TAPE MECHANISM SECTION

Perform steps 1, 2, 3. 4, 5, 6, and 7 of the disassembly method
to remove the tape mechanism.
How to remove the main, FF/rewind belt (See
Fig. 13-1.)
1. Remove the Mann belt, (Al) x 1 PC., at the tape 2 side from
the motor pulley.
2. Remove the main belt, (A2) x 1 pc.,at the tape 1 side from the
motor pulley.
3. Remove the FF/Rewlnd belt, (A3) x 1 PC., from the tlywheel
of tape 2.
4. Put on the belts in the reverse order of removal.
Note:
1. When putiing on the belt, ascertain that the belt is not busted,
and clean It.
How to remove the T2 motor (See Fig. 13-2.)
2. Remove the screws, (82) x 2 PCS., and remove the motor.
How to remove the Tl motor (See Fig. 13-2.)
2. Remove the screws, (84) x3 pcs.,and remove the motor.
Note:
2. When the motor is removedShe belt comes off Put it on,
How to remove the flywheel of tape 1 side (See
Fig. 13-3.)
2. Remove the washers, (Cl),(C3) and the stop wasper, (C2)
with a small precision screwdriver to extract the flywheel from
the chassis.
How to remove the flywheel of tape 2 side. (See
Fig. 1' 3-2 and 13-3.)
1. Remove the drive belt.
2. Remove the screws, (83) x 2 PCS., and remove the motor
fixture.
3. Remove the stop washer, (C4) with a small precision screw-
driver to extract the flywheel from the chassis.
Note:
with a new one.
How to remove the pinch roller of tape 1 side
(See Fig.l4-1.)
1. Remove the stop washer, (Dl) with a small precision
screwdriver, and remove the pinch roller.
How to remove the pinch roller of tape 2 side
(See Fig. 14-l.)
1. Carefully release the pinch roller hook in the directIon
indicated by the arrow mark, and remove the pinch roller.
How to remove the playback head (See Fig.
14-2.)
1. Remove the screws, (El) x 2 PCS., and remove the button
block.
2. Remove the screws, (EZ),(E3), and remove the head.
How to remove the record/playback and
Figure 13-l
erase heads (See Fig. 14-2)
1 . R e m o v e t h e screws,(E4).(E5),and r e m o v e t h e
record/playback head.
2. Removethescrews, (E6)xZpcqandremovetheerase
Be sure to apply screw lock after replacement of head and
azimuth adjustment.
Figure 13-2
Figure 13-3
Figure 14-1
head.
Figure 14-2
