Models 8300 / 8500
T
O R S I O N
R
L
ESIDENTIAL AND
IGHT
S
L
TANDARD
IFT
W
INDLOAD
Q
S
G
UICK
TART
UIDE
DEFINITION OF LIGHT COMMERCIAL:
1. Door Heights less than or equal to 8'0" (< = 8'0") are considered
Residential Applications.
2. Door Heights greater than 8'0" (> 8'0") are considered Light
Commercial Applications.
PLEASE DO NOT RETURN THIS PRODUCT
TO THE STORE
If you need assistance, please call 1-866-
569-3799 (press Option 1) and follow the
prompts to contact a customer service
representative. They will be happy to handle
any questions that you may have.
©Copyright 2021
Wayne Dalton, a division of Overhead Door Corporation
C
OMMERCIAL
T a b l e O f C o n t e n t s
QUICK START GUIDE IMPORTANT NOTICES!
This Quick Start Guide is only meant to be used as an aid and
/ or introduction to garage door installation, and does not replace the
complete Installation Instructions and Owner's manual available on the
web at www.Wayne-Dalton.com. Wayne Dalton highly recommends
that you read and fully understand the Installation Instructions and
Owner's Manual before you attempt this installation.
To avoid possible injury, read and fully understand the enclosed
instructions carefully before installing and operating the garage door. Pay
close attention to all warnings and notes. After installation is complete,
fasten this manual near garage door for easy reference.
The complete Installation Instructions and Owner's Manual are available at no
charge from:
- Your local Wayne Dalton Sales Center, or
- Online at www.Wayne-Dalton.com, or
- By mailing to: Wayne Dalton, a division of Overhead Door Corporation, P.O. Box
67, Mt. Hope, OH., 44660
Part Number
352159
2
2
2
4
5
8
13
13
14
14
14
15
REV13_01/12/2021
