Fora ATMS User Manual

(1) What's in the box
Rolling Stand
1.
IR42b Forehead Thermometer
2.
an iPad
3.
(3) How to assemble the stand?
- Also see the assembly video (https://foracare.com/fora-auto-temperature-measurement-station-atms-assembly-video/)
Step 1.
Pull up the center stand.
Adjust the position of the basket, and tighten up the bolts
Step 4.
Insert the exible conduit and tighten up it.
(4) How to use the application?
1. iFora TM should be already installed in the iPad, and the thermometer has been paired with the APP. If not, refer to the section
(7) How to install the application.
2. Open the app (iFORA TM) and turn on the thermometer. The color of the Bluetooth icon on the app will turn to blue (Figure 2).
When you see the blue icon, it's ready to go. You can take the rst measurement.
3. If the unit of temperature is not for your region, please change it under Setting → Temperature Unit (Figure 3).
Auto Temperature Measurement Station (ATMS)
User Guide
(2) Hardware overview
IR42 Non-Contact
Forehead Thermometer
(Clamp with lock)
Table desk
with holding handler
MCS stand
Step 2.
Adjust the table desk and x it.
Step 5.
Insert the iPad in the holder. Lock and secure the iPad
with the key.
iPad
Step 3.
Fix the iPad holder
Step 6.
Place the thermometer. Make the sensor direction
parallel to the ground.
Clamps
Flexible Coils
Bayonet Mount
Basket
Wheels
Figure 2 Figure 3
