Trion Air Boss VOMP 600 Installation, Operation & Maintenance Manual

Vertical oil mist precipitator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Installation
Operation
Maintenance
Manual
Air Boss
VOMP 600
®
READ AND SAVE THESE INSTRUCTIONS
Vertical Oil Mist Precipitator
T R I O N
| w w w . t r i o n i a q . c o m
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Air Boss VOMP 600 and is the answer not in the manual?

Questions and answers

Related Manuals for Trion Air Boss VOMP 600

Summary of Contents for Trion Air Boss VOMP 600

  • Page 1 Installation Operation Maintenance Manual Air Boss VOMP 600 ® READ AND SAVE THESE INSTRUCTIONS Vertical Oil Mist Precipitator T R I O N | w w w . t r i o n i a q . c o m ®...

  • Page 2: Table Of Contents

    I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l VOMP 600 VERTICAL OIL MIST PRECIPITATOR TABLE OF CONTENTS...

  • Page 3: Warranty

    TRION/HERRMIDIFIER shall not be responsible for loss of use of any product, loss of time, inconvenience, or damage The TRION VOMP 600 weighs 120 lbs. (54 kg.). to other equipment, or any other indirect or consequential damage with respect to property whether as a result of breach of warranty, neglect, or otherwise.

  • Page 4: Introduction And Operation

    I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l III. INTRODUCTION AND OPERATION EXPLANATION IV. INTRODUCTION AND OPERATION EXPLANATION The TRION VOMP 600 is designed primarily for the filtration HOOD AND DUCT DESIGN of mists from ventilation air as found in the metal working industries.

  • Page 5: Inspection And Installation

    Damage should be noted and a claim immediately filed with the carrier at the receiving end. Contact your TRION Representative or the factory INITIAL START-UP for authorization and instructions prior to the return of any equipment.

  • Page 6: Care And Maintenance

    71° C), and a good detergent, safe for use on aluminum, should be used. TRION’s TriDex liquid detergent, formulated specifically for this purpose, is available through your TRION Representative or direct from the factory. The filter components should be rinsed first in warm water, then soaked in a detergent water solution.

  • Page 7: Troubleshooting

    I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l IX. TROUBLESHOOTING All TRION Air Cleaners are manufactured to give the user continued, trouble-free service. However, as with all mechanical equipment, breakdowns can occur.

  • Page 8: Figures

    I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l Figure 1 - VOMP600 Outline w w w.

  • Page 9: System Performance Curve

    I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l Figure 2 - System Performance Curve w w w.

  • Page 10: Wiring Schematic 120V

    I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l Figure 3 - Wiring Schematic 120V / 60Hz w w w.

  • Page 11: Wiring Schematic 240V

    I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l Figure 4 - Wiring Schematic 240V / 60Hz w w w.

  • Page 12: Parts Listing

    I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l Figure 5 - Parts Listing P/N 347330 Item...

  • Page 13: Exploded Parts View

    I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l Figure 6 - Exploded Parts View w w w.
  • Page 14 TRION ® 101 McNeill Rd. | Sanford, NC 27330 P: 800.884.0002 | F: 800.458.2379 | www.trioniaq.com | customerservice@trioniaq.com Form No. 151345-001 Rev. 10/18 © TRION 2018. All Rights Reserved.
