Instruction Manual
Unique PMO Plus CP HT Series
Sizes 2½", 3", 4" & 6"
ESE 02217 2012-05
Sanitary Mixproof Valve
Effective 05/04/2012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Unique PMO Plus CP HT Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Alfa Laval Unique PMO Plus CP HT Series

  • Page 1 Instruction Manual Unique PMO Plus CP HT Series Sanitary Mixproof Valve Sizes 2½", 3", 4" & 6" Effective 05/04/2012 ESE 02217 2012-05...
  • Page 3: Table Of Contents

    Table of Contents The information contained herein is correct at the time of issue but may be subject to change without prior notice. Introduction ....................4 Safety ......................5 Installation ....................6 Specifications ..................... 8 Pneumatic Connections ................10 Position Indication ..................11 Electrical Connections ............
  • Page 4: Introduction

    Failure to do so may result in loss of warranty. Where defects appear on the product during the warranty period, Alfa Laval Inc. will back the product and correct the problem. Should the equipment be modified or not kept in the manner prescribed within this manual, the warranty will become null and void.
  • Page 5: Safety

    Laval for replacement. Maintain equipment in good working condition. Do Not Make Machine Modifications Alfa Laval offers a full range of products to suit all your needs. Therefore, product modification is never necessary. Keep Maintenance Safe Replace damaged or worn parts immediately. Never allow old product, debris, or any lubricants to build up on equipment.
  • Page 6: Installation

    Line Mounted Valve: The valves may be installed in lines that are firmly supported and capable of carrying the valve’s weight. Mount valves at an 15° angle, or as close as possible, ensuring that the angle is as least 15°. Furthermore Alfa Laval recommends that the valve is supported at the actuator.
  • Page 7 Installation Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Clearances required for removal of actuator/plug assembly for repair. 2317-0001 Size 2.5" 3" 4" 6" 6" (2.95") (2.32") stroke stroke 28.94 29.88 38.46 42.83 42.83 34.13 35.59 45.47 52.32...
  • Page 8: Specifications

    Specifications Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual It is important to observe the specification data during installation, operation and maintenance. Valve size 2", 2½" & 3" 4" 6" Stroke length (inch) 1.50 2.95 1.97 2.95 Product pressures (PSI)
  • Page 9: Step

    Specifications Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual CIP solution flows for seat lift (viscosity and density similar to water) CV Values Unique PMO Plus CP HT 2½" & 3" 4" 6" Upper seat lift 12.1 Tank plug push 58.3...
  • Page 10: Pneumatic Connections

    Pneumatic Connections Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Valve Pneumatic Functions: Unique PMO Plus CP HT Valve Series Out 2 Out 1A Out 3 AC1 (red) (Upper seat push) AC2 (blue) (open/close) AC3 (yellow) Valve Pneumatic Connections (Lower seat push) Actuator...
  • Page 11: Position Indication

    Position Indication Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Valve Position Indication: Unique PMO Plus CP HT Series External Sensor & LED (Upper Seat Position Detection) Lower Seat Closed ('A' LED) Open Valve ('B' LED)
  • Page 12: Electrical Connections

    Electrical Connections Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Unique PMO Plus CP HT Valve Series Mixproof Valve ThinkTop , 8-30 VDC #9612-5789-66 (0 Solenoid) ® Electrical Connection Chart ThinkTop Function Remarks Term. No. +8-30 VDC Power + -Common...
  • Page 13: Thinktop

    Electrical Connections Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Unique PMO Plus CP HT Valve Series ThinkTop , 8-30 VDC #9612-5789-69 (3 Solenoids) ® Electrical Connection Chart ThinkTop Function Remarks Term. No. Solenoid - 1 Output - Valve Open Solenoid - 2 Output - Lower Seat Push...
  • Page 14 Electrical Connections Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Unique PMO Plus CP HT Valve Series ThinkTop , 110 VAC #9612-9906-66 (0 Solenoid) ® Electrical Connection Chart ThinkTop Function Remarks Term. No. 110 VAC Power + -Common Power -...
  • Page 15 Electrical Connections Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Unique PMO Plus CP HT Valve Series , 110 VAC #9612-9906-69 (3 Solenoids) ThinkTop ® Electrical Connection Chart ThinkTop Function Remarks Term. No. Solenoid - 1 Output - Valve Open Solenoid - 2 Output - Lower Seat Push...
  • Page 16 Electrical Connections/In- ThinkTop ®, structions Instruction Manual ThinkTop Digital 8 - 30 VDC & 110 VAC PNP/NPN ® Used with Unique PMO Plus CP HT Series Mixproof Valves Effective 05/04/2012...
  • Page 17 Automation Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Digital 8-30 or 110 VAC NO/NC ThinkTop ®, Features *)The initial current during power-on is higher. Typical values are Tolerance 440 mARCS during 10 ms (the first half cycle) followed by 270 The tolerance band is ±1.5 mm.
  • Page 18 Automation Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Digital 8-30 or 110 VAC NO/NC ®, ThinkTop Solenoid valves Up to 3 solenoid valves in each unit. Type ....................3/2 or 5/2 valve (only with one 5/2 valve). Air supply ..................
  • Page 19 Automation Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual ThinkTop ®, Digital 8-30 or 110 VAC NO/NC A. Digital interface command signals B. Internal connections to solenoid 1-3 C. Feedback signals to digital interface D. Jumper connections **) E.
  • Page 20 Installation Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Step 1 Always read the technical specifications thoroughly (see chapter 3). Always have the ThinkTop electrically connected by authorized personnel. ® Always install the ThinkTop before valve or relay is in a safe position. ®...
  • Page 21 Installation Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Step 5 Fit the ø6 mm (1/4") air tubes to ThinkTop (see drawing "Air ® connections" on page 20). Step 6 Fit the air tubes to the actuator (see drawing "Air connections" on page 20).
  • Page 22 Installation Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Step 9 Make sure the cable gland is completely tightened. Step 10 Set up the ThinkTop (see setup diagram page 21 and 22). ® Effective 05/04/2012...
  • Page 23 4.3 Air connections 4. Installation Air Connections Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Air restriction (throttle function) air inlet/outlet Air out 1A Air exhaust Manual hold override Air out 1B (5/2 port solenoid valve only) Solenoid 3/2 or 5/2 Air out 2 3/2 Solenoid...
  • Page 24 Setup diagram Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual ThinkTop setup utilizing local 'I' and 'II' Keys ® General: 1. Flashing IND means no value set. Notes: - Scroll across, no change Steady IND means value set as shown. - Notes Requires Key Function 2.
  • Page 25 Setup diagram Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual LED D, A steady if closed position enabled LED D steady, A flashing if closed position disabled LED D steady, C flashing Actuate the if valve type disabled (LED D flashing) valve to closed position...
  • Page 26 Fault Finding Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Below is stated the meaning of the LEDs' indications for fault finding in connection with the operation of the ThinkTop ® Red flashing: Unit in set-up mode or internal software fault. If internal software fault, re-program unit.
  • Page 27 Fault finding and LEDs Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Yellow steady: Position A (closed valve). Yellow A Yellow steady: Position B (open valve). Yellow B Yellow steady: Position C (Seat lift 1-2 or external sensors). Yellow C Green steady: Solenoid valves activated.
  • Page 28 Maintenance Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Study the instructions carefully. Handle scrap correctly. Always keep spare X-rings in stock. Step 1 1. Remove the ThinkTop from the actuator. ® 2. Pull out X-ring and replace it. Step 2 1.
  • Page 29 Dismantling of ThinkTop Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Study the instructions carefully. Handle scrap correctly. Always keep spare X-rings in stock. Step 5 To remove the sensor unit untighten screw and pull out the sensor unit.
  • Page 30 Maintenance Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Study the instructions carefully. Handle scrap correctly. Always keep spare X-rings in stock. Step 1 Place sensor unit in base and tighten screw (torque: 1 Nm). Step 2 Assemble base with adapter by turning adapter slightly anticlockwise and tighten the three screws (1.9 Nm).
  • Page 31 Assembly of ThinkTop Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Study the instructions carefully. Handle scrap correctly. Always keep spare X-rings in stock. Step 5 1. Replace X-ring. 2. Mount ThinkTop on actuator. ® Effective 05/04/2012...
  • Page 32 Unique PMO Plus CP HT Valve Series Electrical Connections/In- Series Sanitary Mixproof Valve Instruction Manual structions Spare Parts ThinkTop ® P/N 9612578966 8-30 VDC P/N 9612578969 P/N 9612990666 110 VAC P/N 9612990669 Effective 05/04/2012...
  • Page 33 ThinkTop ® Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Effective 05/04/2012...
  • Page 34: Cleaning Procedures

    Each mixproof valve shall be properly operated, including seat lifting, during CIP cleaning to assure exposure to product contact surfaces. Alfa Laval recommend that the cleaning nozzles inside the vent cavity is used during the CIP Cleaning. The nozzles are accessed though the external inlet located at the intermediate piece.
  • Page 35 Cleaning Procedures Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Recommend Cleaning – Specific The chart below provides reference to cleaning solution agents, temperature and exposure times necessary during circulation to achieve good cleaning results. All data shown is required for each valve during cleaning.
  • Page 36 Cleaning Procedures Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Valve Pneumatic Operation During In-Place Cleaning Series) Unique PMO Plus CP HT Each valve seat shall be lifted during the length of the cleaning cycle. Seat lift durations shall not exceed 10 seconds. These pneumatic functions include: 1.
  • Page 37 Cleaning Procedures Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Guide Bearing Cleaning When the valves are removed for replacement of wetted parts and / or sealing elastomers, it is important to remove, and hand clean, the three PTFE guide rings (positions 45, 54, 80) and their seating groves before placing the valves back into service.
  • Page 38: Valve Seat Position Indication

    Valve Seat Position Indication Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Test - 1 Upper Valve Seat Position Detection 'C' LED (Seat Lift) 1. Valve at rest (closed) position · "C" LED (Seat Lift) on ThinkTop is illumated. 2.
  • Page 39 Valve Seat Position Indication Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Test - 2 Lower Valve Seat Position Detection 'A' LED (Closed Valve) 1. Valve at rest (closed) position · "A" LED (Closed Valve) on ThinkTop is illuminated. 2.
  • Page 40 Valve Seat Position Indication Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Adjustments Upper Valve Seat External Sensor (24VDC or 110VAC) (Position Data Existing on ThinkTop) Lock Nuts The following instructions should be made while the valve is hot from CIP cleaning. (worst case) Valve is in a rest position.
  • Page 41 Valve Seat Position Indication Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Adjustments Upper Valve Seat ThinkTop (Set Position New on ThinkTop) The following instructions can be completed while the valve is at room (ambient) temperature.
  • Page 42 Valve Seat Position Indication Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Test - 3 Regulatory Inspection, Confirm Control System Seat Lifting Interlock During an Operating, active CIP Circuit Description of components to be used for this test: 1.
  • Page 43 Valve Seat Position Indication Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Test procedure listed as follows: 1. Select a Unique PMO Plus CP HT mixproof valve for interlock testing. 2. Decide if the cleaning solution will flow through the mixproof valve upper or lower body as part of the CIP cleaning circuit for the test.
  • Page 44: Maintenance

    Maintenance Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual General Maintenance: Replace all product wetted seals every 12 months. Tools Required for Valve Service · 2 x 16mm Wrench · Strap Wrench - 19mm and 13mm ·...
  • Page 45 Maintenance Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Dis-Assemble Valve (Excluding Actuator) 1. Remove ThinkTop. 2. Activate main stroke. See pages 66 to 74 for part numbers. Effective 05/04/2012...
  • Page 46 Maintenance Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual 3. Remove clamp. 4. Remove valve. 5. Release air. 6. Remove flushing pipe using 19mm wrench. See pages 66 to 74 for part numbers. Effective 05/04/2012...
  • Page 47 Maintenance Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual 7. Remove clamp rings. 8. Activate upper seat lift. 9. Loosen lower plug by using 2 16mm wrenches. See pages 66 to 74 for part numbers. Effective 05/04/2012...
  • Page 48 Maintenance Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual 10. Turn out lower plug by hand and remove plug assembly. 11. Remove spindle liner and lock ring. 12. Remove upper stem by using a 13mm and a 16mm wrench. See pages 66 to 74 for part numbers.
  • Page 49 Maintenance Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual 13. Remove lock ring 14. Remove valve body sealing element. and rotaing nozzle by pulling upwards. 15. Sanitize guide ring. See pages 66 to 74 for part numbers. Effective 05/04/2012...
  • Page 50 Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual 64 61 16. Remove clamp, vent body and sealing element. 17. Sanitize guide ring. See pages 66 to 74 for part numbers. Effective 05/04/2012...
  • Page 51 4. Maintenance 4.3 Tank plug, replacement of radial seal 4. Maintenance 4.3 Tank plug, replacement of radial seal Study the instructions carefully. Maintenance Unique PMO Plus CP HT Valve Series The items refer to the parts list and service kits section. Study the instructions carefully.
  • Page 52 4. Maintenance 4.4 Balanced plug, replacement of axial seal 4. Maintenance 4.4 Balanced plug, replacement of axial seal Maintenance Unique PMO Plus CP HT Valve Series Study the instructions carefully. Series Sanitary Mixproof Valve Instruction Manual The items refer to the parts list and service kits section. Study the instructions carefully.
  • Page 53 Maintenance Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Re-Assemble Valve (Excluding Actuator) Assembly valve body sealing element: 1. Lubricate o-rings & lip seal. 2. Mount all components in sealing element. See pages 66 to 74 for part numbers. Effective 05/04/2012...
  • Page 54 Maintenance Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Mounting rotating nozzle and O-ring on upper plug: 3. Lubricate o-ring. 5. Mount o-ring on upper plug. 4. Nozzle and lock ring slides over spindle. See pages 66 to 74 for part numbers. Effective 05/04/2012...
  • Page 55 Maintenance Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Mounting valve body sealing element on upper plug: 6. Ensure sealing element is orientated so the white guide ring is upwards. Mounting two-way nozzle, spacer and guide rings: 7.
  • Page 56 Maintenance Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual 10. Insert spacer. 11. Insert last guide ring. 12. Insert tank plug from the bottom of upper plug. See pages 66 to 74 for part numbers. Effective 05/04/2012...
  • Page 57 Maintenance Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual 14. Tighten. Use a 13mm and 16mm wrench. Torque 20Nm. 13A and 13B. Mount stem for lower plug. 15. Mount o-ring. Mounting yoke on actuator: 16. Lubricate o-ring. See pages 66 to 74 for part numbers.
  • Page 58 Maintenance Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual 17. Mount yoke and the 3 nuts and washers. 18. Use a 13mm wrench. Tighten nuts to 12Nm. 19. Mount o-ring on actuator spindle. 20. Mount plastic bolt and sensor. Assembly vent body sealing element: 21.
  • Page 59 Maintenance Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Assembly valve: 23. Lubricate o-ring. Spindle liner can be turned both ways except 6". 24. Place sealing element 25. Mount the o-ring. 26. Mount vent body. with o-ring and lip seal 27.
  • Page 60 Maintenance Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Lower plug. 28. Activate compressed air on lower seat push (yellow air fitting placed on top of actuator). 29. Insert valve plug assembly through vent sealing element. 30.
  • Page 61 Maintenance Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual 35. Mount flushing pipe. tighten with 19mm wrench. 36. Deactivate lower seat push. 37. Activate compressed air on main stroke (blue air fitting placed mid on actuator). 38.
  • Page 62 Maintenance Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Dismantling of actuator 1. Remove nuts (36) and washers (35). 2. Pull out intermediate piece (37) from the actuator. 3. Remove cover disk (25). 4. Remove retaining ring (24). 5.
  • Page 63 Maintenance Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Actuator Exploded View Effective 05/04/2012...
  • Page 64 Maintenance Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Reassembly of actuator Fit guide ring (6) and O-ring (5). Fit O-rings (7 and 9). Place upper piston (8). Fit stop (4). Tighten screws (2). Place spring assembly (10). Fit O-ring (19) and guide ring (18).
  • Page 65: Parts List

    Parts List Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual See pages 66 to 74 for part numbers. Effective 05/04/2012...
  • Page 66 Parts List Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual See pages 66 to 74 for part numbers. Effective 05/04/2012...
  • Page 67 Parts List Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual See pages 66 to 74 for part numbers. Effective 05/04/2012...
  • Page 68 Parts List Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual See pages 66 to 74 for part numbers. Effective 05/04/2012...
  • Page 69 Parts List Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Effective 05/04/2012...
  • Page 70 Parts List Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Parts Unique PMO Plus CP HT Demonination PMO 2½" PMO 3" PMO 4" PMO 6" PMO 6" (stroke 2.95") (stroke 2.32") Cpl. Actuator 9613-0995-25 9613-0995-25 9613-4890-52 9613-4890-52 9613-4890-56...
  • Page 71 Parts List Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Parts Unique PMO Plus CP HT continued from previous page Demonination PMO 2½" PMO 3" PMO 4" PMO 6" PMO 6" (stroke 2.95") (stroke 2.32") Flushing tube 9614-0308-01 9614-0308-01...
  • Page 72 Parts List Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Parts Unique PMO Plus CP HT Pos. Qty. Denomination PMO 2½" PMO 3" PMO 4" PMO 6” Intermediate piece 9613-0191-23 9613-0191-23 9613-0192-17 9613-4966-03 Valve body TL, clamp end 9614-0050-01 9614-0053-01 9614-0056-01...
  • Page 73 Parts List Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Parts Pos. Qty. Denomination 2½" and 3" 4" and 6" ThinkTop Complete (8-30VDC, 0-Solenoids) 9612-5789-66 9612-5789-66 ThinkTop Complete (8-30VDC, 3-Solenoids) 9612-5789-69 9612-5789-69 ThinkTop Complete (110VAC, 0-Solenoids) 9612-9906-66 9612-9906-66 ThinkTop Complete (110VAC, 3-Solenoids)
  • Page 74 Parts List Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Unique PMO Plus CP HT Wear Parts Qty. Denomination 2½" and 3" 4" 6" O-ring, EPDM 9611-99-2671 9611-99-2671 9611-99-5160 O-ring, EPDM 9611-99-3493 9611-99-3493 9611-99-3493 O-ring, EPDM 9611-99-2671 9611-99-2671 9611-99-2671...
  • Page 75 Parts List Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Axial Installation Tool Effective 05/04/2012...
  • Page 76 Parts List Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Axial Installation Tool 2½" 3" 4" 6" 9613-0505-02 9614-0792-01 9613-0505-06 9613-0505-10 Pos. Qty. Denomination 2½" and 3" 4" 6" Lower Part Piston Upper part O-ring, NBR 9611-99-3703 9611-99-3349 9611-99-5169...
  • Page 77 Parts List Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Radial Installation Tool TD 449-354 Effective 05/04/2012...
  • Page 78 Parts List Unique PMO Plus CP HT Valve Series Series Sanitary Mixproof Valve Instruction Manual Radial Installation Tool 2½" and 3" 4" 6" 9614-0788-01 9614-0788-02 9614-0788-03 Pos. Qty. Denomination 2½" and 3" 4" 6" Piston Lower Part Upper Part Bushing Guide Guide Ring 9613-0084-22...
  • Page 79 Alfa Laval 9560 - 58th Place, Suite 300 Kenosha, WI 53144 Tel: 262-605-2600 Fax: 262-605-2667 www.alfalaval.us The information herein is correct at the time of issue, but may be subject to change without prior notice. © 2012 Alfa Laval Inc.
