  • Page 1 Rack Zubehör TV Toebehoren TV Accessories TV Accessoires TV Accessori TV Accesorios TV Rack 165.30 Rack 165.45 CS Rack 165.45 SP Montageanleitung, Montage-instructies, Installation instructions, Instructions de montage, Istruzioni di montaggio, Instrucciones de montaje...
  • Page 2 Rack 165.30 Art. Nr. 51487xxx Rack 165.45 CS Art. Nr. 51488xxx Rack 165.45 SP Art. Nr. 51489xxx Deutschland Printed in Germany CH 10.12 Loewe Opta GmbH Customer Care Center Änderungen vorbehalten. Industriestraße 11 Wijzigingen voorbehouden. D-96305 Kronach Subject to modi cations.
  • Page 3: Table Of Contents

    Rack 165.45 CS con Center Speaker ...... 28 Rack 165.45 CS con Center Speaker ...... 28 Rack 165.45 SP ............. 29 Rack 165.45 SP ............. 29 Rack 165.30 SP ............. 29 Câblage du rack ............. 30 Cablaggio del rack ..........30 Cableado del Rack ..........30 Nettoyage et entretien ...........
  • Page 4: Sicherheitshinweise

    Rack - 4 - Montageanleitung Instructions de montage Montage-instructies Istruzioni di montaggio Installation instructions Instrucciones de montaje Sicherheitshinweise Veiligheidsvoorschriften Safety Instructions Beachten Sie die Informationen dieser Anleitung. Neem de aanwijzingen in de handleiding in See the information in the manual. acht.
  • Page 5 Rack - 5 - Montageanleitung Instructions de montage Montage-instructies Istruzioni di montaggio Installation instructions Instrucciones de montaje Sicherheitshinweise Veiligheidsvoorschriften Safety Instructions Transportieren Sie das Rack nicht mit der Front Transporteer het rack nooit met het front naar be- Do not move the rack with the front facing nach unten.
  • Page 6: Zuordnung: Adapter Zu Tv-Gerät

    Sie unter folgender Adresse herunterladen: volgende adres: address: ftp://ftp.loewe.de/Assembly_Instructions/ ftp://ftp.loewe.de/Assembly_Instructions/ ftp://ftp.loewe.de/Assembly_Instructions/ .../51487T00_Rack 165.30 .../51487T00_Rack 165.30 .../51487T00_Rack 165.30 De plus, des téléviseurs plua anciens peuvent également Sul rack è possibile montare anche apparecchi TV più También pueden montarse televisores más antiguos en être montés sur le rack (voir tableau en dessous).
  • Page 7: Lieferumfang

    Rack - 7 - Montageanleitung Instructions de montage Montage-instructies Istruzioni di montaggio Installation instructions Instrucciones de montaje Lieferumfang Leveringsinhoud Scope of Supply Contenu de la livraison Dotazione Volumen de suministro Rack 1 Stk. TV Halterung 1 Stk. 4-Fach Netzverteiler 1x Ge echtschlauch 1x Klettkabelbinde 2x Senkschrauben (M5x20) G 3x Innensechskant (M6x30)
  • Page 8: Rack Vorbereiten

    Rack - 8 - Montageanleitung Instructions de montage Montage-instructies Istruzioni di montaggio Installation instructions Instrucciones de montaje Montage TV-Halterung Montage TV-houder TV bracket assembly Rack vorbereiten Rack voorbereiden Rack preparation Montage du support téléviseur Montaggio del supporto TV Montaje del soporte de TV Préparation du rack Predisposizione del rack Preparación del Rack...
  • Page 9: Rack Justieren

    Rack - 9 - Montageanleitung Instructions de montage Montage-instructies Istruzioni di montaggio Installation instructions Instrucciones de montaje Rack vorbereiten Rack voorbereiden Rack preparation Rack justieren Rack afstellen Rack adjustment Préparation du rack Predisposizione del rack Preparación del Rack Ajustage du rack Regolazione del rack Ajuste del Rack Im Rackinneren be ndet sich über jedem Fuß...
  • Page 10: Montage Tv Auf Rack

    Rack - 10 - Montageanleitung Instructions de montage Montage-instructies Istruzioni di montaggio Installation instructions Instrucciones de montaje Connect, Art, Xelos 46-32 LED/3D Connect, Art, Xelos 46-32 LED/3D Connect, Art, Xelos 46-32 LED/3D Standfuß demontieren Voet monteren Disassemble standing foot Connect, Art, Xelos 46-32 LED/3D Connect, Art, Xelos 46-32 LED/3D Connect, Art, Xelos 46-32 LED/3D Démontage du pied...
  • Page 11 Rack - 11 - Montageanleitung Instructions de montage Montage-instructies Istruzioni di montaggio Installation instructions Instrucciones de montaje Connect, Art, Xelos 46-32 LED/3D Connect, Art, Xelos 46-32 LED/3D Connect, Art, Xelos 46-32 LED/3D TV auf Rack montieren TV op rack monteren Mount TV on rack Connect, Art, Xelos 46-32 LED/3D Connect, Art, Xelos 46-32 LED/3D...
  • Page 12 Rack - 12 - Montageanleitung Instructions de montage Montage-instructies Istruzioni di montaggio Installation instructions Instrucciones de montaje Connect, Art, Xelos 46-32 LED/3D Connect, Art, Xelos 46-32 LED/3D Connect, Art, Xelos 46-32 LED/3D TV-Gerät neigen Instellen van de hellingshoek Tilting the TV set Connect, Art, Xelos 46-32 LED/3D Connect, Art, Xelos 46-32 LED/3D Connect, Art, Xelos 46-32 LED/3D...
  • Page 13: Xelos 32/40/46

    Rack - 13 - Montageanleitung Instructions de montage Montage-instructies Istruzioni di montaggio Installation instructions Instrucciones de montaje Xelos 32/40/46 Xelos 32/40/46 Xelos 32/40/46 TV auf Rack montieren TV op rack monteren Mount TV on rack Xelos 32/40/46 Xelos 32/40/46 Xelos 32/40/46 Montage du téléviseur sur le rack Montaggio dell‘apparecchio TV sul rack Montaje del TV en el Rack...
  • Page 14 Rack - 14 - Montageanleitung Instructions de montage Montage-instructies Istruzioni di montaggio Installation instructions Instrucciones de montaje 1 Schraube mit Beilagscheibe aus X1, 2 Schrauben aus X2 herausschrauben und aufbewahren. Standfuss vom TV-Gerät lösen und abziehen. Montageschritt 5 gilt nur für TV-Geräte vom Typ XELOS 32.
  • Page 15 Rack - 15 - Montageanleitung Instructions de montage Montage-instructies Istruzioni di montaggio Installation instructions Instrucciones de montaje TV-Gerät auf Adapter (A) aufsetzen Aufbewahrte Schrauben aus Löchern X2 wieder in X2 einstecken und handfest anschrauben. Montageschritt 8 gilt nur für TV-Geräte vom Typ XELOS 40/46.
  • Page 16: Connect Id

    Rack - 16 - Montageanleitung Instructions de montage Montage-instructies Istruzioni di montaggio Installation instructions Instrucciones de montaje Connect ID 46-32 Connect ID 46-32 Connect ID 46-32 TV auf Rack montieren TV op rack monteren Mount TV on rack Connect ID 46-32 Connect ID 46-32 Connect ID 46-32 Montage du téléviseur sur le rack...
  • Page 17 Rack - 17 - Montageanleitung Instructions de montage Montage-instructies Istruzioni di montaggio Installation instructions Instrucciones de montaje Zwei Zentrierstifte (Z) einsetzen und Adapterteil (G) mit Schrauben (I) und Scheiben (K) an der Rackhalterung handfest anschrauben. Adapterbasis (F) mit drei Schrauben (H) oben am vorher montierten Adapterteil (G) handfest anschrauben.
  • Page 18 Rack - 18 - Montageanleitung Instructions de montage Montage-instructies Istruzioni di montaggio Installation instructions Instrucciones de montaje TV-Gerät auf weiche Unterlage legen und Kabelfachabdeckung abnehmen Achtung! TV-Gerät muss bei der Montage von 2 Personen gehalten werden! TV-Gerät auf TV-Halter aufsetzen (hält ohne Schrauben) Flanschkopfschrauben (G) bis zum Anschlag eindrehen –...
  • Page 19 Rack - 19 - Montageanleitung Instructions de montage Montage-instructies Istruzioni di montaggio Installation instructions Instrucciones de montaje Zum Einstellen des Neigungswinkels des TV-Geräts, Schraube (J) mit Sechskantschlüssel SW5 etwas lösen Gewünschten Neigungswinkel einstellen Schraube (J) mit Sechskantschlüssel festziehen (handfest) Kabelfachabdeckung wieder einsetzen Voor het instellen van de hellingshoek het tv-toestel schroef (J) met inbussleutel SW5 iets losmaken Gewenste hellingshoek instellen...
  • Page 20: Equipment

    Réf. d’article Rack Kit di espansione N. articolo Kits de ampliación Número de referencia Rack 165.30 Rack 165.45 CS Rack 165.45 SP Rear Cover Rack 165.30 51491W00 – – Rear Cover Rack 165.45 51494W00 – Background Lighting Rack 51496W00 Interior Lighting Rack 51497B00 –...
  • Page 21: Montage

    Rack - 21 - Montageanleitung Instructions de montage Montage-instructies Istruzioni di montaggio Installation instructions Instrucciones de montaje Rear Cover Rack Rear Cover Rack Rear Cover Rack Lieferumfang Inhoud van de levering Scope of delivery Rear Cover Rack Rear Cover Rack Rear Cover Rack Contenu de la livraison Dotazione...
  • Page 22 Rack - 22 - Montageanleitung Instructions de montage Montage-instructies Istruzioni di montaggio Installation instructions Instrucciones de montaje Rear Cover Rack Rear Cover Rack Rear Cover Rack Montage Montage Installation Rear Cover Rack Rear Cover Rack Rear Cover Rack Montage Montaggio Montaje Raststift (C) in die Öffnung des Raststifthalters (D) einführen und diesen mit zwei Schrauben (B) an der...
  • Page 23: Center Speaker (Rack 165.45 Cs)

    Rack - 23 - Montageanleitung Instructions de montage Montage-instructies Istruzioni di montaggio Installation instructions Instrucciones de montaje Center Speaker Center Speaker Center Speaker Montage Montage Installation Center Speaker Center Speaker Center Speaker Montage Montaggio Montaje Wandhalter (W) vom Center Speaker demontieren. Hierzu die vier Schrauben lösen und Wandhalter Center Speaker abnehmen.
  • Page 24 Rack - 24 - Montageanleitung Instructions de montage Montage-instructies Istruzioni di montaggio Installation instructions Instrucciones de montaje Center Speaker Center Speaker Center Speaker Montage Montage Installation Center Speaker Center Speaker Center Speaker Montage Montaggio Montaje Center Speaker Center Speaker an den Wandhalter (W) montieren. Zur Befestigung des Center Speakers die vorher entfernten Schrauben verwenden.
  • Page 25: Sound Projector (Rack 165.45 Sp)

    Rack - 25 - Montageanleitung Instructions de montage Montage-instructies Istruzioni di montaggio Installation instructions Instrucciones de montaje Sound Projector Sound Projector Sound Projector Montage Montage Installation Sound Projector Sound Projector Sound Projector Montage Montaggio Montaje Den Einleger der Belüftungsöffnung entfernen. Träger (B) herausziehen.
  • Page 26: Sound Projector Z(Rack 165.45 Sp)

    Rack - 26 - Montageanleitung Instructions de montage Montage-instructies Istruzioni di montaggio Installation instructions Instrucciones de montaje Sound Projector Sound Projector Sound Projector Montage Montage Installation Sound Projector Sound Projector Sound Projector Montage Montaggio Montaje Verkabelung am Sound Projector vornehmen (siehe Bedienungsanleitung des Sound Projectors).
  • Page 27: Aufstellung

    Rack - 27 - Montageanleitung Instructions de montage Montage-instructies Istruzioni di montaggio Installation instructions Instrucciones de montaje Rack 165.30 Rack 165.30 Rack 165.30 Aufstellung Opstelling Set-up Rack 165.30 Rack 165.30 Rack 165.30 Installation Installazione Colocación In allen Fächern, in die Geräte eingestellt werden können, be nden sich im Boden Belüftungs-...
  • Page 28: Rack 165.45 Cs Mit Center Speaker

    Rack - 28 - Montageanleitung Instructions de montage Montage-instructies Istruzioni di montaggio Installation instructions Instrucciones de montaje Rack 165.45 CS Rack 165.45 CS Rack 165.45 CS Aufstellung (mit Center Speaker) Opstelling (met Center Speaker) Set-up (with Center Speaker) Rack 165.45 CS Rack 165.45 CS Rack 165.45 CS Installation (avec Center Speaker)
  • Page 29: Rack 165.45 Sp

    Wird der Sound Projector ganz rechts positioniert, kann nur der Loewe Subwoofer Compact f Si le Sound Projector est positionné tout à droite, seul le Loewe Subwoofer Compact peut être ins Rackinnere gestellt werden installé...
  • Page 30: Rack Verkabeln

    Rack - 30 - Montageanleitung Instructions de montage Montage-instructies Istruzioni di montaggio Installation instructions Instrucciones de montaje Rack verkabeln Rack bekabelen Rack Cabling Câblage du rack Cablaggio del rack Cableado del Rack Kabel am TV-Gerät anschließen (wie in dessen Bedienungsanleitung beschrieben). Kabel wie dargestellt verlegen (mit dem mitgelieferten Kabelschlauch, D) und durch die Öffnung hinten im Rack in das Rackinnere führen.
  • Page 31: Reinigung Und P Ege

    Rack - 31 - Montageanleitung Instructions de montage Montage-instructies Istruzioni di montaggio Installation instructions Instrucciones de montaje Reinigung und Pfelege Reiniging en onderhoud Cleaning and care Reinigen Sie die Gerätekombination mit einem Reinig de toestellencombinatie met een vochtige, Clean the devices using a soft, clean and damp feuchten, weichen und sauberen Tuch (ohne zachte en schone doek (zonder bijtende of schu- cloth (do not use aggressive or abrasive cleaning...
