• Basic specifications
The features that are absolutely essential for the device (mandatory features) are specified
in the basic specifications. The number of positions depends on the number of features
available.
The selected option of a feature can consist of several positions.
• Optional specifications
The optional specifications describe additional features for the device (optional features).
The number of positions depends on the number of features available.
The features have a 2-digit structure to aid identification (e.g. JA). The first digit (ID)
stands for the feature group and consists of a number or a letter (e.g. J = test, certificate).
The second digit constitutes the value that stands for the feature within the group (e.g. A
= 3.1 material (wetted parts), inspection certificate).
More detailed information about the device is provided in the following tables. These tables
describe the individual positions and IDs in the extended order code which are relevant to
hazardous locations.
Device type
Position Selected option
1 Instrument family 8
2 Sensor E, F
3 Transmitter 2
4 Generation index B
5,6 Nominal diameter 08
15
25
40
50
Basic specifications
Position Selected option
1, 2 Approval NF
N4
3 Output A
B
C
G
Optional specificationspecifications
Position Selected Option
A Optional NA
specifications
Description
Coriolis Promass flow measuring system
Sensor type
Transmitter type: 2-wire, compact version
Platform generation
Nominal diameter of sensor
Explosion protection
Ex ia IIC T1 ~ T6 Gb
Ex ia IIC T1 ~ T6 Ga/Gb, DIP A21 T
4-20 mA HART
4-20 mA HART, Impulse/Frequency/Switch output
4-20 mA HART, 4-20 mA
PROFIBUS PA, Impulse/Frequency/Switch output
Description
Overvoltage protection (OVP)
Proline Promass 200
, T* IP6X
A
