- Page 1 Assembly Instructions Caution: You must read this before you proceed Please look in the insert carton box for hardware packs Chair Page 1 OF 7 Noble House Home Furnishings LLC...
- Page 2 Seat Panel Short Leg Long Right Leg Long Left Leg Seat Cushion Hardware Description Label Picture Bolt (M6x 40 mm Bolt (M6x 60 mm Spring Washer (6.5/11x2mm) Washer (6.5/16x2mm) Allen Key Noble House Home Furnishings LLC Page 2 OF 7...
- Page 3 This Chair has multiple parts and may require up to 30 minutes to assemble. To give you an overview of the Chair parts, the above picture is to help you put the various parts into perspective. Please read through the instructions below to familiarise yourself with the parts and steps before assembly.
- Page 4 Attach Long Right Leg(D) to Backrest Panel(A) using Bolts(①) with Allen Key(⑤). Do not fully tighten the Bolts. Repeat the same process with the remaining Long Left Leg(E). Noble House Home Furnishings LLC Noble House Home Furnishings LLC Page 3 OF 7...
- Page 5 Bolts(②), Spring Washers(③), and Washers(④) with Allen Key(⑤). Do not fully tighten the Bolts. Step 4 Attach Short Legs (C) to Seat Panel(B) using Bolts(②), Spring Washers(③), and Washer(④) with Allen Key(⑤). Do not fully tighten the Bolts. Noble House Home Furnishings LLC Page 4 OF 7...
- Page 6 Do not tighten any Bolt fully and then move on towards the next one. If there are still wobbles, loosen the Bolts and excute the same above process. If the Chair is not Stable it could lead to damage to the product. Step 5 Put Seat Cushion(F) onto the Chair.
- Page 7 Not for commercial use. For residential use only . Stains may be removed with mild soap solution and damp cloth. Dust and pick-up spills using a clean, non-colored, lint-free cloth . Noble House Home Furnishings LLC Page 6 OF 7...
