Wooden Space Saver Square Chair
Assembly Instructions
Dimensions
Width - 50cm
Depth - 50cm
Height - 72cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing part s, call the Customer Helpline:
Argos = 0345 6400800
- Please keep for future reference
314/9195
323/4550
Issue 1 - 25/10/14
Advertisement
Related Manuals for hygena 314/9195
Summary of Contents for hygena 314/9195
- Page 1 Wooden Space Saver Square Chair Assembly Instructions 314/9195 - Please keep for future reference 323/4550 Dimensions Width - 50cm Depth - 50cm Height - 72cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing part s, call the Customer Helpline:...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • During assembly do not stand • To reduce • Check you have all the components and tools listed on or put weight on the product, the likelihood of the following pages.
- Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline: Argos = 0345 6400800 Please check you have all the panels listed below The quantities below are for 4 chairs Chair back x 4 Chair back x 4 Side panel x 4 (72 x 50 cm) (72 x 45 cm)
- Page 4 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly of 4 chairs. In some cases more fittings may be supplied than are required. 58mm Bolt x 32 28mm Bolt x 32 16mm Bolt x 12 Plain washer x 76...
- Page 5 Assembly Instructions Step 1 Assemble chair backs Fix upper frame and bottom frame chair back by using bolts , spring washers and plain washers Fix chair back the assembled unit by using bolts , spring washers and plain washers Note: The arrow should point outward as shown in the figure.
- Page 6 Assembly Instructions Step 2 Assemble side panels Fix side panel the assembled unit by using bolts , spring washers and plain washers Fix side panel the assembled unit by using bolts , spring washers and plain washers Note: The arrow should point outward as shown in the figure.
- Page 7 Assembly Instructions Step 3 Assemble bottom panel Fix bottom panel bottom frame by using bolts and plain washers Note: Only fix 3 holes as shown in the figure. Step 4 Important note: After all the parts are positioned, you can now fully tighten all bolts fixed on previous steps. Assemble foot Screw foot into bottom...
- Page 8 Assembly Instructions Step 5 Put chair seat onto the frame. Note: The arrow should point outward as shown in the figure. Assembly is complete. Customer Helpline: If you need help or have damaged or missing parts, call the Argos = 0345 6400800...
