Dancing Wings Hobby Tiger Moth Instruction Manual

Tiger Moth
(X10) INSTRUCTION MANUAL
Wingspan:400mm
Length:330mm
Pls take down the parts from the board by knife,and
assemble them as per the procedures as below,we
suggest you to shape with 502 glue,and firm with
white latex.
A2
A1
1.Fusalage Installation
A4 F-6
F-7
F-6
F-1
F-5
F-8
F-1
F-9
F-16 F-11
F-15 F-11
F-11
F-14
F-12
F-2
Material:
1. Basswood
2. Balsawood
3. Paulownia
4. Fiberglass and others
Tools Needed
A3
A7
A4
A6
A5
F-18
F-19
F-10
F-4
Stick F-5-1 on the
F-5-1 x3
nose,and sanding
the nose shape
F-13
according to the
real airplane.
A3
A7
A7
2.Landing Gear Installation
A5
A6
A5
A6
F-20
Paint with black paint
F-17
F-26
F-3
3.Wing Installation
Down Wing
Down W-4
Carbon rod
W-6
W-7
Up Wing
Insert carbon rod
A2
A2
F-21
W-6
Install the finished down wing and up wing on
A3 and A4.Connect the middle part between up
wing and down wing with A1.Lastly,adjust the
wing straightly before sticking the joints with
glue.
Heat-shrink tube fixing
W-1
W-2
Down W-5
W-1
W-2
Up W-4
Carbon rod
Up W-5
A1
F-25
F-24
