Output impedance:
Output level:
Physical Configuration
Dimensions (h × w × d):
Weight:
Operating Requirements
Operating voltage range:
Rated Power:
Power requirements:
Operating conditions:
PLCI1 Instrument Interface
Analog Inputs
Number of input channels:
Configuration:
Amplification ranges:
Maximum input over-voltage: ± 13 V
Input impedance:
Input Coupling:
Non-linearity (max):
37
1 KΩ
4.5 V
27.5 mm x 68 mm x 88 mm (1.1" x 2.7" x 3.5")
0.1 kg (0 lb 4 oz)
5 - 15 V
15 W
Front-end dependent (Refer Figure 5 - 8)
5–35 °C, 0–90% humidity (non-condensing)
4
Single-ended
Range
± 10 V
± 5 V
± 2 V
± 1 V
± 500 mV
± 200 mV
± 50 mV
± 20 mV
1 M
DC
0.2 %
Resolution
313 µV
156 µV
62 µV
31 µV
15 µV
6 µV
1.5 µV
625 nV
