Groeneveld MultiLine SFi 110 Quick Installation Manual page 2

MultiLine SF
SFi Electrical Information
Voltage: 110/220VAC (50/60Hz)
Power Rating: 4VA
Fuse Rating: 1A
IP Rating: IP66
Grease Compatibility
Lubricant Other commercially
Viscosity available lithium grease
Minimum Temperature
NLGI-2 14ºF (-10ºC)
NLGI-1 9ºF (-12.8ºC)
NLGI-0 2ºF (-16.7ºC)
NLGI-00 -8ºF (-16.7ºC)
NLGI-000 -29ºF (-33.9ºC)
SAE80/90 -40ºF (-40ºC)
Lubricants containing solid additives such as PTFE (Teflon), graphite,
molybdenum disulphide (MoS2) or bentone/bentonite (clay) based
greases can cause blockages in the system and should not be used.
www.timken.com/warnings
150 05-21 Order No. 11346 | Groeneveld-BEKA
i
Groeneveld
Green = Ground
Black = Negative (-0V)
White = Positive (+110V)
Minimum Working Temperature
Groeneveld GreenLube
for MultiLine
GreenLube Grease
N/A
GreenLube EP-1
GreenLube EP-0
N/A
N/A
N/A
WARNING
and Groeneveld are registered trademarks of The Timken Company or its affiliates. | © 2021 The Timken Company | Printed in U.S.A.
® ®
SFi Quick Installation Guide
®
Alternative Pump Elements & Output
Run Delay
Timer
Time Time
0 6 min 6 min
1 6 min 15 min
2 6 min 30 min
3 6 min 60 min
NOTE: Preset from factory at #3 timer setting. Red, green, yellow, grey, and black pump elements sold separately.
Spare Parts and Accessories
Part Number
MSF-P-R010 Red Pump Element – 0.010cc/stroke – (3 pack)
MSF-P-G015 Green Pump Element – 0.015cc/stroke – (3 pack)
MSF-P-Y025 Yellow Pump Element – 0.025cc/stroke – (3 pack)
MSF-P-B040 Blue Pump Element – 0.040cc/stroke – (3 pack)
MSF-P-G060 Grey Pump Element – 0.060cc/stroke – (3 pack)
MSF-P-B100 Black Pump Element – 0.100cc/stroke – (3 pack)
MSF-A-BP10 Blanking Plug (10 pack)
MSF-A-QF Quick Fill Coupler Assembly
MSF-T-4N50E 4mm OD Tubing – Unprimed – 50ft/roll
MSF-T-4N50G 4mm OD Tubing – Primed – Grease – 50ft/roll
MSF-T-4N50F 4mm OD Tubing – Primed – Food Grade Grease – 50ft/roll
F230229* GreenLube EP-0 Grease – 35lb Pail
F801299* GreenLube EP-1 Grease – 35lb Pail
* Available direct from Groeneveld-BEKA
(110/220VAC)
Pump Elements Output (cc/hour)
Cycle
Time P-R010 P-G015 P-Y025 P-B040
Red Green Yellow
12 min 0.050 0.075 0.125
21 min 0.029 0.044 0.073
36 min 0.017 0.025 0.042
66 min 0.009 0.014 0.023
Description
4700 Lyons Road, Dayton, OH 45342
Phone: 937-276-4507
Email: custserv-dayton@groeneveld-beka.com
www.groeneveld-beka.com/US
2
P-G060 P-B100
Blue Gray Black
0.200 0.300 0.500
0.116 0.174 0.290
0.067 0.100 0.167
0.036 0.055 0.091
| FAX: 937-276-4518
