BUILT IN GAS HOB
USER MANUAL
INSTALLATION INSTRUCTION
TG2232BEL
TG2232BEP
To avoid the risk of accidents or damage to the appliance.
It is essential to read these instructions before
it is installed or used for the first time.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TG2232BEL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Brandt TG2232BEL

Summary of Contents for Brandt TG2232BEL

  • Page 1 BUILT IN GAS HOB USER MANUAL INSTALLATION INSTRUCTION TG2232BEL TG2232BEP To avoid the risk of accidents or damage to the appliance. It is essential to read these instructions before it is installed or used for the first time.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS • SAFETY: READ THIS FIRST! • FROM THE MANUFACTURER • COMPONENT INFORMATION • DESCRIPTION OF APPLIANCES • MAINTAINING YOUR COOKTOP • PRACTICAL ADVISE • EASE OF USE 5 - 6 • INSTALLATION REQUIREMENT 6 - 8 • INSTALLATION PROCEDURE 8 - 10 •...

  • Page 3: Safety: Read This First

    • To avoid a hazard, contact only the Brandt After Sales department, its service agent to avoid mishandling. • Always use authentic Replacement Parts. • BRANDT is not liable for damages in case of failure to adopt proper safety measures. • Ensure the location in which this appliance is installed is well ventilated.

  • Page 4: Component Information

    C. Support Grids for Cookware D. Control Knobs for Gas Burners E. Ignitor for Gas Burners F. Flame Failure Device TG2232BEL(LPG) TG2232BEP (TOWN GAS) DESCRIPTION OF APPLIANCES • Two or three burners with a stainless steel base plates are available on built-in gas hob ranges for LPG or Town Gas.

  • Page 5: Maintaining Your Cooktop

    • The appliance's ignition system was powered by transformer 220V-240V. • The differences between the models are described in detail below: (Table 1) MAINTAINING YOUR COOKTOP Before performing maintenance or cleaning on a gas appliance, disconnect it from and 220-240Vac electricity supply. th e gas To prolong the life of the cooktop, it is essential that it be cleaned frequently and thoroughly, keeping in mind the...

  • Page 6: Practical Advise

    PRACTICAL ADVISE For optimal performance, observe these guidelines: • Use the correct cookware for each burner (refer to table below) to prevent the flame from reaching the pot or pan's sides. • Always use flat-bottomed cookware and keep the lid on. •...

  • Page 7: Installation Requirement

    Symbol Description Do not place anything, e.g., flame tamer, asbestos mat, between pan and pan support as serious damage to the Symbol 1 appliance may result. Do not remove the pan support and enclose the burner Symbol 2 with a wok stand as this will concentrate and deflect the heat onto gas hob.
  • Page 8 In a chimney or flue with multiple branches Directly towards the exterior • The space must also accommodate the airflow required for proper combustion. The combustion air flow rate cannot be less than 2 m3/h per kW of installed capacity. The supply of said air can be accomplished by direct influx from the exterior through a duct with an inner cross section of at least 100 cm²...

  • Page 9: Installation Procedure

    • Extensive and prolonged use of the appliance may require supplementary ventilation, such as opening a window or increasing the air intake system's power (if present) • Liquefied petroleum gases (LPG) are heavier than air and as a result, settle downwards.
  • Page 10 • To include distance to back wall - greater than 80mm; To include distance to left wall and right wall - greater than 100mm. (Refer to Fig. E) 80mm (mini) 100mm(mini) 100mm(mini) (Fig. E)
  • Page 11 Clamps are provided to secure the cooktop to countertops between 20mm - 60mm thick. To securely fasten the cooktop, it is recommended that all clamps be utilized. TG2232BEL / TG2232BEP Installation above Ovens If the cooktop is installed above a built-in oven, an insulating wood panel must be installed.

  • Page 12: Gas Connections

    This compartment's opening must facilitate the insertion and removal of the cylinder. The opening and interior dimensions of the compartment must be at least large enough to accommodate the most used cylinders (with regulator installed) in the country. The total area of the opening in the upper portion of the compartment must be at least 1/100 of the floor area.
  • Page 13 LP Gas: Installation Instructions for Fixing Gas Cooker Elbow Joint The gasket depicted above is to prevent gas leakage. After installation, turn on the gas supply and use soap solution (never use naked flame) to check for gas leakage. Sharp edges are not allowed to contact the flexible tube. There shall be no internal connection between the cylinder compartment and the various parts of the appliance containing burners.

  • Page 14: Electrical Connection

    Electrical connection...

  • Page 15: Gas Conversion

    • Take precautions on the operations and adjustments to be carried out when converting from one gas hob to another. • All work must be carried out by a Brandt authorized technician. • Before beginning, disconnect the gas and electrical supply to the appliance.

  • Page 16: Troubleshooting

    Brandt Customer Service Centre, and provide the following information: • The nature of the issue. • The model number as displayed on the rating label Never employ technicians who are not authorized by Brandt or its service agent and refuse to accept non-original replacement parts.
