Regin RU-DFO Quick Start Manual

RU-DFO is a room unit intended for use together
with Regio Maxi controllers.

Function

RU-DFO is a room unit from the Regio series with display
and fan button for controlling a three-speed fan (fan coil).
It should be connected to one of the Regio Maxi control-
lers RCP100F, RCP100FT, RCP200F or RCP200FT.
Regio
Regio is a wide series of controllers which handle heating
and cooling.
The controllers are divided into three different series,
Mini, Midi and Maxi. Mini are pre-programmed,
stand-alone controllers. The Midi controllers are pre-
programmed with communication. The Maxi group, to
which RU-DFO belongs, consists of freely programmable
controllers with communication.

Applications

The Regio controllers are suitable in buildings where you
want optimal comfort and low energy consumption, for
example offices, schools, shopping centres, airports, hotels
and hospitals etc.
HEAD OFFICE SWEDEN
Phone: +46 31 720 02 00
Web: www.regincontrols.com
E-Mail: info@regincontrols.com
RU-DFO
Room unit with display and fan button
for use with RCP
9 Simple installation
9 Built-in temperature sensor
9 Backlit display
9 Cable for connection between the room
unit and the RCP controller is available as
accessory

Sensor

The room unit has a built-in sensor.

Easy to install

The modular design with a separate bottom plate for
Wiring makes the whole Regio series easy to install and
commission. The bottom plate can be put into place be-
fore the electronics are installed. Mounting is directly on
the wall or on an electrical connection box.

Connection to RCP

The room unit is connected to the RCP-unit with an
RJ12-cable, max length 30 m. Regin has two cables as
accessories, RU-CBL3 (length 3 m) and RU-CBL10
(length 10 m).
RU-DFO
— 1 —
Revision 2019-05-27
