Attention for Camera
Installation
Select an Install Height
Please install the camera 2-3 meters (7-10
ft) above ground. This height maximizes
the detection range of the motion sensor.
For effective motion detection, please
install the camera angularly and the angle
between the PIR sensor and the detected
object must be larger than 10°.
NOTICE: Due to the limitation of PIR sensor
detection, if a moving object approaches
the PIR sensor vertically (the direction of
the orange arrow in the image), the
camera may fail to detect motion.
5 English
A B
Mounting Height:
2-3 Meters
PIR Detecting Distance:
2-7 Meters
θ
PIR Sensor Detecting Range
The PIR detection range can be turned to meet your specific needs. You can refer to the following
table to set it up in Reolink App Device Settings.
Sensitivity Value
Low 0 - 10
Mid 11 - 30
High 31 - 50
NOTICE: The path to adjust the Sensitivity on Reolink App: Device Settings-> MD Settings-> Sensitivity
Detecting Distance
(For moving and living things)
Up to 2 meters (3ft)
Up to 4 meters (12ft)
Up to 7 meters (21ft)
