Sime FORMAT DGT HE Installer's Instructions page 5

1.2.2 FORMAT DGT HE 25-30-35 (fig. 1/a)
214
450
169
39
S3
122
33
G
60
100
290
50
29,5
ATTACCHI
R
M Mandata impianto
G
E
U
S3 Scarico condensa ø 25
R M G E U
70 70 70 70
= =
Ritorno impianto
G 3/4" (UNI - ISO 228/1)
G 3/4" (UNI - ISO 228/1)
Alimentazione gas
G 3/4" (UNI - ISO 228/1)
Entrata acqua sanitaria
G 1/2" (UNI - ISO 228/1)
Uscita acqua sanitaria
G 1/2" (UNI - ISO 228/1)
Fig. 1/a
