- Page 1 Display Freezer Model FR-CN-0600-2 Item 48376 Instruction Manual Revised - 08/15/2024 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com...
-
Page 2: Table Of Contents
Table of Contents Model FR-CN-0600-2 Section Page Disclaimer ----------------------------------------------------------------------------------------------------- 3 General Information --------------------------------------------------------------------------------- 4 - 5 Safety and Warranty --------------------------------------------------------------------------------- 5 - 7 Technical Specifications ------------------------------------------------------------------------------- 8 Operation ------------------------------------------------------------------------------------------------ 9 - 10 Maintenance ----------------------------------------------------------------------------------------------- 10 Troubleshooting ----------------------------------------------------------------------------------- 10 - 12... -
Page 3: Disclaimer
Disclaimer OMCAN IS NOT RESPONSIBLE FOR ANY DAMAGES DUE TO WATER LEAKS. WARRANTY FOR WATER LEAKS IS VOID IF THE AMBIENT ROOM TEMPERATURE EXCEEDS 75°F AND 55% RELATIVE HUMIDITY, AND THE APPLIANCE DRAIN IS NOT CONNECTED DIRECTLY TO A FLOOR DRAIN. -
Page 4: General Information
If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents. -
Page 5: Safety And Warranty
Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. - Page 6 Safety and Warranty SUFFICIENT SPACE The distance from both sides and back of the freezer to the walls or other obstructions must not be less than 10cm. The refrigeration capability might be reduced if the surrounding space is too small to circulate air. GOOD VENTILATION Always place the freezer in a place with good ventilation.
- Page 7 2 YEAR PARTS AND LABOUR 5 YEAR COMPRESSOR WARRANTY Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule an Omcan authorized service technician to repair the equipment locally.
-
Page 8: Technical Specifications
Technical Specifications Model FR-CN-0600-2 Item Number 48376 Power 2 HP / 1500 W Capacity 600 L / 21.18 cu.ft. Exterior Material Glass / Stainless Steel / Plastic Interior Material Plastic / Stainless Steel Shelf Material Chrome Plate Shelf Dimensions 27.8” x 19.1” / 705 x 485mm... -
Page 9: Operation
Operation USE AND CAUTION Before Use Plug the freezer in a 110-120V exclusive socket. Once the freezer is running, put a hand on the air suction to confirm it is sufficiently cold. Then you may put food inside the cold box. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. -
Page 10: Maintenance
4. Frequently observe the operation of the product. In case of any abnormal noise, smell or smog, cut the power supply immediately and call Omcan for help. Do not restart the product before the problem is fixed. 5. Omcan will not be responsible for any accident or damage incurred by failure to follow these instructions. -
Page 11: Troubleshooting
Defrost is on. Stop defrosting. The refrigerant is leaking. Patch the leak and refill refrigerant. Unit failure. Call Omcan. Weak air from air curtain, and Evaporator blocked by frost. Increase melting frequency. higher cabinet temperature. Inside fan damaged. Replace the fan. - Page 12 Troubleshooting TROUBLESHOOTING OF DIGITAL CONTROL Fault Code Causes Solution Open circuit or short circuit of Check if the plug on mainboard is loosened or not, or temperature probe. change temperature probe. Open circuit or short circuit of Check if the plug on mainboard is loosened or not, or defrosting probe.
-
Page 13: Parts Breakdown
Parts Breakdown Model FR-CN-0600-2 48376... - Page 14 Parts Breakdown Model FR-CN-0600-2 48376 Item No. Description Position Item No. Description Position Item No. Description Position AR503 Left Door Assembly for 48376 AR520 Right Frame for 48376 AL832 Mainboard for 48376 AR504 Right Door Assembly for 48376 AR521 Condenser for 48376...
-
Page 15: Electrical Schematics
Electrical Schematics Model FR-CN-0600-2 48376... -
Page 16: Notes
Notes ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________... - Page 17 Notes ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________...
- Page 18 Notes ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________...
-
Page 19: Warranty Registration
Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: Merci d’avoir acheté... - Page 20 à plus de 6500 produits provenant du monde entier. Desde 1951 Omcan ha crecido hasta convertirse en un líder en la distribución de equipos y suministros de alimentos en América del Norte industria de servicios. Nuestro éxito en estos años se puede atribuir a nuestro compromiso de fortalecer y desarrollar nuevas relaciones...
