Monitor Main Display Area

Area
1
ECG display area
2
SpO display area
2
3
>> button
4
Print button
5
Print button (ECG)
6
Menu button
7
STAT button
8
Temperature display area
9
Blood glucose display area
10
SpO display area
2
11
NIBP display area
12
Heart rate display area
13
Status indicator display area
14
Date / Time
15
Patient's info
Description
Display ECG-related info
Display SpO -related info
2
Display ECG-
different channel
Touch this button to print out the readings
Touch this button to save the ECG data and to print
out the ECG waveforms
Touch this button to change settings
Touch this button for a 5-min consecutive
measurement
Display temperature-related info
Display blood-glucose-related info
Display SpO -related info
2
Display NIBP-related info
Display heart-rate-related info
Display status indicators
Display date and time
You may key in the date and time
Display the patient's ID
