Summary of Contents for i-team i-bin hygiene15
- Page 1 Revolutionary ladies sanitary container User manual i-team hygiene and services B.V. Hoppenkuil 27b, 5626 DD Eindhoven, The Netherlands Telephone: +31402662400 Email: hello@i-teamhygiene.com Internet: www.i-bin.com...
- Page 2 Original user manual, written in the English Language Email: hello@i-teamhygiene.com i-team hygiene and services B.V. Internet: www.i-bin.com Hoppenkuil 27b, 5626 DD Eindhoven, The Netherlands Telephone: +31402662400 Model: i-bin hygiene Date: Sept/2023 Product code: IHBN.FCT.002xx (Basic), Version: v1.0 Microban is a registered trademark of Microban Products Company.
-
Page 3: Preface
Preface Thank you for purchasing the i-bin hygiene . Please read the important safety information and user instructions in this manual carefully before using the bin for the first time. This manual contains important information. Please keep it for future reference. Purpose of the service manual The purpose of the user manual is to provide the user with information in such a way that during its life, the i-bin hygiene is used correctly, efficiently and safely, even in the event of... -
Page 4: Reading Guide
Reading guide The following symbols and terms are used throughout this manual to alert the reader to safety issues and important information: Symbol Term Explanation WARNING Indicates a hazardous situation which, if the safety instructions are not followed, can lead to injuries of the operator or bystanders and light or moderate damage to the product or the environment. -
Page 5: Table Of Contents
Content Preface ......................................3 Purpose of the service manual ..............................3 Target audience ..................................... 3 Operators of the i-bin hygiene ..............................3 Reading guide ....................................4 Introduction ................................... 7 Intended use of the product ..........................7 Non-intended use of the product ........................7 Lifespan .................................. - Page 6 Install the cassette ..............................20 When to empty the bin? ............................. 22 Install the drawstring bag ..........................23 (Re)placing an i-scent cup..........................24 Maintenance ..................................25 Cleaning ..................................25 Replacing the cassette ............................25 Replacing the battery ............................25 Troubleshooting ................................26 Decommissioning and disposal ..........................
-
Page 7: Introduction
1 Introduction The i-bin hygiene is a safe, user-friendly machine. This manual helps you to get started and explains the operation and maintenance procedure. You will be pleasantly surprised by the fast and effective use of the battery operated i-bin hygiene This manual is intended for those use the i-bin hygiene and/or perform daily maintenance. -
Page 8: Lifespan
To ensure proper and safe operation throughout the life of the i-bin hygiene , the product must be checked by an authorized i-team partner every 3 months. 1.4 Modifications It is not permitted to make modifications to the design of the i-bin hygiene without consultation and permission from the manufacturer. -
Page 9: Specifications
1.5 Specifications Figure 2 Product identification: IHBN.FCT.002xx (Basic) Product name: i-bin hygiene Model: Basic version Product size: 20 x 23.5 x 65,5 cm Weight (including batteries): 4 kg Capacity 15 L Li-ion battery: DC (11.1 V, 4400 mAh, 353 Wh) Battery capacity: 1 battery Charging current:... -
Page 10: Description
2 Description The compact i-bin hygiene consists of three main parts: • The upper part that contains the foil lid, the working status light and the Indicator light. • The stand that contains the IR-sensors, the Reset button, the Main switch, the Locking mechanism and the Detachable base. -
Page 11: Safety
3 Safety Safety comes first. Therefore, please take your time to read and understand these safety instructions. kindly follow the instructions correctly to avoid potential danger or injury. Improper use can cause harm or void the manufacturer’s warranty. 3.1 General safety instructions 3.1.1 Indoor use This product is intended for indoor use only. -
Page 12: Risks During Operation
3.2 Risks during operation The i-bin hygiene is designed to close and seal bio friendly storage bags. The sealed bags will drop and collect in a container at the bottom part of the machine. CAUTION The sealing mechanism of the i-bin hygiene can get very hot. -
Page 13: Transport And Storage
4 Transport and storage 4.1 General CAUTION Always store the i-bin hygiene in a dry environment. -
Page 14: Assembly And Installation
5 Assembly and installation The i-bin hygiene does not require much assembly. 5.1 Unboxing The i-bin hygiene is packed in a single box. Ensure that no items are missing and compare contents with the list in Figure 4. lf one of the items listed is missing, contact your i-bin hygiene dealer. -
Page 15: Assembly
Manual i-scent (optional) 3M Adhesive sticker Bag holder Figure 4 5.2 Assembly 5.2.1 Battery Connect the charger to the battery. For first use, charge the battery for approximately 5 hrs. Figure 5 5.2.2 Install the battery Press the metal handle on either side of the i-bin hygiene down. - Page 16 Slide the bin out from the stand. Figure 7 Open the battery compartment with the key and insert the battery in the slot. Figure 8 Press the ON/OFF switch to turn on the machine. Figure 9...
-
Page 17: In Case Of Wall Mount
Close the battery compartment and lock with the key. Click the bin back into the stand. The magnet, fitted in the middle of the stand, will hold the bin in place. Figure 10 CAUTION Please be aware of the integrated magnet fitted on the stand of the i-bin hygiene 5.3 In case of wall mount CAUTION... - Page 18 Check if the wall where the i-bin hygiene is to be placed, is smooth. Place the template (pos 2, Figure 12) with the bottom part on the floor. Check with a water level (pos 1, Figure 12) if the template is exactly horizontal, Figure 12 Mark the four holes (Pos 1, Figure 13) on the...
-
Page 19: In Case Of Wall Mount With Stickers
5.4 In case of wall mount with stickers In case drilling in the wall is not possible, the i-bin hygiene can also be attached to the wall using the provided 3M stickers. ATTENTION Prior to fixing the i-bin to the wall, mark with a thin pencil and a spirit level a vertical line on the wall. -
Page 20: Operation
6 Operation Check if the i-bin hygiene is assembled and installed properly, see paragraph 5.2 and 5.3 or 5.4. 6.1 Install the cassette Switch off the machine and remove the bin as described in paragraph 5.2.2. Figure 17 Lift the top foil lid and remove the empty cassette (if present). - Page 21 Two sets of splined wheels are fitted diagonally on either side of the opening. Place the foil between the wheels and press down with the provided Foil loading tool. Figure 20 Switch on the i-bin. The two wheels will automatically pull down the foil. The cassette is now installed.
-
Page 22: When To Empty The Bin
The backside of the foil loading tool includes a small knob. Press this knob into the small hole in the left side of the stand. Hold it for about 3 s. After 3 s the red indication light will switch off and a small beep can be heard. -
Page 23: Install The Drawstring Bag
CAUTION Always empty the bin when it is removed from the machine. As soon as the bin is removed, the ‘bags-counter’ will be reset to zero. Refraining from emptying the bin will lead to miscounting. This can lead to overfilling of the bin. -
Page 24: Re)Placing An I-Scent Cup
Push the bag down inside the container. Figure 27 6.4 (Re)placing an i-scent cup To (re)place a new i-scent cup: Use a pointed object and remove the cupholder. Remove the old i-scent cup from the cupholder (if applicable). Pull off the plastic foil from the new i-scent cup. -
Page 25: Maintenance
7 Maintenance CAUTION Remove the battery before executing any cleaning or maintenance task. 7.1 Cleaning To clean the i-bin hygiene , wipe the plastic bin with a damp cloth. CAUTION Don’t use chemicals for cleaning the i-bin hygiene 7.2 Replacing the cassette For replacing the cassette follow the steps as described in paragraph 6.1. -
Page 26: Troubleshooting
8 Troubleshooting Problem Cause Solution Power indicator Only 15% charge remaining Charge battery light flashes Power indicator Only 2% charge remaining light on Foil low indicator Only foil for 5 bags Change the light flashes remaining. cassette Foil low indicator Only foil for 2 bags light on remaining. -
Page 27: Decommissioning And Disposal
2. Remove all loose components like foil cassette. 3. Dispose all items according to your local laws and regulations. i-team hygiene and services B.V. Hoppenkuil 27b, 5626 DD Eindhoven, The Netherlands Telephone: +31402662400 Email: hello@i-teamhygiene.com... -
Page 28: Attachments
10Attachments 10.1 CE Certificate...
