Vestil UNI Owner's Manual

V M
ESTIL ANUFACTURING
2999 N. Wayne St., Angola, IN 46703
Ph: 260-665-7586 · Fax: 260-665-1339
E-mail: sales@vestil.com Website: www.vestil.com
Installation Instructions .......................................... 2
Operation Instructions ..................................... 3-4
Routine Maintenance & Safety Checks .................. 5
Exploded Structural Parts Drawing & BOM ............ 6-7
Motor and Transformer Connections ............................ 8
I N
MPORTANT OTES
Ensure that all employees understand and follow the following.
Read and understand the owner's manual before using or servicing
o
the Uni-Tilt.
The load must be removed and the platform supported or fully
o
lowered before any work is performed on the lift.
Ensure that all safety and warning labels stay in place and are
o
legible.
Do not use the Uni-Tilt if any damage or unusual noise is observed.
o
Always watch the platform and the container carefully when the
o
tilter is in operation.
Do not transport the Uni-Tilt with any load on the platform.
o
Do not use brake fluid or jack oils in the hydraulic system. If oil is
o
needed, use an anti-wear hydraulic oil with a viscosity grade of
150 SUS at 100°F, (ISO 32 cSt @ 40°C), or Dexron transmission fluid.
Contact the manufacturer for any needed MSDS information.
o
Do not perform any modifications to the Uni-Tilt without the
♦
manufacturer's approval. Failure to receive authorization for
changes to the equipment could void the warranty.
Maintenance and repairs are to be done only by personnel qualified
♦
to perform the required work. Warranty labor charges will not
receive consideration without prior written authorization by the
manufacturer.
V M . C .
ESTIL FG O
C .
ORP
M
ODEL
Serial number ____________
, W S
ARNINGS AND AFETY
02/05
O
WNER
M
UNI
Electrical & Hydraulic Diagrams & BOM .............. 9-10
Power Unit's Operation ...................................... 11
Troubleshooting .............................................. 12
Safety Label Identification .............................................13
Warranty ....................................................... 14
I
NSTRUCTIONS
03-126-121.doc
'
S
ANUAL
WHEN ORDERING
:
REPLACEMENT PARTS
We take pride in using quality
parts on the equipment we
manufacture. We are not
responsible for equipment
problems resulting from the use
of unapproved replacement
parts.
To order replacement or
spare parts for this equipment,
contact the factory.
In any communication with
the factory please be prepared
to provide the machine's serial
number, which is indicated on
the machine dataplate.
R
ECEIVING INSTRUCTIONS
Every unit is thoroughly
tested and inspected prior to
shipment. However, it is
possible that the unit could
incur damage during transit.
Inspect the unit closely when
it arrives. If you see evidence
of damage or rough handling to
either the packaging or to the
product when it is being
unloaded, immediately make a
note of it on the Bill Of Lading!
It is important that you
remove the product's packaging
upon its arrival to ensure that
there is no concealed damage
or to enable a timely claim with
the carrier for freight damage.
Also verify that the product
and its specifications are as
ordered.
1
