Technical Specifications - Omcan FR-CN-0155 Instruction Manual

Model
Power
Freezer Capacity
Number of Doors
Number of Baskets
Included
Max. Number of
Baskets
Temperature Range
Max Ambient Temp
Rating
Refrigerant
Electrical
Weight
Packaging Weight
Dimensions
Packaging
Dimensions
Item Number
TRANSPORTATION AND PLACEMENT
• When transporting the chest freezer from one place to another, the inclination of the cabinet should not
exceed 45 degrees, for prevention against compressor or system damage.
• Before use, remove all the packing material. The back side of the cabinet should be more than 20cm away
from the wall, both flank sides more than 20cm.
• The freezer should be put in well-ventilated, dry place. Don't use it under direct sunshine. The freezer
should be kept away from water sink, heat source and any volatile, corrosive material.
POWER SOURCE AND TEST-RUNNING
• Specified capacity of the wire is 7A. Section squares of the wire is 0.82mm2. Single line or compound
lines are all allowed. The fuse of 2.5A specified electric current should be installed. (Power cord should be
replaced with the same of 7A and 0.82mm2, when it is damaged).
• Single-phase power supply, 60Hz, voltage range 98~132V. If the voltage is unstable, please install a
voltage stabilizer with capacity above 1000W.

Technical Specifications

FR-CN-0155
64.3W
156 L / 5.5 cu.ft.
3
70.5 lbs. / 32 kgs. 79.4 lbs. / 36 kgs.
79.4 lbs. / 36 kgs. 90.4 lbs. / 41 kgs.
22" x 32.5" x 33" 22.3" x 40" x 33"
559 x 826 x 838mm 565 x 1016 x 838mm
23" x 34" x 34.3" 23" x 43" x 34.5"
584 x 864 x 870mm 584 x 1092 x 876mm
45294
FR-CN-0198
67.5W
204 L / 7.2 cu.ft. 230 L / 8.1 cu.ft.
1
1
≤ -18°C / ≤ -0.4°F
32°C / 90°F
R600a
110V / 60Hz
97 lbs. / 44 kgs.
110.2 lbs. / 50 kgs.
25.5" x 43" x 32.6"
648 x 1092 x 828mm
27" x 45.5" x 34.5"
686 x 1156 x 876mm
45295
7
FR-CN-0230 FR-CN-0412
63.9W
412 L / 14.6 cu.ft.
4
141 lbs. / 64 kgs.
165 lbs. / 75 kgs.
27.6" x 60" x 32.5"
701 x 1524 x 826mm
30.3" x 62.2" x 34.3"
770 x 1580 x 871mm
45296
Installation
106.6W
R134a
45297
