Proline Promass H 300 PROFIBUS DP Table of contents Table of contents About this document ....6 Installation ..... . . 21 Document function .
Page 4 Table of contents Proline Promass H 300 PROFIBUS DP 8.3.10 User roles and related access 10.6.3 Selecting and setting the medium . . . authorization ....57 10.6.4 Configuring communication...
Page 5 13.2 Measuring and test equipment ... 214 13.3 Endress+Hauser services ....214 Repairs ......215 14.1 General notes .
Page 6: About This Document
About this document Proline Promass H 300 PROFIBUS DP About this document Document function These Operating Instructions contain all the information that is required in various phases of the life cycle of the device: from product identification, incoming acceptance and storage, to mounting, connection, operation and commissioning through to troubleshooting, maintenance and disposal.
Page 7: Tool Symbols
Proline Promass H 300 PROFIBUS DP About this document Symbol Meaning Light emitting diode is on. Light emitting diode is flashing. 1.2.4 Tool symbols Symbol Meaning Flat blade screwdriver Allen key Open-ended wrench 1.2.5 Symbols for certain types of information...
Page 8: Documentation
• W@M Device Viewer (www.endress.com/deviceviewer): Enter the serial number from nameplate • Endress+Hauser Operations App: Enter the serial number from the nameplate or scan the 2D matrix code (QR code) on the nameplate Detailed list of the individual documents along with the documentation code →...
Page 9: Basic Safety Instructions
Proline Promass H 300 PROFIBUS DP Basic safety instructions Basic safety instructions Requirements for the personnel The personnel for installation, commissioning, diagnostics and maintenance must fulfill the following requirements: ‣ Trained, qualified specialists must have a relevant qualification for this specific function and task.
Page 10: Workplace Safety
Verification for borderline cases: ‣ For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in verifying the corrosion resistance of fluid-wetted materials, but does not accept any warranty or liability as minute changes in the temperature, concentration or level of contamination in the process can alter the corrosion resistance properties.
Page 11: Security
Proline Promass H 300 PROFIBUS DP Basic safety instructions It meets general safety standards and legal requirements. It also complies with the EU directives listed in the device-specific EU Declaration of Conformity. Endress+Hauser confirms this by affixing the CE mark to the device. IT security Our warranty is valid only if the device is installed and used as described in the Operating Instructions.
Page 12: Access Via Web Server
Basic safety instructions Proline Promass H 300 PROFIBUS DP • User-specific access code Protect write access to the device parameters via the local display, Web browser or operating tool (e.g. FieldCare, DeviceCare). Access authorization is clearly regulated through the use of a user-specific access code.
Page 13: Access Via Service Interface (Cdi-Rj45)
Proline Promass H 300 PROFIBUS DP Basic safety instructions 2.7.4 Access via service interface (CDI-RJ45) The device can be connected to a network via the service interface (CDI-RJ45). Device- specific functions guarantee the secure operation of the device in a network.
Page 14: Product Description
Product description Proline Promass H 300 PROFIBUS DP Product description The device consists of a transmitter and a sensor. The device is available as a compact version: The transmitter and sensor form a mechanical unit. Product design N ic te r e rg ö...
Page 15: Incoming Acceptance And Product
Technical Documentation present? • If one of the conditions is not satisfied, contact your Endress+Hauser Sales Center. • Depending on the device version, the CD-ROM might not be part of the delivery! The Technical Documentation is available via the Internet or via the Endress+Hauser Operations App, see the "Product identification"...
Page 16: Transmitter Nameplate
 8 sections • The W@M Device Viewer: enter the serial number from the nameplate (www.endress.com/deviceviewer) • The Endress+Hauser Operations App: Enter the serial number from the nameplate or scan the 2-D matrix code (QR code) on the nameplate. 4.2.1...
Page 17: Sensor Nameplate
Proline Promass H 300 PROFIBUS DP Incoming acceptance and product identification 4.2.2 Sensor nameplate Order code: Ser. no.: Ext. ord. cd.: Date: A0029199  3 Example of a sensor nameplate Name of the sensor Manufacturing location Order code Serial number (ser. no.) Extended order code (Ext.
Page 18: Symbols On Measuring Device
Incoming acceptance and product identification Proline Promass H 300 PROFIBUS DP 4.2.3 Symbols on measuring device Symbol Meaning WARNING! This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in serious or fatal injury. Reference to documentation Refers to the corresponding device documentation.
Page 19: Storage And Transport
Proline Promass H 300 PROFIBUS DP Storage and transport Storage and transport Storage conditions Observe the following notes for storage: ‣ Store in the original packaging to ensure protection from shock. ‣ Do not remove protective covers or protective caps installed on process connections.
Page 20: Measuring Devices With Lifting Lugs
Storage and transport Proline Promass H 300 PROFIBUS DP 5.2.2 Measuring devices with lifting lugs CAUTION Special transportation instructions for devices with lifting lugs ‣ Only use the lifting lugs fitted on the device or flanges to transport the device.
Page 21: Installation
Proline Promass H 300 PROFIBUS DP Installation Installation Installation conditions No special measures such as supports are necessary. External forces are absorbed by the construction of the device. 6.1.1 Mounting position Mounting location A0028772 To prevent measuring errors arising from accumulation of gas bubbles in the measuring tube, avoid the following mounting locations in the pipe: •...
Page 22 Installation Proline Promass H 300 PROFIBUS DP Ø orifice plate, pipe restriction [mm] [in] [mm] [in] ³⁄₈ 0.24 ½ 0.40 0.55 1½ 0.87 1.10 Orientation The direction of the arrow on the sensor nameplate helps you to install the sensor according to the flow direction (direction of medium flow through the piping).
Page 23: Requirements From Environment And Process
If operating outdoors: Avoid direct sunlight, particularly in warm climatic regions. You can order a weather protection cover from Endress+Hauser. →  217. System pressure It is important that cavitation does not occur, or that gases entrained in the liquids do not outgas.
Page 24 Installation Proline Promass H 300 PROFIBUS DP Thermal insulation In the case of some fluids, it is important to keep the heat radiated from the sensor to the transmitter to a low level. A wide range of materials can be used for the required insulation.
Page 25: Special Mounting Instructions
Proline Promass H 300 PROFIBUS DP Installation Using an electrical trace heating system If heating is regulated via phase angle control or pulse packages, magnetic fields can affect the measured values (= for values that are greater than the values permitted by the EN standard (sine 30 A/m)).
Page 26: Mounting The Measuring Device
Installation Proline Promass H 300 PROFIBUS DP SW 2.5 5 (0.2) min. 15 (0.6) A0029800 Cover borehole for the securing screw Securing screw to lock the cover Mounting the measuring device 6.2.1 Required tools For sensor For flanges and other process connections: Corresponding mounting tools 6.2.2...
Page 27: Turning The Transmitter Housing
Proline Promass H 300 PROFIBUS DP Installation 2. Install the measuring device or turn the transmitter housing so that the cable entries do not point upwards.  A0029263 6.2.4 Turning the transmitter housing To provide easier access to the connection compartment or display module, the transmitter housing can be turned.
Page 28: Post-Installation Check
Installation Proline Promass H 300 PROFIBUS DP – – – 3 mm A0030035 1. Depending on the device version: Loosen the securing clamp of the connection compartment cover. 2. Unscrew the connection compartment cover. 3. Turn the display module to the desired position: max. 8 × 45° in each direction.
Page 29: Electrical Connection
Proline Promass H 300 PROFIBUS DP Electrical connection Electrical connection NOTICE The measuring device does not have an internal circuit breaker. ‣ For this reason, assign the measuring device a switch or power-circuit breaker so that the power supply line can be easily disconnected from the mains.
Page 30 Electrical connection Proline Promass H 300 PROFIBUS DP Signal damping Max. 9 dB over the entire length of the cable cross-section Shield Copper braided shielding or braided shielding with foil shield. When grounding the cable shield, observe the grounding concept of the plant.
Page 31 Proline Promass H 300 PROFIBUS DP Electrical connection Standard cable - customer-specific cable No cable is supplied, and it must be provided by the customer (up to max. 300 m (1 000 ft)) for the following order option: Order code for DKX001: Order code 040 for "Cable", option 1 "None, provided by customer, max 300 m"...
Page 32: Terminal Assignment
Electrical connection Proline Promass H 300 PROFIBUS DP 7.1.3 Terminal assignment Transmitter: supply voltage, input/outputs The terminal assignment of the inputs and outputs depends on the individual order version of the device. The device-specific terminal assignment is documented on an adhesive label in the terminal cover.
Page 33: Preparing The Measuring Device
Proline Promass H 300 PROFIBUS DP Electrical connection A0036639 Controller (e.g. PLC) Cable shield T-box Measuring device Local grounding Bus terminator Potential matching line 7.1.5 Preparing the measuring device NOTICE Insufficient sealing of the housing! Operational reliability of the measuring device could be compromised.
Page 34: Connecting The Transmitter
Electrical connection Proline Promass H 300 PROFIBUS DP 7.2.1 Connecting the transmitter A0026781 Terminal connection for supply voltage Terminal connection for signal transmission, input/output Terminal connection for signal transmission, input/output or terminal connection for network connection via service interface (CDI-RJ45); optional: connection for external WLAN antenna or remote display and...
Page 35 Proline Promass H 300 PROFIBUS DP Electrical connection 10 (0.4) mm (in) – A0029815 7. Push the cable through the cable entry . To ensure tight sealing, do not remove the sealing ring from the cable entry. 8. Strip the cable and cable ends. In the case of stranded cables, also fit ferrules.
Page 36 Electrical connection Proline Promass H 300 PROFIBUS DP Removing a cable 3 (0.12) A0029598  7 Engineering unit mm (in) 1. To remove a cable from the terminal, use a flat-blade screwdriver to push the slot between the two terminal holes 2.
Page 37: Connecting The Remote Display And Operating Module Dkx001
Proline Promass H 300 PROFIBUS DP Electrical connection 7.2.2 Connecting the remote display and operating module DKX001 The remote display and operating module DKX001 is available as an optional extra →  217. • The measuring device is always supplied with a dummy cover when the remote display and operating module DKX001 is ordered directly with the measuring device.
Page 38: Special Connection Instructions
Electrical connection Proline Promass H 300 PROFIBUS DP Special connection instructions 7.4.1 Connection examples PROFIBUS DP A0028765  8 Connection example for PROFIBUS DP, non-hazardous area and Zone 2/Div. 2 Control system (e.g. PLC) Cable shield: the cable shield must be grounded at both ends to comply with EMC requirements; observe cable...
Page 39 Proline Promass H 300 PROFIBUS DP Electrical connection 4...20 mA A0028759  10 Connection example for 4-20 mA current output (passive) Automation system with current input (e.g. PLC) Active barrier for power supply (e.g. RN221N) Analog display unit: observe maximum load...
Page 40 Electrical connection Proline Promass H 300 PROFIBUS DP Relay output A0028760  13 Connection example for relay output (passive) Automation system with relay input (e.g. PLC) Power supply Transmitter: Observe input values →  224 Current input A0028915  14...
Page 41: Hardware Settings
Proline Promass H 300 PROFIBUS DP Electrical connection Hardware settings 7.5.1 Setting the device address The address must always be configured for a PROFIBUS DP/PA device. The valid address range is between 1 and 126. In a PROFIBUS DP/PA network, each address can only be assigned once.
Page 42: Activating The Default Ip Address
Electrical connection Proline Promass H 300 PROFIBUS DP • If the device is operated with a baud rate of 1.5 MBaud and under: For the last transmitter on the bus, terminate by setting DIP switch 3 (bus termination) to ON.
Page 43: Post-Connection Check
Proline Promass H 300 PROFIBUS DP Electrical connection To guarantee IP66/67 degree of protection, Type 4X enclosure, carry out the following steps after the electrical connection: 1. Check that the housing seals are clean and fitted correctly. 2. Dry, clean or replace the seals if necessary.
Page 44: Operation Options
Operation options Proline Promass H 300 PROFIBUS DP Operation options Overview of operation options A0034513 Local operation via display module Computer with Web browser (e.g. Internet Explorer) or with operating tool (e.g. FieldCare, DeviceCare, AMS Device Manager, SIMATIC PDM) Field Xpert SFX350 or SFX370...
Page 45: Structure And Function Of The Operating Menu
Proline Promass H 300 PROFIBUS DP Operation options Structure and function of the operating menu 8.2.1 Structure of the operating menu For an overview of the operating menu for experts: "Description of Device Parameters" document supplied with the device→  246...
Page 46: Operating Philosophy
Operation options Proline Promass H 300 PROFIBUS DP 8.2.2 Operating philosophy The individual parts of the operating menu are assigned to certain user roles (operator, maintenance etc.). Each user role contains typical tasks within the device lifecycle. Menu/parameter User role and tasks...
Page 47: Display
Proline Promass H 300 PROFIBUS DP Operation options Menu/parameter User role and tasks Content/meaning Expert function-oriented Tasks that require detailed Contains all the parameters of the device and makes it possible to access these knowledge of the function of the parameters directly using an access code.
Page 48 Operation options Proline Promass H 300 PROFIBUS DP Display area In the display area, each measured value is prefaced by certain symbol types for further description: Measured variable Measurement channel Diagnostic behavior number ↓ ↓ ↓ Example Appears only if a diagnostics event is present for this measured variable.
Page 49: Navigation View
Proline Promass H 300 PROFIBUS DP Operation options 8.3.2 Navigation view In the submenu In the wizard /../Operation 0091-1 /../Select medium Access stat.disp Select medium Operator Liquid Locking status Display A0013993-EN A0013995-EN Navigation view Navigation path to current position Status area Display area for navigation Operating elements →...
Page 50 Operation options Proline Promass H 300 PROFIBUS DP Display area Menus Symbol Meaning Operation Appears: • In the menu next to the "Operation" selection • At the left in the navigation path in the Operation menu Setup Appears: • In the menu next to the "Setup" selection •...
Page 51: Editing View
Proline Promass H 300 PROFIBUS DP Operation options 8.3.3 Editing view Numeric editor +0.000 Xx – A0034250  17 For entering values in parameters (e.g. limit values) Entry display area Input screen Confirm, delete or reject entry Operating elements Text editor...
Page 52 Operation options Proline Promass H 300 PROFIBUS DP Operating key(s) Meaning Enter key • Press the key briefly: confirm your selection. • Press the key for 2 s: confirm the entry. Escape key combination (press keys simultaneously) Close the editing view without accepting the changes.
Page 53: Operating Elements
Proline Promass H 300 PROFIBUS DP Operation options 8.3.4 Operating elements Operating key(s) Meaning Minus key In a menu, submenu Moves the selection bar upwards in a picklist. With a Wizard Confirms the parameter value and goes to the previous parameter.
Page 54 Operation options Proline Promass H 300 PROFIBUS DP Calling up and closing the context menu The user is in the operational display. 1. Press the  and  keys for longer than 3 seconds.  The context menu opens. XXXXXXXXXX Setup Conf.backup...
Page 55: Navigating And Selecting From List
Proline Promass H 300 PROFIBUS DP Operation options 8.3.6 Navigating and selecting from list Different operating elements are used to navigate through the operating menu. The navigation path is displayed on the left in the header. Icons are displayed in front of the individual menus.
Page 56: Calling Up Help Text
Operation options Proline Promass H 300 PROFIBUS DP The direct access code consists of a 5-digit number (at maximum) and the channel number, which identifies the channel of a process variable: e.g. 00914-2. In the navigation view, this appears on the right-hand side in the header of the selected parameter.
Page 57: User Roles And Related Access Authorization
Proline Promass H 300 PROFIBUS DP Operation options Ent. access code Invalid or out of range input value Min:0 Max:9999 A0014049-EN For a description of the editing view - consisting of the text editor and numeric editor - with symbols →  51, for a description of the operating elements →  53 8.3.10...
Page 58: Enabling And Disabling The Keypad
Operation options Proline Promass H 300 PROFIBUS DP 2. Enter the access code.  The -symbol in front of the parameters disappears; all previously write- protected parameters are now re-enabled. 8.3.12 Enabling and disabling the keypad lock The keypad lock makes it possible to block access to the entire operating menu via local operation.
Page 59: Prerequisites
Proline Promass H 300 PROFIBUS DP Operation options 8.4.2 Prerequisites Computer hardware Hardware Interface CDI-RJ45 WLAN Interface The computer must have an RJ45 The operating unit must have a interface. WLAN interface. Connection Standard Ethernet cable with RJ45 Connection via Wireless LAN.
Page 60: Establishing A Connection
Operation options Proline Promass H 300 PROFIBUS DP Measuring device: Via CDI-RJ45 service interface Device CDI-RJ45 service interface Measuring device The measuring device has an RJ45 interface. Web server Web server must be enabled; factory setting: ON  For information on enabling the Web server →  64...
Page 61 Proline Promass H 300 PROFIBUS DP Operation options Via WLAN interface Configuring the Internet protocol of the mobile terminal NOTICE If the WLAN connection is lost during the configuration, settings made may be lost. ‣ Make sure that the WLAN connection is not disconnected while configuring the device.
Page 62: Logging On
Operation options Proline Promass H 300 PROFIBUS DP 2. Enter the IP address of the Web server in the address line of the Web browser: 192.168.1.212  The login page appears. 2 3 4 A0029417 Picture of device Device name...
Page 63: User Interface
Proline Promass H 300 PROFIBUS DP Operation options 8.4.5 User interface A0029418 Function row Local display language Navigation area Header The following information appears in the header: • Device name • Device tag • Device status with status signal →  151 •...
Page 64: Disabling The Web Server
Operation options Proline Promass H 300 PROFIBUS DP Navigation area If a function is selected in the function bar, the submenus of the function open in the navigation area. The user can now navigate through the menu structure. Working area...
Page 65: Access To The Operating Menu Via The Operating Tool
Proline Promass H 300 PROFIBUS DP Operation options Access to the operating menu via the operating tool The structure of the operating menu in the operating tools is the same as for operation via the local display. 8.5.1 Connecting the operating tool Via PROFIBUS DP network This communication interface is available in device versions with PROFIBUS DP.
Page 66 Operation options Proline Promass H 300 PROFIBUS DP A0027563  21 Connection via service interface (CDI-RJ45) Computer with Web browser (e.g. Microsoft Internet Explorer, Microsoft Edge) for accessing the integrated device Web server or with "FieldCare", "DeviceCare" operating tool with COM DTM "CDI Communication TCP/IP"...
Page 67: Fieldcare
FieldCare Function scope FDT-based plant asset management tool from Endress+Hauser. It can configure all smart field devices in a system and helps you manage them. By using the status information, it is also a simple but effective way of checking their status and condition.
Page 68 Operation options Proline Promass H 300 PROFIBUS DP Typical functions: • Configuring parameters of transmitters • Loading and saving device data (upload/download) • Documentation of the measuring point • Visualization of the measured value memory (line recorder) and event logbook...
Page 69: Devicecare
DeviceCare Function scope Tool to connect and configure Endress+Hauser field devices. The fastest way to configure Endress+Hauser field devices is with the dedicated "DeviceCare" tool. Together with the device type managers (DTMs) it presents a convenient, comprehensive solution. For details, see Innovation Brochure IN01047S Source for device description files See information →...
Page 70: System Integration
System integration Proline Promass H 300 PROFIBUS DP System integration Overview of device description files 9.1.1 Current version data for the device Firmware version 01.00.zz • On the title page of the Operating instructions • On the transmitter nameplate • Firmware version Diagnostics →...
Page 71: Manufacturer-Specific Gsd
Proline Promass H 300 PROFIBUS DP System integration 9.2.1 Manufacturer-specific GSD This GSD guarantees the unrestricted functionality of the measuring device. Device-specific process parameters and functions are therefore available. Manufacturer-specific GSD ID number File name PROFIBUS DP 0x156F EH3x156F.gsd The fact that the manufacturer-specific GSD should be used is specified in the Ident number selector parameter by selecting the Manufacturer option.
Page 72: Manual Setting
System integration Proline Promass H 300 PROFIBUS DP 9.3.2 Manual setting The manual setting is made in the Ident number selector parameter via the Promass 83 (0x1529) option. Afterwards the Promass 300 PROFIBUS DP makes the same input and output data and measured value status information →...
Page 73: Using The Control_Block Module
Proline Promass H 300 PROFIBUS DP System integration 9.4.1 Using the CONTROL_BLOCK module in the previous model If the CONTROL_BLOCK module is used in the previous model, the control variables are processed further if relevant functionalities can be assigned for the Promass 300.
Page 74: Cyclic Data Transmission
System integration Proline Promass H 300 PROFIBUS DP Cyclic data transmission Cyclic data transmission when using the device master file (GSD). 9.5.1 Block model The block model shows which input and output data the measuring device makes available for cyclic data exchange. Cyclic data exchange takes place with a PROFIBUS master (Class 1), e.g.
Page 75 Proline Promass H 300 PROFIBUS DP System integration AI module (Analog Input) Transmit an input variable from the measuring device to the PROFIBUS master (Class 1). The selected input variable, along with the status, is cyclically transmitted to the PROFIBUS Master (Class 1) via the AI module. The input variable is depicted in the first four bytes in the form of a floating point number as per the IEEE 754 standard.
Page 76 System integration Proline Promass H 300 PROFIBUS DP Factory setting Function block Factory setting AI 1 Mass flow AI 2 Volume flow AI 3 Corrected volume flow AI 4 Density AI 5 Mass flow AI 6 Temperature AI 7 Mass flow...
Page 77 Proline Promass H 300 PROFIBUS DP System integration SETTOT_TOTAL module The module combination consists of the SETTOT and TOTAL functions: • SETTOT: Control the totalizers via the PROFIBUS master. • TOTAL: Transmit totalizer value, along with the status, to the PROFIBUS master.
Page 78 System integration Proline Promass H 300 PROFIBUS DP Data structure Output data of SETTOT and MODETOT Byte 1 Byte 2 Control variable 1: SETTOT Control variable 2: MODETOT Input data of TOTAL Byte 1 Byte 2 Byte 3 Byte 4...
Page 79 Proline Promass H 300 PROFIBUS DP System integration Selection: device function Device function Factory setting: Status (meaning) Empty pipe detection • 0 (device function not active) • 1 (device function active) Low flow cut off • Bit 0: Verification status - Check not done •...
Page 80 System integration Proline Promass H 300 PROFIBUS DP Function block Device function Values: control (meaning) DO 6 Is not used. Assignment of medium type DO 7 Concentration (see the following table) Only available with the Heartbeat Verification application package Only available with the Concentration application package...
Page 81: Address Shifting Configuration
Proline Promass H 300 PROFIBUS DP System integration modules. The GSD file contains a description of the individual modules along with their individual properties. The modules are permanently assigned to the slots. When configuring the modules, it is absolutely essential to observe the sequence/arrangement of the modules. Any gaps between the configured modules must be filled with the EMPTY_MODULE.
Page 82: Configuring Address Shifting
1001 : °C 1002 : °F 1000 : K 1003 : °R For more information on the "slot/index table", please contact the Endress+Hauser Sales Center. 9.6.4 Accessing data via PROFIBUS DP The PROFIBUS master uses the indexes 230 to 245 in slot 0 to access the address shifting data area.
Page 83 Proline Promass H 300 PROFIBUS DP System integration parameter via address shifting, the master can read out the current volume flow measured value in slot 0 and index 230. The data type (integer/float) and data access (read/write) depend on the parameter entered in the configuration area.
Page 84: Commissioning
Commissioning Proline Promass H 300 PROFIBUS DP Commissioning 10.1 Function check Before commissioning the measuring device: ‣ Make sure that the post-installation and post-connection checks have been performed. • "Post-installation check" checklist→  28 • "Post-connection check" checklist →  43 10.2...
Page 85: Configuring The Measuring Device
Proline Promass H 300 PROFIBUS DP Commissioning X X X X X X X 20.50 Main menu 0104-1 Display language English Operation Setup Display language 0104-1 English Ã Deutsch Español Français Display language 0104-1 Ã English Deutsch Español Français Hauptmenü...
Page 86: Defining The Tag Name
Commissioning Proline Promass H 300 PROFIBUS DP Navigation "Setup" menu  Setup →  87 Device tag ‣ →  87 System units ‣ Medium selection →  90 ‣ Communication →  91 ‣ Analog inputs →  93 ‣...
Page 87: Setting The System Units
Proline Promass H 300 PROFIBUS DP Commissioning XXXXXXXXX A0029422  24 Header of the operational display with tag name Tag name Enter the tag name in the "FieldCare" operating tool →  69 Navigation "Setup" menu → Device tag Parameter overview with brief description...
Page 88 Commissioning Proline Promass H 300 PROFIBUS DP Temperature unit →  89 Pressure unit →  89 Parameter overview with brief description Parameter Description Selection Factory setting Mass flow unit Select mass flow unit. Unit choose list Country-specific: • kg/h Result •...
Page 89 Proline Promass H 300 PROFIBUS DP Commissioning Parameter Description Selection Factory setting Temperature unit Select temperature unit. Unit choose list Country-specific: • °C Result • °F The selected unit applies for: • Electronic temperature parameter (6053) • Maximum value parameter (6051) •...
Page 90: Selecting And Setting The Medium
Commissioning Proline Promass H 300 PROFIBUS DP 10.6.3 Selecting and setting the medium The Select medium wizard submenu contains parameters that must be configured in order to select and set the medium. Navigation "Setup" menu → Select medium ‣ Medium selection →...
Page 91: Configuring Communication
Proline Promass H 300 PROFIBUS DP Commissioning Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry / User interface Select medium – Select medium type. • Liquid Liquid • Gas Select gas type The Gas option is selected in Select measured gas type.
Page 92 Commissioning Proline Promass H 300 PROFIBUS DP Navigation "Setup" menu → Communication ‣ Communication →  92 Device address Parameter overview with brief description Parameter Description User entry Factory setting Device address Enter device address. 0 to 126 Endress+Hauser...
Page 93: Configuring The Analog Inputs
Proline Promass H 300 PROFIBUS DP Commissioning 10.6.5 Configuring the analog inputs The Analog inputs submenu guides the user systematically to the individual Analog input 1 to n submenu. From here you get to the parameters of the individual analog input.
Page 94 Commissioning Proline Promass H 300 PROFIBUS DP Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Channel – Select the process variable. • Mass flow Mass flow • Volume flow • Corrected volume flow • Density • Reference density •...
Page 95: Displaying The I/O Configuration
Proline Promass H 300 PROFIBUS DP Commissioning Parameter Prerequisite Description Selection / User Factory setting entry Fail safe type – Select the failure mode. • Fail-safe value • Fallback value • Off Fail-safe value In Fail safe type parameter, Specify the values to be output...
Page 96: Configuring The Current Input
Commissioning Proline Promass H 300 PROFIBUS DP Parameter Description User interface / Selection / Factory setting User entry Apply I/O configuration Apply parameterization of the freely • No configurable I/O module. • Yes Alteration code Enter the code in order to change the I/O Positive integer configuration.
Page 97: Configuring The Status Input
Proline Promass H 300 PROFIBUS DP Commissioning Parameter Prerequisite Description User interface / Factory setting Selection / User entry Failure mode – Define input behavior in alarm • Alarm Alarm condition. • Last valid value • Defined value Failure value In the Failure mode...
Page 98: Configuring The Current Output
Commissioning Proline Promass H 300 PROFIBUS DP 10.6.9 Configuring the current output The Current output wizard guides you systematically through all the parameters that have to be set for configuring the current output. Navigation "Setup" menu → Current output ‣...
Page 99 Proline Promass H 300 PROFIBUS DP Commissioning Parameter Prerequisite Description User interface / Factory setting Selection / User entry Assign current output 1 to n – Select process variable for • Off Mass flow current output. • Mass flow • Volume flow • Corrected volume flow •...
Page 100 Commissioning Proline Promass H 300 PROFIBUS DP Parameter Prerequisite Description User interface / Factory setting Selection / User entry Damping output 1 to n A process variable is selected Set reaction time for output 0.0 to 999.9 s 1.0 s in the Assign current output signal to fluctuations in the parameter (→...
Page 101: 10.6.10 Configuring The Pulse/Frequency/Switch Output
Proline Promass H 300 PROFIBUS DP Commissioning 10.6.10 Configuring the pulse/frequency/switch output The Pulse/frequency/switch output wizard guides you systematically through all the parameters that can be set for configuring the selected output type. Navigation "Setup" menu → Advanced setup → Pulse/frequency/switch output ‣...
Page 102 Commissioning Proline Promass H 300 PROFIBUS DP Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting interface / User entry Operating mode – Define the output as a pulse, • Pulse Pulse frequency or switch output. • Frequency • Switch Terminal number –...
Page 103 Proline Promass H 300 PROFIBUS DP Commissioning Terminal number →  103 Signal mode →  103 Assign frequency output →  104 Minimum frequency value →  104 →  104 Maximum frequency value Measuring value at minimum →  104...
Page 104 Commissioning Proline Promass H 300 PROFIBUS DP Parameter Prerequisite Description Selection / User Factory setting interface / User entry Assign frequency output The Frequency option is Select process variable for • Off selected in the Operating frequency output. • Mass flow mode parameter (→  101) •...
Page 105 Proline Promass H 300 PROFIBUS DP Commissioning Parameter Prerequisite Description Selection / User Factory setting interface / User entry Measuring value at maximum The Frequency option is Enter measured value for Signed floating-point Depends on country frequency selected in the Operating maximum frequency. number and nominal mode parameter (→...
Page 106 Commissioning Proline Promass H 300 PROFIBUS DP Configuring the switch output Navigation "Setup" menu → Pulse/frequency/switch output ‣ Pulse/frequency/switch output 1 to n Operating mode →  106 Terminal number →  106 Signal mode →  106 →  107...
Page 107 Proline Promass H 300 PROFIBUS DP Commissioning Parameter Prerequisite Description Selection / User Factory setting interface / User entry Switch output function The Switch option is selected Select function for switch • Off in the Operating mode output. • On parameter. • Diagnostic behavior •...
Page 108: 10.6.11 Configuring The Relay Output
Commissioning Proline Promass H 300 PROFIBUS DP Parameter Prerequisite Description Selection / User Factory setting interface / User entry Switch-off value • In the Operating mode Enter measured value for the Signed floating-point Country-specific: parameter, the Switch switch-off point. number • 0 kg/h option is selected.
Page 109 Proline Promass H 300 PROFIBUS DP Commissioning Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting interface / User entry Relay output function – Select the function for the • Closed Closed relay output. • Open • Diagnostic behavior • Limit •...
Page 110: 10.6.12 Configuring The Local Display
Commissioning Proline Promass H 300 PROFIBUS DP Parameter Prerequisite Description Selection / User Factory setting interface / User entry Switch-on delay In the Relay output function Define delay for the switch-on 0.0 to 100.0 s 0.0 s parameter, the Limit option is of status output.
Page 111 Proline Promass H 300 PROFIBUS DP Commissioning Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Format display A local display is provided. Select how measured values • 1 value, max. size 1 value, max. size are shown on the display.
Page 112 Commissioning Proline Promass H 300 PROFIBUS DP Parameter Prerequisite Description Selection / User Factory setting entry Value 3 display A local display is provided. Select the measured value that For the picklist, see None is shown on the local display. the Value 1 display parameter (→...
Page 113: 10.6.13 Configuring The Low Flow Cut Off
Proline Promass H 300 PROFIBUS DP Commissioning 10.6.13 Configuring the low flow cut off The Low flow cut off wizard systematically guides the user through all the parameters that must be set to configure low flow cut off. Navigation "Setup" menu → Low flow cut off ‣...
Page 114: Configuring The Partial Filled Pipe
Commissioning Proline Promass H 300 PROFIBUS DP 10.6.14 Configuring the partial filled pipe detection The Partial filled pipe detection wizard guides you systematically through all parameters that have to be set for configuring the monitoring of the pipe filling. Navigation "Setup"...
Page 115: Advanced Settings
Proline Promass H 300 PROFIBUS DP Commissioning 10.7 Advanced settings The Advanced setup submenu together with its submenus contains parameters for specific settings. Navigation to the "Advanced setup" submenu X X X X X X X 20.50 0104-1 Main menu...
Page 116: Calculated Values
Commissioning Proline Promass H 300 PROFIBUS DP ‣ WLAN settings →  123 ‣ Concentration ‣ Heartbeat setup ‣ Configuration backup →  124 ‣ →  125 Administration 10.7.1 Calculated values The Calculated values submenu contains parameters for calculating the corrected volume flow.
Page 117: Carrying Out A Sensor Adjustment
Proline Promass H 300 PROFIBUS DP Commissioning Parameter Prerequisite Description Selection / User Factory setting interface / User entry Fixed reference density The Fixed reference density Enter fixed value for reference Positive floating- 1 kg/Nl option is selected in the density. point number Corrected volume flow calculation parameter parameter.
Page 118: Configuring The Totalizer
Commissioning Proline Promass H 300 PROFIBUS DP Navigation "Setup" menu → Advanced setup → Sensor adjustment → Zero point adjustment ‣ Zero point adjustment →  118 Zero point adjustment control →  118 Progress Parameter overview with brief description...
Page 119 Proline Promass H 300 PROFIBUS DP Commissioning Parameter overview with brief description Parameter Description Selection Factory setting Assign process variable Select process variable for totalizer. • Mass flow Mass flow • Volume flow • Corrected volume flow • Target mass flow •...
Page 120: Carrying Out Additional Display Configurations
Commissioning Proline Promass H 300 PROFIBUS DP 10.7.4 Carrying out additional display configurations In the Display submenu you can set all the parameters associated with the configuration of the local display. Navigation "Setup" menu → Advanced setup → Display ‣...
Page 121 Proline Promass H 300 PROFIBUS DP Commissioning Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Format display A local display is provided. Select how measured values • 1 value, max. size 1 value, max. size are shown on the display.
Page 122 Commissioning Proline Promass H 300 PROFIBUS DP Parameter Prerequisite Description Selection / User Factory setting entry Value 2 display A local display is provided. Select the measured value that For the picklist, see None is shown on the local display. the Value 1 display parameter (→...
Page 123: Wlan Configuration
Proline Promass H 300 PROFIBUS DP Commissioning Parameter Prerequisite Description Selection / User Factory setting entry Header text In the Header parameter, the Enter display header text. Max. 12 characters ------------ Free text option is selected. such as letters, numbers or special characters (e.g.
Page 124: Configuration Management
Commissioning Proline Promass H 300 PROFIBUS DP Parameter overview with brief description Parameter Prerequisite Description User entry / Factory setting Selection WLAN IP address – Enter IP address of the device 4 octet: 0 to 255 (in 192.168.1.212 WLAN interface. the particular octet) Network security –...
Page 125: Using Parameters For Device Administration
Proline Promass H 300 PROFIBUS DP Commissioning Backup state →  125 Comparison result →  125 Parameter overview with brief description Parameter Description User interface / Selection Factory setting Operating time Indicates how long the device has been in Days (d), hours (h), minutes –...
Page 126 Commissioning Proline Promass H 300 PROFIBUS DP Navigation "Setup" menu → Advanced setup → Administration ‣ Administration ‣ →  126 Define access code ‣ →  126 Reset access code Device reset →  127 Using the parameter to define the access code Navigation "Setup"...
Page 127: Simulation
Proline Promass H 300 PROFIBUS DP Commissioning Parameter overview with brief description Parameter Description User interface / User entry Factory setting Operating time Indicates how long the device has been in Days (d), hours (h), minutes – operation. (m) and seconds (s) Reset access code Reset access code to factory settings.
Page 128 Commissioning Proline Promass H 300 PROFIBUS DP Value current output 1 to n →  129 Frequency output simulation 1 to n →  129 Frequency value 1 to n →  129 Pulse output simulation 1 to n →  129 →...
Page 129 Proline Promass H 300 PROFIBUS DP Commissioning Parameter Prerequisite Description Selection / User Factory setting entry / User interface Input signal level In the Status input simulation Select the signal level for the • High High parameter, the On option is simulation of the status input.
Page 130: 10.9 Protecting Settings From Unauthorized
Commissioning Proline Promass H 300 PROFIBUS DP Parameter Prerequisite Description Selection / User Factory setting entry / User interface Diagnostic event simulation – Select a diagnostic event to • Off simulate this event. • Diagnostic event picklist (depends on the category selected) Logging interval –...
Page 131: Write Protection Via Write Protection
Via Web browser, FieldCare, DeviceCare (via CDI-RJ45 service interface), fieldbus For a reset code, contact your Endress+Hauser service organization. 1. Navigate to the Reset access code parameter (→  127). 2. Enter the reset code.
Page 132 Commissioning Proline Promass H 300 PROFIBUS DP A0029630 Setting the write protection (WP) switch on the main electronics module to the ON position enables hardware write protection.  In the Locking status parameter the Hardware locked option is displayed →  133. In addition, on the local display the -symbol appears in front of the parameters in the header of the operational display and in the navigation view.
Page 133: Operation
Proline Promass H 300 PROFIBUS DP Operation Operation 11.1 Reading the device locking status Device active write protection: Locking status parameter Operation → Locking status Function scope of the "Locking status" parameter Options Description None The access status displayed in the Access status parameter applies →  57. Only appears on local display.
Page 134: Measured Variables" Submenu
Operation Proline Promass H 300 PROFIBUS DP 11.4.1 "Measured variables" submenu The Measured variables submenu contains all the parameters needed to display the current measured values for each process variable. Navigation "Diagnostics" menu → Measured values → Measured variables ‣...
Page 135: Totalizer
Proline Promass H 300 PROFIBUS DP Operation Parameter Prerequisite Description User interface Reference density – Displays the reference density currently Signed floating-point calculated. number Dependency The unit is taken from the Reference density unit parameter (→  88). Temperature –...
Page 136: Input Values" Submenu
Operation Proline Promass H 300 PROFIBUS DP Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry / User interface Assign process variable – Select process variable for • Mass flow Mass flow totalizer. • Volume flow • Corrected volume flow •...
Page 137 Proline Promass H 300 PROFIBUS DP Operation Navigation "Diagnostics" menu → Measured values → Input values ‣ Input values ‣ →  137 Current input 1 to n ‣ →  137 Status input 1 to n Input values of current input The Current input 1 to n submenu contains all the parameters needed to display the current measured values for every current input.
Page 138: Output Values
Operation Proline Promass H 300 PROFIBUS DP 11.4.4 Output values The Output values submenu contains all the parameters needed to display the current measured values for every output. Navigation "Diagnostics" menu → Measured values → Output values ‣ Output values ‣...
Page 139 Proline Promass H 300 PROFIBUS DP Operation Navigation "Diagnostics" menu → Measured values → Output values → Pulse/frequency/switch output 1 to n ‣ Pulse/frequency/switch output 1 to n Output frequency 1 to n →  139 Pulse output 1 to n →...
Page 140: Adapting The Measuring Device To The Process
Operation Proline Promass H 300 PROFIBUS DP 11.5 Adapting the measuring device to the process conditions The following are available for this purpose: • Basic settings using theSetup menu (→  85) • Advanced settings using theAdvanced setup submenu (→  115) 11.6...
Page 141 Proline Promass H 300 PROFIBUS DP Operation Function range • A total of 1000 measured values can be stored • 4 logging channels • Adjustable logging interval for data logging • Display of the measured value trend for each logging channel in the form of a chart / ../XXXXXXXX...
Page 142 Operation Proline Promass H 300 PROFIBUS DP ‣ Display channel 3 ‣ Display channel 4 Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry / User interface Assign channel 1 The Extended HistoROM Assign process variable to • Off application package is logging channel.
Page 143 Proline Promass H 300 PROFIBUS DP Operation Parameter Prerequisite Description Selection / User Factory setting entry / User interface Assign channel 3 The Extended HistoROM Assign process variable to Picklist, see Assign application package is logging channel. channel 1 parameter available. (→  142) ...
Page 144: Diagnostics And Troubleshooting
Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting 12.1 General troubleshooting For local display Error Possible causes Solution Local display dark and no output Supply voltage does not match the Apply the correct supply voltage signals value indicated on the nameplate.
Page 145 Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting For access Error Possible causes Solution No write access to parameters Hardware write protection enabled Set the write protection switch on main electronics module to the OFF position →  131.
Page 146 Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP Error Possible causes Solution No or incomplete display of • JavaScript not enabled 1. Enable JavaScript. contents in the Web browser • JavaScript cannot be enabled 2. Enter http://XXX.XXX.X.XXX/ basic.html as the IP address.
Page 147: Diagnostic Information Via Light Emitting
Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting 12.2 Diagnostic information via light emitting diodes 12.2.1 Transmitter Different LEDs in the transmitter provide information on the device status. 1 2 3 4 5 A0029629 Supply voltage Device status Not used...
Page 148: Diagnostic Information On Local Display
Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP 12.3 Diagnostic information on local display 12.3.1 Diagnostic message Faults detected by the self-monitoring system of the measuring device are displayed as a diagnostic message in alternation with the operational display.
Page 149 Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting Diagnostic behavior Symbol Meaning Alarm • Measurement is interrupted. • Signal outputs and totalizers assume the defined alarm condition. • A diagnostic message is generated. Warning Measurement is resumed. The signal outputs and totalizers are not affected. A diagnostic message is generated.
Page 150: Calling Up Remedial Measures
Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP 12.3.2 Calling up remedial measures X X X X X X X X X X X X X X 20.50 S801 Supply voltage Menu Diagnostic list Diagnostics 1 S801 Supply voltage...
Page 151: Calling Up Remedy Information
Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting A0031056 Status area with status signal Diagnostic information→  149 Remedy information with Service ID In addition, diagnostic events which have occurred can be shown in the Diagnostics menu: • Via parameter •...
Page 152: Calling Up Remedy Information
Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP Xxxxxx/…/…/ Device name: Xxxxxxx Mass flow: kg/h 12.34 Device tag: Xxxxxxx Volume flow: 12.34 m /h ³ Status signal: Function check (C) Xxxxxx Diagnostics 1: C485 Simu... Remedy information: Deactivate... Failure (F)
Page 153: Adapting The Diagnostic Information
Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting The user is in the Diagnostics menu. 1. Call up the desired parameter. 2. On the right in the working area, mouse over the parameter.  A tool tip with remedy information for the diagnostic event appears.
Page 154 Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP Coding Measuring value (hex) Byte 5 Quality Quality Substatus Limits A0032228-EN  27 Structure of the coding byte The content of the coding byte depends on the configured failsafe mode in the particular function block.
Page 155 Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information pertaining to the electronics: diagnostic number 200 to 399 Diagnostic number 200 to 301, 303 to 399 Measured value status (fixed assignment) Diagnostic behavior Device diagnosis Quality Coding Category...
Page 156: Overview Of Diagnostic Information
Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP 12.7 Overview of diagnostic information The amount of diagnostic information and the number of measured variables affected increase if the measuring device has one or more application packages. In the case of some items of diagnostic information, the diagnostic behavior can be changed.
Page 157 Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 046 Sensor limit exceeded 1. Inspect sensor 2. Check process condition Measured variable status [from the factory] Quality Good Quality substatus Maintenance demanded Coding (hex)
Page 158 Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP Diagnostic information Remedy instructions Short text 062 Sensor connection faulty 1. Check or replace sensor electronic module (ISEM) 2. If available: Check connection cable between sensor and transmitter Measured variable status 3.
Page 159 Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 082 Data storage 1. Check module connections 2. Contact service Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27 Status signal...
Page 160 Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP Diagnostic information Remedy instructions Short text 083 Memory content 1. Restart device 2. Restore HistoROM S-DAT backup (' D evice reset' parameter) Measured variable status 3. Replace HistoROM S-DAT Quality Quality substatus...
Page 161 Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 140 Sensor signal asymmetrical 1. Check or replace sensor electronic module (ISEM) 2. If available: Check connection cable between sensor and transmitter Measured variable status [from the factory] 3.
Page 162 Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP Diagnostic information Remedy instructions Short text 144 Measuring error too high 1. Check or change sensor 2. Check process conditions Measured variable status [from the factory] Quality Quality substatus Maintenance alarm...
Page 163: Diagnostic Of Electronic
Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting 12.7.2 Diagnostic of electronic Diagnostic information Remedy instructions Short text 201 Device failure 1. Restart device 2. Contact service Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27...
Page 164 Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP Diagnostic information Remedy instructions Short text 242 Software incompatible 1. Check software 2. Flash or change main electronics module Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27...
Page 165 Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 252 Modules incompatible 1. Check electronic modules 2. Check if correct modules are available (e.g. NEx, Ex) Measured variable status 3. Replace electronic modules Quality...
Page 166 Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP Diagnostic information Remedy instructions Short text 262 Sensor electronic connection faulty 1. Check or replace connection cable between sensor electronic module (ISEM) and main electronics Measured variable status 2. Check or replace ISEM or main electronics...
Page 167 Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 270 Main electronic failure Change main electronic module Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27 Status signal Diagnostic behavior...
Page 168 Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP Diagnostic information Remedy instructions Short text 271 Main electronic failure 1. Restart device 2. Change main electronic module Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27...
Page 169 Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 272 Main electronic failure 1. Restart device 2. Contact service Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27 Status signal...
Page 170 Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP Diagnostic information Remedy instructions Short text 273 Main electronic failure Change electronic Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27 Status signal Diagnostic behavior Alarm Influenced measured variables •...
Page 171 Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 276 I/O module 1 to n faulty 1. Restart device 2. Change I/O module Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27...
Page 172 Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP Diagnostic information Remedy instructions Short text 302 Device verification active Device verification active, please wait. Measured variable status Quality Good Quality substatus Function check Coding (hex) 0xBC to 0xBF Status signal...
Page 173 Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 311 Electronic failure 1. Do not reset device 2. Contact service Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27 Status signal...
Page 174 Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP Diagnostic information Remedy instructions Short text 332 Writing in HistoROM backup failed Replace user interface board Ex d/XP: replace transmitter Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27...
Page 175 Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 372 Sensor electronic (ISEM) faulty 1. Restart device 2. Check if failure recurs Measured variable status 3. Replace sensor electronic module (ISEM) Quality Quality substatus...
Page 176 Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP Diagnostic information Remedy instructions Short text 373 Sensor electronic (ISEM) faulty 1. Transfer data or reset device 2. Contact service Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27...
Page 177 Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 375 I/O- 1 to n communication failed 1. Restart device 2. Check if failure recurs Measured variable status 3. Replace module rack inclusive electronic modules...
Page 178 Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP Diagnostic information Remedy instructions Short text 382 Data storage 1. Insert T-DAT 2. Replace T-DAT Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27 Status signal Diagnostic behavior...
Page 179 Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 383 Memory content 1. Restart device 2. Delete T-DAT via ' R eset device' parameter Measured variable status 3. Replace T-DAT Quality Quality substatus Maintenance alarm...
Page 180: Diagnostic Of Configuration
Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP Diagnostic information Remedy instructions Short text 387 HistoROM backup failed Contact service organization Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27 Status signal Diagnostic behavior Alarm Influenced measured variables •...
Page 181 Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 331 Firmware update failed 1. Update firmware of device 2. Restart device Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27...
Page 182 Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP Diagnostic information Remedy instructions Short text 410 Data transfer 1. Check connection 2. Retry data transfer Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27 Status signal...
Page 183 Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 412 Processing download Download active, please wait Measured variable status Quality Uncertain Quality substatus Initial value Coding (hex) 0x4C to 0x4F Status signal Diagnostic behavior...
Page 184 Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP Diagnostic information Remedy instructions Short text 437 Configuration incompatible 1. Restart device 2. Contact service Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27 Status signal Diagnostic behavior...
Page 185 Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 438 Dataset 1. Check data set file 2. Check device configuration Measured variable status 3. Up- and download new configuration Quality Uncertain Quality substatus Maintenance demanded...
Page 186 Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP Diagnostic information Remedy instructions Short text 442 Frequency output 1 to n 1. Check process 2. Check frequency output settings Measured variable status [from the factory] Quality Good Quality substatus Function check...
Page 187 Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 453 Flow override Deactivate flow override Measured variable status Quality Good Quality substatus Function check Coding (hex) 0xBC to 0xBF Status signal Diagnostic behavior Warning Influenced measured variables •...
Page 188 Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP Diagnostic information Remedy instructions Short text 482 FB not Auto/Cas Set Block in AUTO mode Measured variable status Quality Good Quality substatus Coding (hex) 0x80 to 0x83 Status signal Diagnostic behavior...
Page 189 Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 485 Measured variable simulation Deactivate simulation Measured variable status Quality Good Quality substatus Function check Coding (hex) 0xBC to 0xBF Status signal Diagnostic behavior Warning Influenced measured variables •...
Page 190 Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP Diagnostic information Remedy instructions Short text 491 Current output 1 to n simulation Deactivate simulation Measured variable status Quality Good Quality substatus Function check Coding (hex) 0xBC to 0xBF Status signal...
Page 191 Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 494 Switch output simulation 1 to n Deactivate simulation switch output Measured variable status Quality Good Quality substatus Function check Coding (hex) 0xBC to 0xBF...
Page 192 Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP Diagnostic information Remedy instructions Short text 497 Simulation block output Deactivate simulation Measured variable status Quality Good Quality substatus Coding (hex) 0x80 to 0x83 Status signal Diagnostic behavior Warning Influenced measured variables –...
Page 193 Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 529 Concentration settings faulty 1. Check concentration settings 2. Check input values e.g. pressure, temperature Measured variable status Quality Quality substatus Function check Coding (hex)
Page 194: Diagnostic Of Process
Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP 12.7.4 Diagnostic of process Diagnostic information Remedy instructions Short text 803 Current loop 1. Check wiring 2. Change I/O module Measured variable status Quality Quality substatus Process related Coding (hex) 0x28 to 0x2B...
Page 195 Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 831 Sensor temperature too low Increase ambient temp. around the sensor housing Measured variable status [from the factory] Quality Uncertain Quality substatus Process related Coding (hex)
Page 196 Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP Diagnostic information Remedy instructions Short text 832 Electronic temperature too high Reduce ambient temperature Measured variable status [from the factory] Quality Quality substatus Process related Coding (hex) 0x28 to 0x2B Status signal...
Page 197 Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 833 Electronic temperature too low Increase ambient temperature Measured variable status [from the factory] Quality Quality substatus Process related Coding (hex) 0x28 to 0x2B Status signal...
Page 198 Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP Diagnostic information Remedy instructions Short text 834 Process temperature too high Reduce process temperature Measured variable status [from the factory] Quality Uncertain Quality substatus Process related Coding (hex) 0x78 to 0x7B...
Page 199 Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 835 Process temperature too low Increase process temperature Measured variable status [from the factory] Quality Uncertain Quality substatus Process related Coding (hex) 0x78 to 0x7B...
Page 200 Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP Diagnostic information Remedy instructions Short text 842 Process limit Low flow cut off active! 1. Check low flow cut off configuration Measured variable status [from the factory] Quality Uncertain Quality substatus...
Page 201 Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 882 Input signal 1. Check input configuration 2. Check external device or process conditions Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27...
Page 202 Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP Diagnostic information Remedy instructions Short text 910 Tubes not oscillating 1. Check electronic 2. Inspect sensor Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27 Status signal...
Page 203 Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 912 Medium inhomogeneous 1. Check process cond. 2. Increase system pressure Measured variable status [from the factory] Quality Uncertain Quality substatus Process related Coding (hex)
Page 204 Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP Diagnostic information Remedy instructions Short text 913 Medium unsuitable 1. Check process conditions 2. Check electronic modules or sensor Measured variable status [from the factory] Quality Uncertain Quality substatus Process related...
Page 205 Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 942 API density out of specification 1. Check process density with selected API commodity group 2. Check API related parameters Measured variable status Quality Quality substatus...
Page 206 Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP Diagnostic information Remedy instructions Short text 944 Monitoring failed Check process conditions for Heartbeat Monitoring Measured variable status [from the factory] Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27...
Page 207: Pending Diagnostic Events
Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting 12.8 Pending diagnostic events The Diagnostics menu allows the user to view the current diagnostic event and the previous diagnostic event separately. To call up the measures to rectify a diagnostic event: •...
Page 208: Event Logbook
Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP / ../Diagnose list Diagnostics F273 Main electronic Diagnostics 2 Diagnostics 3 A0014006-EN  28 Taking the example of the local display To call up the measures to rectify a diagnostic event: •...
Page 209: 12.10.2 Filtering The Event Logbook
Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting 12.10.2 Filtering the event logbook Using the Filter options parameter you can define which category of event message is displayed in the Events list submenu. Navigation path Diagnostics → Event logbook → Filter options Filter categories •...
Page 210: 12.11 Resetting The Measuring Device
Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP Info number Info name I1451 Monitoring on I1457 Measured error verification failed I1459 I/O module verification failed I1460 HBSI verification failed I1461 Sensor verification failed I1462 Sensor electronic module verific. failed...
Page 211: 12.11.1 Function Scope Of The "Device Reset" Parameter
Proline Promass H 300 PROFIBUS DP Diagnostics and troubleshooting 12.11.1 Function scope of the "Device reset" parameter Options Description Cancel No action is executed and the user exits the parameter. To delivery settings Every parameter for which a customer-specific default setting was ordered is reset to this customer-specific value.
Page 212 Diagnostics and troubleshooting Proline Promass H 300 PROFIBUS DP Parameter overview with brief description Parameter Description User interface Factory setting Device tag Shows name of measuring point. Max. 32 characters, such as Promass_300 letters, numbers or special characters (e.g. @, %, /).
Page 213: 12.13 Firmware History
"Manufacturer' s information" document. The manufacturer' s information is available: • In the Download Area of the Endress+Hauser web site: www.endress.com → Downloads • Specify the following details: –...
Page 214: Maintenance
13.2 Measuring and test equipment Endress+Hauser offers a wide variety of measuring and test equipment, such as W@M or device tests. Your Endress+Hauser Sales Center can provide detailed information on the services.
Page 215: Repairs
• The measuring devices have a modular design. • Spare parts are grouped into logical kits with the associated Installation Instructions. • Repairs are carried out by Endress+Hauser Service or by appropriately trained customers. • Certified devices can only be converted to other certified devices by Endress+Hauser Service or at the factory.
Page 216: Disposal
Repairs Proline Promass H 300 PROFIBUS DP 14.5 Disposal 14.5.1 Removing the measuring device 1. Switch off the device. WARNING Danger to persons from process conditions. ‣ Beware of hazardous process conditions such as pressure in the measuring device, high temperatures or aggressive fluids.
Page 217: Accessories
Various accessories, which can be ordered with the device or subsequently from Endress +Hauser, are available for the device. Detailed information on the order code in question is available from your local Endress+Hauser sales center or on the product page of the Endress+Hauser website: www.endress.com.
Page 218: For The Sensor
Is used to stabilize the temperature of the fluids in the sensor. Water, water vapor and other non-corrosive liquids are permitted for use as fluids.  If using oil as a heating medium, please consult with Endress+Hauser.  Special Documentation SD02157D 15.2...
Page 219 Proline Promass H 300 PROFIBUS DP Accessories Accessories Description Cerabar S The pressure transmitter for measuring the absolute and gauge pressure of gases, steam and liquids. It can be used to read in the operating pressure value.  • Technical Information TI00383P •...
Page 220: Technical Data
Technical data Proline Promass H 300 PROFIBUS DP Technical data 16.1 Application The measuring device is suitable for flow measurement of liquids and gases only. Depending on the version ordered, the measuring device can also measure potentially explosive, flammable, poisonous and oxidizing media.
Page 221: Input
Proline Promass H 300 PROFIBUS DP Technical data 16.3 Input Measured variable Direct measured variables • Mass flow • Density • Temperature Calculated measured variables • Volume flow • Corrected volume flow • Reference density Measuring range Measuring ranges for liquids Measuring range full scale values ...
Page 222 • Operating pressure to increase accuracy (Endress+Hauser recommends the use of a pressure measuring device for absolute pressure, e.g. Cerabar M or Cerabar S) •...
Page 223: Output
Proline Promass H 300 PROFIBUS DP Technical data 16.4 Output Output signal PROFIBUS DP Signal encoding NRZ code Data transfer 9.6 kBaud…12 MBaud Current output 0/4 to 20 mA Current output 0/4 to 20 mA Maximum output values 22.5 mA...
Page 224 Technical data Proline Promass H 300 PROFIBUS DP Maximum pulse rate 10 000 Impulse/s Pulse value Adjustable Assignable measured • Mass flow variables • Volume flow • Corrected volume flow Frequency output Maximum input values DC 30 V, 250 mA (passive) Maximum output current 22.5 mA (active)
Page 225 Proline Promass H 300 PROFIBUS DP Technical data Switching behavior Can be set to: • NO (normally open), factory setting • NC (normally closed) Maximum switching • DC 30 V, 0.1 A capacity (passive) • AC 30 V, 0.5 A Assignable functions •...
Page 226 Technical data Proline Promass H 300 PROFIBUS DP 0 to 20 mA Failure mode Choose from: • Maximum alarm: 22 mA • Freely definable value between: 0 to 20.5 mA Pulse/frequency/switch output Pulse output Failure mode Choose from: • Actual value •...
Page 227: Power Supply
Proline Promass H 300 PROFIBUS DP Technical data Light emitting diodes (LED) Status information Status indicated by various light emitting diodes The following information is displayed depending on the device version: • Supply voltage active • Data transmission active • Device alarm/error has occurred ...
Page 228: Performance Characteristics
Technical data Proline Promass H 300 PROFIBUS DP Current consumption Transmitter • Max. 400 mA (24 V) • Max. 200 mA (110 V, 50/60 Hz; 230 V, 50/60 Hz) Power supply failure Depending on the device version, the configuration is retained in the device memoryor in the pluggable data memory (HistoROM DAT).
Page 229 Proline Promass H 300 PROFIBUS DP Technical data Density (liquids) Under Standard density Wide-range 2) 3) reference operating conditions calibration Density specification [g/cm³] [g/cm³] [g/cm³] ±0.0005 ±0.02 ±0.002 Valid over the entire temperature and density range Valid range for special density calibration: 0 to 2 g/cm³, +10 to +80 °C (+50 to +176 °F) Order code for "Application package", option EE "Special density"...
Page 230 Technical data Proline Promass H 300 PROFIBUS DP Accuracy of outputs The outputs have the following base accuracy specifications. Current output Accuracy ±5 µA Pulse/frequency output o.r. = of reading Accuracy Max. ±50 ppm o.r. (over the entire ambient temperature range) Repeatability o.r.
Page 231 Proline Promass H 300 PROFIBUS DP Technical data Density When there is a difference between the density calibration temperature and the process temperature, the typical measured error of the sensor is ±0.0001 g/cm /°C (±0.00005 g/cm /°F). Field density calibration is possible.
Page 232: Installation
Technical data Proline Promass H 300 PROFIBUS DP MeasValue = measured value; ZeroPoint = zero point stability Calculation of the maximum measured error as a function of the flow rate Flow rate Maximum measured error in % o.r. ZeroPoint ⋅...
Page 233 Proline Promass H 300 PROFIBUS DP Technical data Climate class DIN EN 60068-2-38 (test Z/AD) Degree of protection Measuring device • As standard: IP66/67, type 4X enclosure • When housing is open: IP20, type 1 enclosure • Display module: IP20, type 1 enclosure...
Page 234 Technical data Proline Promass H 300 PROFIBUS DP Dependency of ambient temperature on medium temperature A0031121  30 Exemplary representation, values in the table below. Ambient temperature Medium temperature Maximum permitted medium temperature T at T = 60 °C (140 °F); higher medium temperatures T...
Page 235 Proline Promass H 300 PROFIBUS DP Technical data Sensor housing nominal pressure rating and burst pressure The following sensor housing nominal pressure ratings/burst pressures are only valid for standard devices and/or devices equipped with closed purge connections (not opened/as delivered).
Page 236: Mechanical Construction
Technical data Proline Promass H 300 PROFIBUS DP 16.10 Mechanical construction Design, dimensions For the dimensions and installation lengths of the device, see the "Technical Information" document, "Mechanical construction" section. Weight All values (weight exclusive of packaging material) refer to devices with EN/DIN PN 40 flanges.
Page 237 Proline Promass H 300 PROFIBUS DP Technical data Cable entries/cable glands A0020640  31 Possible cable entries/cable glands Female thread M20 × 1.5 Cable gland M20 × 1.5 Adapter for cable entry with internal thread G ½" or NPT ½"...
Page 238: Operability
Technical data Proline Promass H 300 PROFIBUS DP Process connections • Stainless steel, 1.4301 (304); wetted parts: zirconium 702, tantalum • Flanges according to EN 1092-1 (DIN 2501) / according to ASME B16.5 / according to JIS B2220 Available process connections→  238...
Page 239 Proline Promass H 300 PROFIBUS DP Technical data Local operation Via display module Two display modules are available: • Order code for "Display; operation", option F "4-line, illuminated, graphic display; touch control" • Order code for "Display; operation", option G "4-line, illuminated, graphic display; touch control + WLAN"...
Page 240 Technical data Proline Promass H 300 PROFIBUS DP A0026786  33 Operation via remote display and operating module DKX001 Display and operating elements The display and operating elements correspond to those of the display module →  239. Material The housing material of the display and operating module DKX001 depends on the choice of transmitter housing material.
Page 241 Proline Promass H 300 PROFIBUS DP Technical data Supported operating Operating unit Interface Additional information tools Web browser Notebook, PC or tablet • CDI-RJ45 service Special Documentation for with Web browser interface device →  247 • WLAN interface DeviceCare SFE100 Notebook, PC or tablet •...
Page 242 Technical data Proline Promass H 300 PROFIBUS DP HistoROM The measuring device features HistoROM data management. HistoROM data management data management comprises both the storage and import/export of key device and process data, making operation and servicing far more reliable, secure and efficient.
Page 243: Certificates And Approvals
The device meets the legal requirements of the applicable EU Directives. These are listed in the corresponding EU Declaration of Conformity along with the standards applied. Endress+Hauser confirms successful testing of the device by affixing to it the CE mark. C-Tick symbol The measuring system meets the EMC requirements of the "Australian Communications...
Page 244 • With the identification PED/G1/x (x = category) on the sensor nameplate, Directive Endress+Hauser confirms conformity with the "Essential Safety Requirements" specified in Appendix I of the Pressure Equipment Directive 2014/68/EU. • Devices not bearing this marking (PED) are designed and manufactured according to good engineering practice.
Page 245 The application packages can be ordered with the device or subsequently from Endress+Hauser. Detailed information on the order code in question is available from your local Endress+Hauser sales center or on the product page of the Endress+Hauser website: www.endress.com.
Page 246: Accessories
For an overview of the scope of the associated Technical Documentation, refer to the following: • W@M Device Viewer (www.endress.com/deviceviewer): Enter the serial number from nameplate • Endress+Hauser Operations App: Enter the serial number from the nameplate or scan the 2D matrix code (QR code) on the nameplate Standard documentation Brief Operating Instructions...
Page 247 Proline Promass H 300 PROFIBUS DP Technical data Device-dependent Safety instructions additional documentation Safety instructions for electrical equipment for hazardous areas. Contents Documentation code ATEX/IECEx Ex d/Ex de XA01405D ATEX/IECEx Ex ec XA01439D cCSAus XP XA01373D cCSAus Ex d/ Ex de...
Page 248: Index
Index Proline Promass H 300 PROFIBUS DP Index About this document ......6 Declaration of Conformity ..... 10 Access authorization to parameters Define access code .
Page 249 Proline Promass H 300 PROFIBUS DP Index Document Functions Function ....... . 6 see Parameters Symbols used .
Page 250 Index Proline Promass H 300 PROFIBUS DP Measuring and test equipment ....214 Operable flow range ......222 Measuring device Operating elements .
Page 251 Proline Promass H 300 PROFIBUS DP Index Status input (Submenu) ....97 Administration ......125 Status input 1 to n (Submenu) .
Page 252 Index Proline Promass H 300 PROFIBUS DP I/O configuration ......95 Tools Input values ......136 Electrical connection .
Page 253 Proline Promass H 300 PROFIBUS DP Index Write protection Via access code ......130 Via write protection switch ....131 Write protection switch .
Page 254 www.addresses.endress.com...

Endress+Hauser Proline Promass H 300 PROFIBUS DP Operating Instructions Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Endress+Hauser Proline Promass H 300 PROFIBUS DP

Summary of Contents for Endress+Hauser Proline Promass H 300 PROFIBUS DP

Table of Contents
