120x200x100CM LED LIGHT TENT
PARTS
A
A.
5x Long Frame Poles
B.
12x Short Frame Poles
C.
4x Mains Power Adapters
D.
9x Corner Joints
E.
4x Pole Joints
Step 1
B
D
F
G
B
C
D
F.
2x Short Strip Diffusers
G. 2x Long Strip Diffusers
H.
1x Large Diffuser
I.
3x Clamps
J.
2x Hooks
A
H
I
K
L
M
J
E
First, get 2x Long frame poles [A], 2x Short Frame
Poles [B] and four Corner-Joints [D] and connect them
together to form the base of the tent, as shown in the
photos to the left, and below.
D
B
D
Instruction Manual
N
O
K.
1x Black Background
L.
1x Peach Background
M. 1x White Background
N. 8x LED Light Panels
O. 1x Outer Skin
A
A
D
B
D
