Audio signal interface
Hide thumbs Also See for QIF-2011:

Advertisement

Terminal
SH (beside R2
R2
H2
M2
Across V3 terminals
C2
SH (beside R3)
R3
H3
M3
C3
SH (beside R4)
R4
H4
Across V4 terminals
M4
C4
A1
A2
A3
A4
OP
OM
NP (two terminals ,
internal connection)
NM (two terminals,
internal connection))
AP
connect to normally open dry contact used to activate input 1.
Audio signal shield connection
External signal #2 audio return
External signal #2 audio positive. Connect H1 and R1 to external
signal source.
External signal #2 control input return
High voltage input for signal #3 (70VRMS maximum)
External signal #2 control input positive. M2 and C2 typically
connect to normally open dry contact used to activate input 2.
Audio signal shield connection
External signal #3 audio return
External signal #3 audio positive. Connect H3 and R3 to external
signal source.
External signal #3 control input return
External signal #3 control input positive. M3 and C3 typically
connect to normally open dry contact used to activate input 3.
Audio signal shield connection
External signal #4 audio return
External signal #4 audio positive. Connect H4 and R4 to external
signal source with highest priority.
High voltage input for signal #4 (70VRMS maximum)
External signal #4 control input return
External signal #4 control input positive. M4 and C4 typically
connect to normally open dry contact used to activate input 4.
Command for signal #1 zone selection ( Compatible with QIF-2000)
Command for signal #2 zone selection ( Compatible with QIF-2000)
Command for signal #3 zone selection ( Compatible with QIF-2000)
Command for signal #4 zone selection ( Compatible with QIF-2000)
Common command for zones selections when any of signals 1 to 4
are active. Compatible with QIF-5000 opto-isolated inputs. If used,
typically connects to QIF-5000 connector J4 screw 3 (Opto input 3).
Return for OP. If used, typically connects to QIF-5000 connector J4
screw 4 (Opto input 3).
Connect is parallel with either silenceable or non-silenceable inputs
of the QIF-5000 (J4 screws 7 or 5). Provides alarm status of the QX-
5000 system to the QIF-2011 interface.
Return for MP (QIF-5000 J4 screws 8 or 6 depending on control
signal used).
Connection for Push-to-Talk line from QMP-510X series remote
paging microphone consoles (QMP-510X terminal PTT IN +) .
Provides QX-5000 internal paging status to the QIF-2011 interface
Function
LT-6041 Rev 3
