 101.6 DN/OD 101.6...
  • Page 59 www.sks-online.com www.sks-webshop.com...

  • Page 60: Plug Setup 13

    7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. 7.7 Plug setup 4 2300-0021 = wear parts = with SpiralClean in leakage chamber Pos.
  • Page 61 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Parts list Pos. Denomination Plug ♦ O-ring, EPDM O-ring, EPDM...
  • Page 62 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Service kits DN/OD 63.5 DN/OD 38 DN/OD 51 DN/OD 76.1 DN/OD 101.6...
  • Page 63 www.sks-online.com www.sks-webshop.com...

  • Page 64: Plug Setup 14

    7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. 7.8 Plug setup 5 2300-0022 = wear parts = with SpiralClean in leakage chamber Pos.
  • Page 65 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Parts list Pos. Denomination Plug ♦ O-ring, EPDM O-ring, EPDM...
  • Page 66 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Service kits DN/OD 63.5 DN/OD 51 DN/OD 76.1 DN/OD 101.6 DN/OD 101.6...
  • Page 67 www.sks-online.com www.sks-webshop.com...

  • Page 68: Plug Setup 15

    7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. 7.9 Plug setup 6 2300-0023 = wear parts = with SpiralClean in leakage chamber Pos.
  • Page 69 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Parts list Pos. Denomination Plug ♦ O-ring, EPDM O-ring, EPDM...
  • Page 70 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Service kits DN/OD 63.5 DN/OD 38 DN/OD 51 DN/OD 76.1 DN/OD 101.6...
  • Page 71 www.sks-online.com www.sks-webshop.com...

  • Page 72: Plug Setup 16

    7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. 7.10 Plug setup 7 2300-0024 = wear parts = with SpiralClean in leakage chamber Pos.
  • Page 73 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Parts list Pos. Denomination Plug ♦ O-ring, EPDM O-ring, EPDM...
  • Page 74 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Service kits DN/OD 63.5 DN/OD 51 DN/OD 76.1 DN/OD 101.6 DN/OD 101.6...
  • Page 75 www.sks-online.com www.sks-webshop.com...
  • Page 76 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. 7.11 Plug setup 8 2300-0025 = wear parts = with SpiralClean in leakage chamber Pos.
  • Page 77 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Parts list Pos. Denomination Plug ♦ O-ring, EPDM O-ring, EPDM...
  • Page 78 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Service kits DN/OD 63.5 DN/OD 51 DN/OD 76.1 DN/OD 101.6 DN/OD 101.6...
  • Page 79 www.sks-online.com www.sks-webshop.com...
  • Page 80 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. 7.12 Plug setup 9 2300-0026 = wear parts = with SpiralClean in leakage chamber Pos.
  • Page 81 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Parts list Pos. Denomination Plug ♦ O-ring, EPDM O-ring, EPDM...
  • Page 82 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Service kits DN/OD 63.5 DN/OD 51 DN/OD 76.1 DN/OD 101.6 DN/OD 101.6...
  • Page 83 www.sks-online.com www.sks-webshop.com...
  • Page 84 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. 7.13 Plug setup 10 2300-0027 = wear parts = with SpiralClean in leakage chamber Pos.
  • Page 85 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Parts list Pos. Denomination Plug ♦ O-ring, EPDM O-ring, EPDM...
  • Page 86 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Service kits DN/OD 63.5 DN/OD 76.1 DN/OD 51 DN 65/ DN/OD 101.6...
  • Page 87 www.sks-online.com www.sks-webshop.com...
  • Page 88 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. 7.14 Plug setup 11 2300-0028 = wear parts = with SpiralClean in leakage chamber Pos.
  • Page 89 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Parts list Pos. Denomination Plug ♦ O-ring, EPDM O-ring, EPDM...
  • Page 90 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Service kits DN/OD 63.5 DN/OD 51 DN/OD 76.1 DN/OD 101.6 DN/OD 101.6...
  • Page 91 www.sks-online.com www.sks-webshop.com...
  • Page 92 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. 7.15 Plug setup 12 2300-0029 = wear parts = with SpiralClean in leakage chamber Pos.
  • Page 93 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Parts list Pos. Denomination Plug ♦ O-ring, EPDM O-ring, EPDM...
  • Page 94 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Service kits DN/OD 63.5 DN/OD 38 DN/OD 51 DN/OD 76.1 DN/OD 101.6...
  • Page 95 www.sks-online.com www.sks-webshop.com...
  • Page 96 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. 7.16 Plug setup 13 2300-0030 = wear parts = with SpiralClean in leakage chamber Pos.
  • Page 97 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Parts list Pos. Denomination Plug ♦ O-ring, EPDM O-ring, EPDM...
  • Page 98 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Service kits DN/OD 63.5 DN/OD 51 DN/OD 76.1 DN/OD 101.6 DN/OD 101.6...
  • Page 99 www.sks-online.com www.sks-webshop.com...
  • Page 100 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. 7.17 Plug setup 14 2300-0031 = wear parts = with SpiralClean in leakage chamber Pos.
  • Page 101 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Parts list Pos. Denomination Plug ♦ O-ring, EPDM O-ring, EPDM...
  • Page 102 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Service kits DN/OD 63.5 DN/OD 38 DN/OD 51 DN/OD 76.1 DN/OD 101.6...
  • Page 103 www.sks-online.com www.sks-webshop.com...
  • Page 104 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. 7.18 Plug setup 15 2300-0032 = wear parts = with SpiralClean in leakage chamber Pos.
  • Page 105 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Parts list Pos. Denomination Plug ♦ O-ring, EPDM O-ring, EPDM...
  • Page 106 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Service kits DN/OD 63.5 DN/OD 51 DN/OD 76.1 DN/OD 101.6 DN/OD 101.6...
  • Page 107 www.sks-online.com www.sks-webshop.com...
  • Page 108 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. 7.19 Plug setup 16 2300-0033 = wear parts = with SpiralClean in leakage chamber Pos.
  • Page 109 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Parts list Pos. Denomination Plug ♦ O-ring, EPDM O-ring, EPDM...
  • Page 110 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Service kits DN/OD 63.5 DN/OD 51 DN/OD 76.1 DN/OD 101.6 DN/OD 101.6...
  • Page 111 www.sks-online.com www.sks-webshop.com...

  • Page 112: Valve Body

    7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. 7.20 Valve body 2300-0017 2300-0016 Body combination - welded bodies www.sks-online.com...
  • Page 113 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Parts list Pos. Denomination Intermediate piece Valve body Valve body, upper...
  • Page 114 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. 7.21 Axial installation tool TD 449-038_1 www.sks-online.com www.sks-webshop.com...
  • Page 115 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Parts list Pos. Denomination Lower Part Piston Upper Part O-ring, NBR...
  • Page 116 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. 7.22 Radial installation tool TD 449-354 www.sks-online.com www.sks-webshop.com...
  • Page 117 7 Parts list and service kits Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Parts list Pos. Denomination Piston Lower Part Upper Part Bushing...
  • Page 118 © Alfa Laval Corporate AB This document and its contents is owned by Alfa Laval Corporate AB and protected by laws governing intellectual property and thereto related rights. It is the responsibility of the user of this document to comply with all applicable intellectual property laws. Without limiting any rights related to this document, no part of this document may be copied, reproduced or transmitted in any form or by any means (electronic, mechanical, photocopying, recording, or otherwise), or for any purpose, without the expressed permission of Alfa Laval Corporate AB.
