911 E. Fox Farm Rd. #2
Cheyenne, WY 82007
Guarantee
No hassle refund
If you are not completely
satisfied with any ARROW
ANTENNA Product it can
be returned for a FULL
refund less shipping and
handling within 90 DAYS
of purchase date.
SIMPLY THE BEST
ArrowAntennas.com
Simply the Best
6 Meter ¼ Wave Ground Plane
(307) 222-4712
info@arrowantennas.com
Model
GP 52
Ground Plane
We don't invent antennas.
We simply build them better.
Advertisement
Table of Contents
Related Manuals for Arrow Antenna GP 52
Summary of Contents for Arrow Antenna GP 52
- Page 1 Simply the Best 6 Meter ¼ Wave Ground Plane Guarantee Model No hassle refund If you are not completely GP 52 satisfied with any ARROW ANTENNA Product it can Ground Plane be returned for a FULL refund less shipping and We don’t invent antennas.
- Page 2 53.0 52.0 51.0 Be sure to include the Coupling Nut in the measurement. Part # Price Model GP 52 Parts List GP5211 $10.00 3/8" X 55" Element with Coupling Nut and End Cap GP1262 $5.00 1/4" X 55 ½" Ground Radial with End Cap (Ground Radial) GP00013 $15.00...
- Page 3 Remember the ground radials must be attached and secure before installing the vertical element. 55” Element --------- Caution: Do NOT over-tighten the 55” element. 30 ft./lb. max. Coupling Nut --------- Shoulder Washer------ --------- Assembly / Mounting Bracket Saddle --------- ------3/8 x 24 Ground Radial -------- ------SO-239 Assembly Instructions...
- Page 4 CHECKLIST FOR OUR SHIPPING DEPARTMENT GP52 ___3/8" x 55" Element with Coupling Nut and End Cap ___4 @ 1/4" x 55 1/2" Ground Radials with End Cap ___1 1/2" x 2 1/2" x 2 1/2" Assembly / Mounting Bracket – has 4 bolts and 1 hole.
