i-team i-gum User Manual

Portable gas chewing gum removal system
Hide thumbs Also See for i-gum:
Table of Contents

Advertisement

Quick Links

Download this manual
i-gum
Portable gas chewing gum removal system
User manual
i-team Professional b.v.
Hoppenkuil 27b, 5626 DD Eindhoven, The Netherlands
T +31402662400
E hello@i-teamglobal.com
I www.i-teamglobal.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the i-gum and is the answer not in the manual?

Questions and answers

Related Manuals for i-team i-gum

Summary of Contents for i-team i-gum

  • Page 1  i-gum Portable gas chewing gum removal system User manual i-team Professional b.v. Hoppenkuil 27b, 5626 DD Eindhoven, The Netherlands T +31402662400 E hello@i-teamglobal.com I www.i-teamglobal.com...
  • Page 2 Original user manual, written in the English Language Future Cleaning Technologies B.V. Hoppenkuil 27b, 5626 DD Eindhoven, The Netherlands T +31402662400 E hello@i-teamglobal.com I www.i-teamglobal.com Model: I-GUM GAS VERSION Date: 08/07/2019 Product code: IGM.I-V.1100C/1 Version: v.01...

  • Page 3: Preface

    Purpose of the user manual ® The purpose of the user manual is to provide the user with information during the life of the i-gum ® in such a way that the i-gum is used correctly, efficiently and safely, even in the event of reasonably foreseeable misuse.

  • Page 4: Reading Guide

    Reading guide The following symbols and terms are used throughout this manual to alert the reader to safety issues and important information: Symbol Term Explanation WARNING Indicates a hazardous situation which, if the safety instructions are not followed, can lead to injuries of the operator or bystanders, light and/or moderate damage to the product or the environment.

  • Page 5: Table Of Contents

    .................................... 1 Preface ..................................3 Purpose of the user manual ............................ 3 Target audience ..............................3  Operators of the i-gum ............................3 Reading guide ................................4 Introduction ..............................7 Intended use of the product ........................7 Non-intended use of the product ......................8 Lifespan ..............................
  • Page 6 Before you start ........................... 22 6.1.1 Charge the battery .......................... 22 6.1.2 Insert the gas cartridges ........................23 6.1.3 Fill the gum remover solution tank ....................24 6.1.4 Cleaning fluid low level indication ....................24 Dry start ............................... 24 Trolley operation ..........................25 6.3.1 Adjust pump speed .........................

  • Page 7: Introduction

    ® The i-gum G is the gas-operated version. The butane propane mix gas cartridges used in the i-gum G are fitted with a standard type EN 417 threaded, self-sealing safety valve. Please refer to the instructions on the bottle for correct procedure. The built-in battery operates amongst other things the gas ignition and the operation display.

  • Page 8: Non-Intended Use Of The Product

    The solution can cause floors to become slippery; it is advised to mark the floor of the job site to ® warn people. (Please note: the wet floor sign is not part of the i-gum system delivery). ® In order to use the i-gum on hard (outdoor) as well as soft (indoor) surfaces, both steel and nylon brushes are provided.

  • Page 9: Specifications

    1.5 Specifications Figure 2 Product Size (body unit): 347*330*500 mm Lance Size: 60*1100 mm Weight (including 2 gas cartridges): 10.5 kg Lance Weight: 1.6 kg Broom Extended Length: 1.3 M Li-on Battery: 14.8V 6.6Ah Gas Cartridge Drawer Capacity: 2 Gas Cartridges Operation Time of Gas Cartridges: About 4 hours/ Cartridge;...

  • Page 10: Warranty

    ® The i-gum should only be operated with the materials supplied. Using alternative supplies may ® cause damage to the i-gum and may cause a risk to the operator. The use of alternative supplies voids manufacturer's warranty. 1.7 Identification ®...

  • Page 11: Description

    2 Description ® The compact lightweight i-gum consists of two main parts: 1. The body that contains the cleaning solution and the gas cartridges and that can be carried as a backpack. 2. The steam lance with the integrated gas heating installation to deliver the heated gum cleaner solution exactly on the gum patch.
  • Page 12 Wheels and a handle to use the i-gum as a trolley. ® The back plate and harness to use the i-gum as a backpack. A battery charger and a storage bag for the battery charger. A brush storage tube to store spare brushes.

  • Page 13: Safety

    (fig 5, pos 1) should not be touched. The temperature stays well below 60°C. CAUTION ® Always keep the body of the i-gum in an upright position when gum remover solution or batteries are inserted. 3.1.1 Trolley operation CAUTION When using as a trolley remove the harness as the machine can trip over loose straps.

  • Page 14: Backpack Operation

    When using as a backpack fit the machine to the operator and adjust straps before inserting the batteries or filling the tank with the gum remover solution. Proceed only when the operator is ® comfortable using the backpack, else use the i-gum as a trolley. 3.1.3 Brush condition Make sure to check the condition of the brush before use, change the brush only when the machine is turned off and the steam lance is cooled.

  • Page 15: Risks During Operation

    DO NOT operate barefoot, wear closed shoes while operating the machine. 3.2.2 The gum remover solution WARNING ® The water based i-gum gum remover solution does not provide significant hazards, however, please be aware of these general safety rules: •...

  • Page 16: Transport And Storage

    Store the steam lance in its holder during transport and storage. • The gas cartridges can remain in the machine during storage and transport. • ® ® Store the i-gum in an upright position, under normal storage conditions. Don't expose the i-gum to open fire.

  • Page 17: Assembly And Installation

    ® The i-gum is packed in 1 box, containing: ® 1. The i-gum itself including a starter package of brushes, gas cartridges and cleaning fluid. 2. The battery charger and the storage bag for the battery charger. Figure 6 Legend ®...

  • Page 18: Assembly

    5.2 Assembly 1. Attach the drip tray (Figure 8, pos 2) to the body. 2. Click the lance (Figure 8, pos 1) into the holder (Figure 8, pos 3), with the metal plate facing the main body. 3. Screw the broom on the broom handle. 4.

  • Page 19: Trolley Or Backpack Operation

    5.3 Trolley or backpack operation 5.3.1 Trolley operation ® When you use the i-gum as a trolley it is advised to remove the harness so loose straps cannot be caught between the wheels. To remove the harness: 1. Remove padding (Figure 9, pos 1) that is attached to the back plate with Velcro.
  • Page 20 2. Unscrew the four screws (Figure 10, pos 1) using a Philips screwdriver. 3. Remove the back plate (Figure 10, pos 2). Figure 9...

  • Page 21: Backpack Operation

    4. Put the four screws back in place, as these also hold the trolley handle (Figure 11, pos 1). TIP: Keep all removed parts safely stored for future use. Figure 10 5.3.2 Backpack operation ® When you use the i-gum as a backpack no further assembly is required.

  • Page 22: Operation

    Figure 11 WARNING Don't charge the built-in battery while the charger is in the storage bag. This might overheat the charger. Make sure the i-gum® is turned off before you charge the built-in battery.

  • Page 23: Insert The Gas Cartridges

    4) at the same time. TIP: ® It is not necessary to use two gas cartridges at the same time. The i-gum can operate on a single cartridge for 4 hours. It can operate on 2 cartridges for 8 hours.

  • Page 24: Fill The Gum Remover Solution Tank

    Please proceed carefully, safety glasses are recommended. 1. Remove the yellow stopper (Figure 13, pos 1). ® 2. Pour in the i-gum gum remover solution (Figure 13, pos 3) while checking the fluid indicator (Figure 13, pos 2) on the side.

  • Page 25: Trolley Operation

    Figure 14 6.3 Trolley operation Proceed to paragraph 6.4 when you are using the harness. ® 1. Walk to the job site with the i-gum and a wet floor marker. 2. Mark the job site. ® 3. Turn on the i-gum using the main power switch on the bottom (Figure 17, pos 2) left of the body.
  • Page 26 The pump starts. 17. Wait for 20 seconds until steam comes out of the lance. The i-gum® is ready for use. 18. Check the H/M/L indicator light (Figure 17, pos 4). The pump will default operate at low speed (see 6.3.1).
  • Page 27 Figure 16...

  • Page 28: Adjust Pump Speed

    6.3.1 Adjust pump speed The pump will default operate at low speed. You can change it to medium or high speed for more steam via the H/M/L multi function button. 1. Press the H/M/L multi function button (Figure 17, pos 2). 2.
  • Page 29 ® (Figure 19, pos 1); • close the gas cartridge holder (Figure 19, pos 4) at the same time. ® 6. Turn off the i-gum via the main power switch Figure 19 (Figure 18, pos 3).

  • Page 30: Backpack Operation

    6.4 Backpack operation ® 1. Turn on the i-gum using the main power switch on the bottom (Figure 22, pos 2) left of the body. 2. Check the battery power indicator (Figure 22, pos 1). (See 6.1.1 for charging the built-in battery.)
  • Page 31 8. Put on the backpack. 9. Adjust waistband (Figure 21, pos 2) and straps (Figure 21, pos 1) for comfort. ® 10. Walk to the job site with the i-gum and a wet floor marker. 11. Mark the job site.
  • Page 32 19. Press the IGNITION button (Figure 22, pos 6) for 2 seconds. You can hear the gas heater is burning. The pump starts. 20. Wait for 20 seconds until steam comes out of the lance. The i-gum® is ready for use. 21. Check the H/M/L multi function indicator light (Figure 22, pos 5). The pump will default operate at low speed (see 6.3.1).

  • Page 33: Adjust Pump Speed

    6.4.1 Adjust pump speed See paragraph 6.3.1. 6.4.2 After operation 1. Turn off the SELF-LOCK button (Figure 24, pos 2. Turn off the pump via the ON/OFF button (Figure 24, pos 1). The H/M/L indicator light goes out. The pump goes out after 3 minutes, as the ventilator needs to be cooled before storage.
  • Page 34 6. Turn off the SELF-LOCK button (Figure 24, pos 4). ® 7. Turn off the i-gum via the ON/OFF switch on the handle control (Figure 24, pos 1). 8. Remove the backpack and close the strap (Figure 24, pos 2) to hold the waistband together.

  • Page 35: Cleaning And Storage

    6.5.1 Drain the machine ® 1. Put the i-gum on a table with the back side towards you. 2. Release the drainage tube (Figure 25, pos 2) via the clips (Figure 25, pos 1).

  • Page 36: Rinse The Machine

    3). Remove the drip tray and clean. Figure 28 ® After the rinse operation the machine is completely dry. Next time you use the i-gum please follow the Dry start procedure (see paragraph 6.2). 6.5.3 Remove the gas cartridges The gas cartridges can remain in the machine during storage and transport.

  • Page 37: Storage

    (Figure 29, pos 4) at the same time. Remove the empty gas cartridges for separate disposal. If you want to insert new gas cartridges see 6.1.2. 6.5.4 Storage ® Store the i-gum in an upright position, under normal storage conditions.

  • Page 38: Maintenance

    The wires on the steel brush are sharp and bended after use, make sure you do not cut yourself and grab the brush by the top. ® 1. Make sure the i-gum is turned off and completely cooled down. 2. Unscrew the old brush by a small turn clockwise (right) and pull (Figure 31).

  • Page 39: Recommended Additional Cleaning

    7.2 Recommended additional cleaning ® It is recommended once per month to rinse the i-gum with water. 7.2.1 Clean with water 1. Pour some water in the fluid tank (see 6.1.3). 2. Make sure the drip tray (Figure 33, pos 2) is attached to the machine.

  • Page 40: Drain The Machine

    7.2.2 Drain the machine ® 1. Put the i-gum on a table with the back side towards you. 2. Release the drainage tube (Figure 34, pos 2) via the clips (Figure 34, pos 1). 3. Put the end of the drainage tube in a bucket or empty bottle.

  • Page 41: Rinse The Machine

    10. Turn off the main power switch. 11. Clean the drip tray (Figure 37, pos 2). Figure 37 ® After the rinse operation the machine Is completely dry. Next time you use the i-gum please follow the Dry start procedure (see paragraph 6.2).

  • Page 42: Replace The Fuse

    7.2.4 Replace the fuse When the i-gum® has no power at all, the fuse might be blown. WARNING Make sure the i-gum® is switched off before you replace the fuse. Replace the fuse: 1. Make sure the i-gum® is switched off.

  • Page 43: Recommended Service Time

    7.3 Recommended service time When you do not have a service agreement check the timer on the bottom left side of the machine on a regular basis. It is recommended to schedule a full service by one of our service partners every 1,000 hours.

  • Page 44: Trouble Shooting

    8 Trouble shooting Problem Cause Solution No power Main power switch of Turn on power switch. Empty battery Charge battery. Fuse has blown Replace fuse. SELF-LOCK button is turned off Turn on the SELF-LOCK button. No steam No gas cartridge(s) Insert gas cartridge(s).

  • Page 45: Decommissioning And Disposal

    Decommissioning and disposal ATTENTION ® It is the responsibility of the i-gum owner to dispose of the product responsibly. ® At the end-of-life the i-gum still contains valuable resources and needs to be disposed of according to your local laws and regulations regarding recycling of electrical equipment.

  • Page 46: Attachments

    10 Attachments 10.1 CE Certificate...

  • Page 47: Safety Data Sheet Gum Remover Solution

    10.2 Safety data sheet gum remover solution Information on the i-GUM chewing gum remover solution can be found on the SAFETY DATA SHEET i-GUM, SDS number 23393 - revision date 01/05/2015. This safety data sheet conforms to Regulation (EC) No. 1272/2008 on Classification, Labelling and Packaging of Substances and Mixtures.
