Sheridan Ottoman bed
Assembly lnstructions - Please keep for future reference
hygena
Dimensions (3')
Length - 202.5 cm
Width- 100 cm
Height - 84.5 cm
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400 800
357/0537
339/6096
359/6676
Issue 1- 29-10-14
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for hygena 357/0537
Summary of Contents for hygena 357/0537
- Page 1 Sheridan Ottoman bed Assembly lnstructions - Please keep for future reference 357/0537 339/6096 hygena 359/6676 Dimensions (3') Length - 202.5 cm Width- 100 cm Height - 84.5 cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400 800...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly Check you have all the Assemble the item as close We do not components and tools listed on to its final position (in the same recommend the pages 2, 3 and 4.
-
Page 3: Components - Parts
Components - Parts lf you have damaged or missing components. call the Customer Helpline: 0345 6400 800 INSIDE Right side rail (1930*300mm) FRONT INSIDE Headboard (1000*800mm) Left side rail (1930*300mm) INSIDE Footboard Hinges x 2 Piston x 2 (1000*300mm) (750*115mm) (420mm) Mattress support Base panel... - Page 4 Components - Parts lf you have damaged or missing components. call the Customer Helpline: 0345 6400 800 Bentwood Slats x 14 Base Support x 4 (915*9*55mm) (120*20mm) Wooden support railx 2 Metal support rail x 1 (940*20mm) (940*60mm) Slat caps x 28 Fabric strap (5.5mm) (240*40mm)
-
Page 5: Tools Required
Components - Fittings 0345 6400 800 45mm 5/16'' Bolt x 2 25mm 5/16'' Bolt x 16 15mm 1/4'' Bolt x 24 32mm M4 Wood screw x 28 5/16'' Flat washer x 10 Nut x 4 4mm Allen key x 1 Spanner x 1 5mm Allen key x 1 Tools required... - Page 6 Assembly Instructions Attaching feet Attach 2 x Feet the underside of the headboard using screws as shown. Repeat on the underside of the footboard Note: The position is outlined.
- Page 7 Assembly Instructions Preparing footboard Attach the ottoman frame support to the footboard using fixings shown. Attach base supports to the footboard headboard shown using screws Note: The positions should be outlined.
- Page 8 Assembly Instructions Attaching side rails Loosely fit bolts into headboard footboard as shown. With help, raise the headboard into the standing position. Hang the metal brackets on the end of the side rails , over the bolts in the headboard Note: Ensure the 4 holes on the inside of each side rail are located...
- Page 9 Assembly Instructions Preparing base Assemble corner brackets in each corner using screws Note: Ensure these are at the same height as all other metal support bars. The positions should be outlined. Attach the wooden support rails in beween side rails using screws C: Attach the metal...
- Page 10 Assembly lnstructions Attaching folding hinges Secure the hinges to the side rails & using bolts as shown. Note: Ensure the hinges are fitted the correct way around as shown. Locate pistons onto down hinges as shown. Note: Ensure the "smaller" down tube is facing down as shown.
- Page 11 Assembly lnstructions Attaching mattress support brackets With help, carefully turn the frame over. Note: The frame is heavy, lift with care. Assemble mattress support brackets end frame using screws Locating ottoman frame With help, lift the ottoman frame into position onto hinges Note: The frame is heavy, lift with care.
- Page 12 Assembly lnstructions Attaching slats Assemble slat caps onto each end of bentwood slats Fit the bentwood slats into the ottoman frame (sides) by locating slat caps into the holes. If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400 800 Home Retail Group.
