Symbol Legend
Thefollowingsymbolsandmarkingsareusedinthedocument:

WARNING! Safety-related information
recommended to read and keep in every case!

ATTENTION! Useful information to perform a successful procedure;
it is recommended to read.

DIFFERENCE: Feature or function that is available with a specific
firmware/hardwareversionorproductvariant.
INFO:
A notice which may contain additional information. Procedure
can be successful without reading it.

DEFINITION: The short description of a feature or a function.
TIPSANDTRICKS:
Ideas which you may have not known yet but
can be useful.
Navigation Buttons
Go back to the previous page. If you clicked on a link previously,

you can go back to the source page by clicking the button.

Navigate to the Table of Contents.

Step back one page.

Step forward to the next page.
Document Information
This User's Manual applies to the following versions of the mentioned
software,firmwareandhardware:
which is highly
Lightware Device Controller (LDC) software
Lightware Device Updater V2 (LDU2) software
Applied firmware package
Hardware
Documentrevision:v3.1
Releasedate:25-06-2021
Editor:LaszloZsedenyi
Appliedfirmwarepackage:v1.5.0b3 | LDCsoftware:v2.5.9b2
HDMI-TPS-RX110AY series – User's Manual
Item Version
2.5.9b2
2.10.0b6
1.5.0b3
1.2
About Printing
Lightware Visual Engineering supports green technologies and
eco-friend mentality. Thus, this document is made for digital usage
primarily. If you need to print out few pages for any reason, follow the
recommendedprintingsettings:
▪ Pagesize:A4
▪ Outputsize:FittopageorMatchpagesize
▪ Orientation:Landscape

TIPSANDTRICKS: Thanks to the size of the original page, a border
around the content (grey on the second picture below) makes
possible to organize the pages better. After punching the printed
pages, they can be placed easily into a ring folder.
1 2
Hashtag (#) Keywords in the Document
This user's manual contains keywords with hashtag (#) to help you to
findtherelevantinformationasquickaspossible.
Theformatofthekeywordsisthefollowing:
#<keyword>
Theusageofthekeywords:usetheSearchfunction(Ctrl+F/Cmd+F)
of your PDF reader application, type the # (hashtag) character and the
wished keyword.
The #newspecialkeywordindicatesanewfeature/functionthathas
justappearedinthelatestfirmwareorsoftwareversion.
Example
#dhcp
This keyword is placed at the DHCP setting command in the LW3
Programmer's reference section.
See the list of all hashtag keywords of the document in the
KeywordList section, and it is highlighted with
contents of the document.
3
3
Hashtag
claret in the table of
