STANDARD INSTALLATION MANUAL
NORDICCO
ENGLISH
1
Vers. 1.0
NORTHERN LIGHT HVLS
®
This system is equipped with UV-lamps and if not used and installed
correctly it can be harmful to people and animals.
Installation and calibration of the Northern Light systems is to be
done by professional and trained installers only. Calibration and in-
spection of the installed systems is recommended every 6 months as
a minimum.
NEVER LOOK DIRECTLY INTO THE LUMINAIRES.
IMPORTANT
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for NORDICCO NORTHERN LIGHT HVLS
Summary of Contents for NORDICCO NORTHERN LIGHT HVLS
- Page 1 STANDARD INSTALLATION MANUAL NORDICCO NORTHERN LIGHT HVLS ® ENGLISH IMPORTANT This system is equipped with UV-lamps and if not used and installed correctly it can be harmful to people and animals. Installation and calibration of the Northern Light systems is to be done by professional and trained installers only.
- Page 2 SULT IN DAMAGE OR INJURY. THE PURPOSE OF THIS INSTALLATION AND COMISSIONING MANUAL IS TO ENSURE, THAT THE NORDICCO NORTHERN LIGHT HVLS FANS ARE CORRECTLY INSTALLED, AND THAT THE UVC IRRADITION LEVEL IS CORRECTLY CALIBRATED AND BELOW ALL LEVELS ALLOWED BY LOCAL LAWS AND GUIDELINES PRIOR TO HUMAN OCCUPANCY.
-
Page 3: Table Of Contents
HAVE A NEED TO KNOW. Other manuals, such as Advanced User Guides for setting up fan networking mode and integrating fans to a building management system - as well as manuals in other languages can be downloaded from our website: www.nordicco.eu/ downloads... -
Page 4: General Safety Information, Pre-Installation Checks
5. Depending on local requirements an emergency disconnect switch is to be installed between each NORDICCO fans and the electrical mains. Ensure that such a switch is NOT located directly above the air blades, so that it can be accessed at all times - regardsless of local requirements it is always recommended to install an emergency disconnect switch. - Page 5 8. BEFORE INSTALLATION, IT IS IMPORTANT TO VERIFY THE MOUNTING SURFACE WILL BEAR THE OPERATING WEIGHT AND MAXIMUM TORQUE (TWISTING FORCE) OF THE TO-BE-INSTALLED NORDICCO SYSTEM. IT IS THE SOLE RESPONSIBILITY OF THE INSTALL- ER TO ENSURE THAT THE MOUNTING STRUCTURE AND FAN INSTALLATION METHOD ARE ADEQUATE FOR SAFE OPERATION OF THE NORDICCO FAN.
-
Page 6: Precautions & Best Practice In Relation To Fire
Fire and Security Technology) have prepared this guide to ensure optimal installation of NOR- DICCO HVLS fans. It is DBI's assessment that NORDICCO HVLS fans can be installed while main- taining fire safety. However, it should be noted that the smaller the rotor diameter of the HVLS fan, the less the risk of fire spreading. - Page 7 Scenario 3: NORDICCO HVLS fans installed in a room where a Fire Sprinkler system is in- stalled. HVLS fans can be installed in such rooms, but it must be taken into account that the Fire Sprinkler system must be able to be activated by a fire in the room. The points in scenario 1...
-
Page 8: What's In The Box
what’s in the box? Swivel Mount Drop Tube Drive and Onboard Electronics Motor Controller (if ordered) Starfish Blade Hub 1,5m Patch Cable with RJ45 Plug 3m (3 x 1,5 mm ) 230V power cable Fire alarm cable Mount Cover (if ordered) Safety Wire Safetywire Lock (Gripple) 2 x Extension Tubes... - Page 9 UVC-irradiation dampers Reduction percentage with different dampers Anodized Aluminum SCREWS FOR MOUNTING AIR Air Blades with UVC BLADES system 10 pcs. 6x16 mm. 10 lock washers Required screws and bolts NO DRILL BIT NEEDED...
-
Page 10: Required Tools & Accessories, Standard Mounting
SCREWDRIVER SCREWDRIVER STANDARD MOunting Using the swivel mount, the NORDICCO FAN SYSTEM can be mounted directly on to standard I and H steel beams, wood beams and concrete beams. This is done using relevant bolts and screws as shown on page 8 and explained on page 11. -
Page 11: Standard Installation Process
SURFACE, YOU CAN USE EXTRA MOUNTING BRACKETS AS EXPLAINED IN ‘INSTALLATION MANUAL - EXTRA MOUNTING OPTIONS’. AVAILABLE ON WWW.NORDICCO.EU/DOWN- LOADS Secure safety wire around mounting Push the mount cover up and twist to beam. lock in place by the two small screws as IMPORTANT: follow steps on page 12. -
Page 12: Mounting & Securing Safety Wire
Tighten wire. Cut or organize excess wire to ensure it does not interfere with fan performance. NOTE: THE SAFETY WIRE MUST BE INSTALLED AS IT PREVENTS THE NORDICCO HVLS FAN FROM FALLING IN THE UNLIKELY EVENT THAT THE MOUNTING SYSTEM SHOULD FAIL. -
Page 13: Mounting The Air Blades
Mounting the air blades NOTE: Before mounting the air blades, ensure the fan is vertically and horizontally level. IMPORTANT: Do not operate the fan without the air blades mounted, as this may damage the motor and the motor drive. Slide air blade onto the starfish hub Secure air blade using screws and tools Ensure that the system is fully powered off before proceeding. -
Page 14: Fire Alarm Relay Installation
FIRE ALARM RELAY INSTALLATION Pre-wired fire alarm landing point 24 VDC N.C. To landingpoint at fan Relay OPTIONAL FIRE ALARM RELAY INSTALLATION Note: This section is only applicable in buildings equipped with a fire suppression system. For buildings without a fire suppression system, simply leave the fire cable untouched in the droptube. Important: The fire alarm relay should only be installed by qualified personnel familiar with the operation of building fire suppression systems. -
Page 15: Connecting Power & Controller
Fan Management System, then please refer to the NORDICCO Fan Management System installation guide available on www.nordicco.eu/downloads. If you control and monitor the installed NORDICCO HVLS fans using a building ma- nagement system (CTS), then please refer to the integration to the building manage-... -
Page 16: Assement Of Uvc-Irradiation
Reduction percentage with different dampers Using UVC-irradition measuring tools such as the SAFETEST suggested abo- ve (available from NORDICCO upon request) the UVC-irradiation levels are measured in accordance with the equipment providers´ instructions and at several locations across the specific room. In the event UVC-irradiation levels are above usage or local requirement, use the supplied "UVC-irradiation... -
Page 17: Technical Specifications
TECHNICAL SPECIFICATIONS EN version 1.0 NORTHERN LIGHT NORTHERN LIGHT NORTHERN LIGHT NORTHERN LIGHT PRODUCT NUMBER System Diameter (m) Voltage (V) System hanging weight (kg) Effective coverage area (m2) Recommended distance between systems (m) System Diameter Load Level 100% Speed (RPM) m3/hr * 23.400 18.720... -
Page 18: Electrical Diagram
ELECTRICAL DIAGRAM... -
Page 19: Declaration Of Conformity
DECLARATION OF CONFORMITY March 17 2021 Dennis Thomsen... - Page 20 CLIMATE-FRIENDLY COMFORT NORDICCO A/S We are a family owned and operated company, wanting to contribute towards the acceleration to a more sustainable economy. We design and manufacture climate-friendly High Volume Low Speed (HVLS) fan based ventilation and desinfection systems. Our solutions help our customers improve...
