Summary of Contents for Brandt TG528BC1
- Page 1 99637181_GB_B.qxd 12/05/05 11:15 Page 1 Gas hob operating guide...
-
Page 2: Table Of Contents
99637181_GB_B.qxd 12/05/05 11:15 Page 2 Contents Using your hob in complete safety What your hob looks like? Installing your hob in all simplicity Fitting recommendations Electrical connections Gas connections Changing the type of gas supply for CHINA 10-11 Using your hob in all simplicity How to use your gas burners? Which pans are best adapted for use on the gas burner How to look after your hob? - Page 3 Our design staff have produced a new generation of kitchen equipment, to make everyday cooking a pleasure. You will find that the clean lines and modern look of your Brandt hob blends in perfectly with your kitchen décor. It is easy to use and performs to a high standard.
-
Page 4: Using Your Hob In Complete Safety
99637181_GB_B.qxd 12/05/05 11:15 Page 4 our hob in complete safety sing your hob in complete safety We have designed your hob for prolonged use of this appliance may private domestic use. require additional ventilation, (for example by opening the window), or With a view to the constant more effective ventilation (for improvement of our products, we... -
Page 5: What Your Hob Looks Like
99637181_GB_B.qxd 12/05/05 11:15 Page 5 hat your hob looks like? Semi-fast burner 1,5 kW * Extra-fast burner 3,1 kW * ( * Powers in Hong Kong gas) Installing your hob in all simplicity itting recommendations Width Depth Height 26,5 cm 48 cm Depending on the unit Standard cutout... - Page 6 99637181_GB_B.qxd 12/05/05 11:15 Page 6 Installing your hob in all simplicity itting recommendations (cont'd) The hob must be built into the work- top of a support cupboard. This work- top must be at least 3 cm thick and heat-resistant or else coated with a heat resistant material.
- Page 7 99637181_GB_B.qxd 12/05/05 11:15 Page 7 Installing your hob in all simplicity itting recommendations (cont'd) - Place the hob in position in the cutout Fixing Worktop lugs on the worktop, pulling it forward as far as possible. - Put the burners, caps and pan grates back in position.
-
Page 8: Electrical Connections
99637181_GB_B.qxd 12/05/05 11:15 Page 8 Installing your hob in all simplicity lectrical connections Your hob is delivered with a three- ROSS SECTION OF THE CABLE TO USE conductor (phase + ground + neutral) H05VVF- T105 or H05V2V2F - T90 220-240 V~- 50 Hz 1mm²... - Page 9 99637181_GB_B.qxd 12/05/05 11:15 Page 9 Installing your hob in all simplicity onnecting the gas supply Preliminary remarks If the hob is installed above an oven or if the proximity of other heat generating ele- The gas supply must be connected in ments threatens to cause the connection line with current regulations in the to heat up, it is vital that the connection be...
-
Page 10: Changing The Type Of Gas Supply For China
99637181_GB_B.qxd 12/05/05 11:16 Page 10 Installing your hob in all simplicity hanging the type of gas supply for CHINA The changing from Hong Kong towngas to natural gas G20/20mbar for CHINA must be realised by a qualified installer. He will find the injectors and the spanner available from the manufacturer or its After Sales Service. - Page 11 99637181_GB_B.qxd 12/05/05 11:16 Page 11 Installing your hob in all simplicity hanging the type of gas supply for CHINA (cont’d) The changing from Hong Kong towngas to natural gas G20/20mbar for CHINA must be realised by a qualified installer. He will find the injectors and the spanner available from the manufacturer or its After Sales Service.
-
Page 12: Using Your Hob In All Simplicity
99637181_GB_B.qxd 12/05/05 11:16 Page 12 Using your hob in all simplicity ow to use your gas burners? • To ignite a burner, press down and Lighting a hob F ITTED WITH A SAFETY turn the knob anti-clockwise until it DEVICE is pointing to the maximum position •... - Page 13 99637181_GB_B.qxd 12/05/05 11:16 Page 13 Using your hob in all simplicity hich pans are best adapted for use on the gas burner ? • Recommended pan sizes: Extra burner Small burner Extra-fast auxiliary 18 to 28 cm 12 to 16 cm Adjust the flames so that they do not lick up the side of your pan.
-
Page 14: How To Look After Your Hob
99637181_GB_B.qxd 12/05/05 11:16 Page 14 How to look after your hob? Keeping your hob in good condition is easy if you clean it before it is completely cold. Even so, never clean it when it is in use. Put all the electric and gas control knobs at zero. -
Page 15: Minor Troubleshooting
99637181_GB_B.qxd 12/05/05 11:16 Page 15 Minor troubleshooting You have doubts about whether your hob is working correctly. This does not necessarily mean there is a breakdown. Nevertheless, check the following points IF YOU REALIZE THAT WHAT SHOULD YOU DO? Lighting the burners: - Check the electrical connections on the hob. -
Page 16: Gas-Cooking Guide
This information appears on the manufacturer’s nameplate at- tached to your equipment. Brandt Appliances - société par actions simplifiée au capital de 10.000.000 euros RCS Nanterre 440 302 347. Réf. appareil : TG 528* 9963-7181 - 05/05...
