TILTING MECHANISM

For easy access to your boot, even if the bikes are mounted on the carrier, you
may use the tilting mechanism.
First you must push aside the safety lock of the tilting mechanism (1).
2
The bike carrier may never be used if the tilting mechanism is not
well secured.
1 1
By pushing the entire carrier up, the
tilting mechanism is locked again.
Make sure to always secure the handle
again with the safety lock!
38
With one hand, keep a firm grip
on the U-frame so that the carrier
cannot fall down in an
uncontrolled movement. With the
other hand, push the handle of
the tilting mechanism down to
unlock it (2). It is now possible to
tilt the carrier.
