vita Huron Planter With Trellis Assembly Instructions

A S S E M B LY I N S T R U C T I O N S
Huron Planter With Trellis
Please read through before starting assembly.

Check Box for These Contents

In the event of missing or defective parts please call our customer service dept. at 1 800 282 9346 (Mon. to Fri. 8:00 AM to 5:00 PM EST).
1. Post Caps (4) - 10810
2. Trellis Top and Bottom Rails (2) - 11089
3. Trellis Left Post (1) - 11090
4. Trellis Horizontal Slats (4) - 11091
5. Trellis Vertical Slats (5) - 11092
6. Trellis Right Post (1) - 11093
7. Pre-Assembled Side Panels (2) - 11094
8. Pre-Assembled Front & Back Wall Panels with Posts Connected (2) - 11097
9. Planter Box Post Trims (4) - 10730-1
10. Floor - Left (1) - 11098
11. Floor - Middle (1) - 11099
12. Floor - Right (1) - 11100
13. Floor Supports (2) - 11101
14. 5/8" (1.6 cm) Self-Augering Stainless Steel Screws (12) - 20016

Tools You Will Need

• Cordless Drill

General Information

• Read Instructions through carefully before beginning assembly.
• When assembling components, place on a non-abrasive surface
(i.e. shipping box) to avoid scratching.
• We recommend an area approx 4'x 8' for (1.2 m x 2.4 m) unobstructed
assembling.
• You should not need to use excessive force when assembling
32.125 in
81.6 cm
48 in
122 cm
15.88 in
40.3 cm
7
8
14 9
Not to scale
13.88 in
35 cm
33 in
84 cm
36 in
91 cm
1
2
3
4
5
6
10 11
Ver2.2 10272020
www.wearevita.com
11.83 in
30 cm
15 in
38 cm
12 13
