ZEPHYRONLINE.COM
Replacing Aluminum Mesh Filters
Hood Model
ZOM-E30BS/ ZOM-E30BBS
ZOM-E36BS/ ZOM-E36BBS
To order parts, visit us online at http://store.zephyronline.com.
LumiLight LED
In the unlikely event that your LumiLight LED fails, please contact Zephyr to order replacement parts.
See the list of parts and accessories page for part numbers and contact information.
LED Removal (FIG. D):
1. Remove aluminum mesh filter.
2. If applicable, remove side panels by two screws each. Remove light panel by two screws.
3. Disconnect LED light quick connector.
4. Push in the two side clips on the ends of the LED light.
5. Push LED light through the light panel opening.
Milano Use, Care, and Installation Guide
Part Number
50200059
50200059
Push the clip
FIG. D
Maintenance
Quantity to Order
2
2
21
