Groeneveld MultiLine SFi 110 Quick Installation Manual

MultiLine SF
Connecting Lube Lines
1
Remove bulkhead plug
3
Insert lubrication line
into bulkhead fitting
5
Replace with
appropriate fitting
Note: Temporary bulkhead plugs prevent dust from
entering and reduce leakage during shipping or storage.
i
Groeneveld
2
Position lubrication line
from bearing fitting
4
Remove existing grease fitting
6
Route lube lines to appropriate
bearings/components
SFi Quick Installation Guide
®
Reducing Lube Points
1
Remove lube line
Adjusting Output
1
Remove lube line
3
Replace with alternative output
pump element, see back
2
Remove pump element
2
Remove blue pump element
4
Plug lube line into pump element
For quick selection and output
calculations, open the mobile
web app. MultiLineSF.com
1
(110/220VAC)
3
Replace with plug
Filling Pump
1
Pour lubricant in the top fill.
Oil & NLGI #000 greases ONLY.
2
With grease gun or pump,
fill at the zerk fitting.
NLGI #1 and #2 ONLY.
F801308
